▶ EnginePTO Power 18.2 hp (13.6 kW) — Alternator 12 V, 40 A — Air Cleaner Dual element Dual element with mechanical restriction indicator Engine Type Diesel Diesel Fuel System Indirect injection Indirect injection Displacement 77 in³ (1,267 cc) Three cylinders: 1.267 L, 77.3 cu in. No. of Cylinders 3 Three Rated Engine Speed 3200 rpm 3200 rpm Cooling System Type Water pump (liquid-cooled) Water pump Engine Manufacturer Yanmar Yanmar® Engine Emissions Constraints Tier 4 Final Tier 4 Engine Power (Gross vs. Net HP) Gross: 23.9 hp (17.8 kW) @ 3200 rpm; Net: Not Published SAE J1995 rated power: 17.8 kW, 23.9 hp, 24.2 PS at 3200 rpm ▶ WeightTractor Weight with Loader Not Published — Weight with Cab and Loader 63 in (1,600 mm) Cab: 906 kg, 1996 lb Weight with ROPS and Loader Not Published Cab: 906 kg, 1996 lb Tractor Weight (Base) — Open station: 706 kg, 1556 lb ▶ HydraulicsPump Type Tandem gear Single gear Steering Flow 13.25 L/min (3.5 gpm) — Implement Flow 13.25 L/min (3.5 gpm) — Total Hydraulic Flow 26.5 L/min (7.0 gpm) — Hydraulic System Type Open center — Rear Remote Hydraulic Flow Not Published — Overall Hydraulic Pump Flow 26.5 L/min (7.0 gpm) — No. of Optional Remote Valves 2 — No. of Standard Remote Valves 2 — Pump Flow (Total) — 24 L/min, 6.3 gpm Pump Flow (Steering) — 13.2 L/min, 3.5 gpm Pump Flow (Implement) — 13.2 L/min, 3.5 gpm System Operating Pressure — 138 bar, 2000 psi ▶ Tire OptionsR3 Turf - Rear 12-16.5 — R3 Turf - Front 23X8.50-12 — Tire Size & Options R3 Turf, R3 Radial, R4 Industrial — R4 Industrial - Rear 12-16.5 — R4 Industrial - Front 23X8.50-12 — R1 Agricultural - Rear Not Applicable — R1 Agricultural - Front Not Published — ▶ Pto & HitchPTO Rear 540 rpm — PTO Type Independent — Lift Control Type Position control — Hitch Lift Capacity 915 lb (415 kg) — Mid-PTO Availability Yes — Category, 3-Point Hitch Limited Category 1 — Hitch Lift Capacity (at 24”) 915 lb (415 kg) — Rear 3-Point Hitch Lift Capacity Not Published — ▶ Fluid CapacityCoolant Capacity 3.4 qt (3.2 L) — Crankcase Capacity 3.4 qt (3.2 L) 2.7 L, 2.9 gal. Fuel Tank Capacity 6.1 gal (23 L) 24 L, 6.3 U.S. gal. Front Axle Fluid Capacity 4.8 qt (4.5 L) — Transmission / Hydraulic System Capacity 6.9 gal (26 L) — Transmission/Hydraulic Capacity — 12.3 L, 3.2 gal. ▶ Loader & AttachmentsLoader Lift Height 72 in (1,828 mm) — Loader Breakout Force 1963 lbf (890 kgf) — Price for Backhoe Option Not Published — Price for Mid-Mount Mower Not Published — Quick Attach Loader System Quik-Park™ — Loader Lift Capacity (Full Height) 803 lb (364 kg) — ▶ Transmission & DrivetrainClutch Not Applicable — No. of Speeds Infinite (2-range) — Transmission Type Hydrostatic - two range — Max Travel Speed (Forward) Not Published — Max Travel Speed (Reverse) Not Published — Differential Lock & Limited Slip Options Differential lock: Yes; Limited slip differential: No — ▶ Chassis Steering & ControlsBrakes Wet disc — Steering Power steering — Frame Type Open operator station; folding ROPS — Front Axle Type Four-wheel drive (4WD) — Drawbar Capacity Not Published — Front Axle Rating 1,349 lb (612 kg) — Seat Suspension & Adjustability High-back seat with suspension — ▶ Dimensions & ManeuverabilityWheelbase Not Published — Overall Width Not Published — Ground Clearance Not Published — Height to Top of ROPS Not Published — Height to Top of Cab Model Not Published — Height to Top of ROPS (folded) Not Published — Min. Turn Radius without Brakes 98.4 in (2,510 mm) — Overall Length with 3-Point Hitch Not Published — ▶ Pricing Financing & WarrantyFinancing Options 90 Day No Interest No Payment; Free Delivery (up to $125) — Base Price with Loader Not Published — Warranty Length & Coverage 6-year/2,000-hour powertrain; 2-year/2,000-hour basic (full machine) — Base Price with Loader + Cab Not Published — ▶ PtoPTO Power — 13.6 kW, 18.2 hp Mid PTO (Type / RPM) — 2100 rpm Rear PTO (Type / RPM) — 540 rpm ▶ HitchThree-Point Hitch Category — Limited Category 1 Lift Capacity at 24 in Behind — 344 kg, 758 lb ▶ EnginePTO Power — 13.6 kW 18.2 hp Alternator — 40 amp (12-V) Air Cleaner — Dual element with mechanical restriction indicator Engine Type — Diesel Fuel System — Indirect injection Displacement — 1.267 L 77.3 cu in. No. of Cylinders — Three Rated Engine Speed — 3200 rpm Cooling System Type — Water pump Engine Manufacturer — Yanmar® Engine Emissions Constraints — Final Tier 4 Engine Power (Gross vs. Net HP) — 17.8 kW 23.9 hp 24.2 PS at 3200 rpm (SAE J1995 rated power) ▶ WeightWeight with Cab and Loader — approx. 1,996 lb (906 kg) shipping weight with cab Weight with ROPS and Loader — approx. 1,444 lb (706 kg) shipping weight open station (no loader); operating weight with loader approx. 1,556 lb (706 kg) shipping ▶ HydraulicsPump Type — Single gear Steering Flow — 13.2 L/min 3.5 gpm Implement Flow — 13.2 L/min 3.5 gpm Total Hydraulic Flow — 6.3 gpm 23.8 lpm Hydraulic System Type — Open center Rear Remote Hydraulic Flow — 3.5 gpm (13.2 L/min) per circuit (implement pump); dual SCVs standard Overall Hydraulic Pump Flow — 3.5 gpm 13.2 lpm No. of Optional Remote Valves — Three ▶ DimensionsWheelbase — 1450 mm, 57.1 in. Ground Clearance — 195 mm, 7.7 in. ▶ PTO & HitchPTO Rear — 540 rpm PTO Type — Independent Lift Control Type — position control Mid-PTO Availability — 2100 rpm Category, 3-Point Hitch — Limited Category 1 Rear 3-Point Hitch Lift Capacity — 344 kg 758 lb ▶ Tire OptionsR3 Turf - Rear — 26x12-12 R3 Turf - Front — 18x8.50-10 R4 Industrial - Rear — 26x12-12 R4 Industrial - Front — 18x8.5-10 ▶ TransmissionTransmission Type — Hydrostatic - two range ▶ Fluid CapacityCoolant Capacity — 3.7 L (0.98 gal) Crankcase Capacity — 2.7 L (0.71 gal) Fuel Tank Capacity — 21.2 L (5.6 gal) Front Axle Fluid Capacity — 2.8 L (0.74 gal) Transmission / Hydraulic System Capacity — 12.3 L (3.3 gal) ▶ Loader & AttachmentsLoader Breakout Force — 120R: 1,823 lbf (826 kg-force) at pivot point; H120: 1,724 lbf (782 kg-force) at pivot point Quick Attach Loader System — Quik-Park™ system (120R loader mounts/dismounts in ~1 minute, no tools needed) Loader Lift Capacity (Full Height) — 120R: 754 lb (342 kg) at pivot point to max height; H120: 703 lb (319 kg) at pivot point to max height ▶ Transmission & DrivetrainClutch — wet disc No. of Speeds — Hydrostatic — infinite speeds in 2 ranges (Hi / Lo) forward and reverse Transmission Type — hydrostatic Max Travel Speed (Forward) — 9.1 mph (14.5 km/h) Max Travel Speed (Reverse) — 9.1 mph (14.5 km/h) Differential Lock & Limited Slip Options — Differential lock Yes; Limited slip differential No ▶ Chassis, Steering & ControlsBrakes — Wet disc (left-hand pedal) Steering — Power Frame Type — Semi-flat platform; two-post folding ROPS; 4WD with mechanical front-wheel drive Front Axle Type — Four-wheel drive Front Axle Rating — Front 612 kg 1349 lb ▶ Dimensions & ManeuverabilityWheelbase — 57.1 inches 145 cm Overall Width — 47 in (119.4 cm) Ground Clearance — 195 mm 7.7 in. Min. Turn Radius without Brakes — 2.51 m 8.2 ft ▶ Pricing, Financing & WarrantyFinancing Options — 0% APR fixed rate for 60 months; 0% APR fixed rate for 72 Months PLUS $1,000 off Warranty Length & Coverage — 6-year / 2,000-hour powertrain warranty (standard); PowerGard extended warranty available ▶ SourcesSpec sheet sources [1] deere.com [2] deere.ca [3] deere.com [4] deere.com [5] deere.com [6] deere.com [1] deere.com [2] deere.com [3] deere.com [4] deere.com
