▶ EnginePTO Power 25.0 hp (18.6 kW) 17.4 hp (13.0 kW) Alternator 12 V, 55 A 12 V, 55 A Air Cleaner Dry, dual element Dry, dual element Engine Type Diesel, naturally aspirated Diesel, naturally aspirated, direct injection Fuel System High pressure common rail direct injection Direct injection Displacement 100.2 in³ (1,642 cc) 100.2 in³ (1,642 cc) No. of Cylinders 3 3 Rated Engine Speed 2500 rpm 2400 rpm Cooling System Type Water pump Liquid-cooled Engine Manufacturer Yanmar Yanmar Engine Emissions Constraints Final Tier 4 Final Tier 4 Engine Power (Gross vs. Net HP) Gross: 31.1 hp (22.9 kW) @ 2500 rpm Gross: 24.4 hp (18.2 kW) @ 2400 rpm ▶ WeightTractor Weight with Loader Not Published Not Published Weight with Cab and Loader Not Applicable Not Applicable Weight with ROPS and Loader Not Published Not Published ▶ HydraulicsPump Type Dual gear Dual gear Steering Flow 16.8 L/min (4.4 gpm) 15.0 L/min (4.0 gpm) Implement Flow 22.4 L/min (5.9 gpm) 20.2 L/min (5.3 gpm) Total Hydraulic Flow 39.2 L/min (10.3 gpm) 35.2 L/min (9.3 gpm) Hydraulic System Type Open center Open center Rear Remote Hydraulic Flow Not Published Not Published Overall Hydraulic Pump Flow 39.2 L/min (10.3 gpm) 35.2 L/min (9.3 gpm) No. of Optional Remote Valves Up to 2 (optional) Up to 2 (optional) No. of Standard Remote Valves Not Published Not Published ▶ Tire OptionsR3 Turf - Rear 41X14-20 41X14-20 R3 Turf - Front 27X8.50-15 27X8.50-15 Tire Size & Options R1 Bar, R3 Turf, R4 Industrial R1 Bar, R3 Turf, R4 Industrial R4 Industrial - Rear 15.00-19.5 or 43X16-20 15.00-19.5 or 43X16-20 R4 Industrial - Front 25X8.50-14 or 27X8.50-15 25X8.50-14 or 27X8.50-15 R1 Agricultural - Rear 11.2-24 11.2-24 R1 Agricultural - Front 7-14 7-14 ▶ Pto & HitchPTO Rear 540 rpm 540 rpm PTO Type Independent Not Published Lift Control Type Position control Not Published Hitch Lift Capacity Not Published 1,356 lb (615 kg) @ 24 in behind link arms Mid-PTO Availability Not Applicable Not Published Category, 3-Point Hitch Category 1 Category 1 Hitch Lift Capacity (at 24”) 1,356 lb (615 kg) @ 24 in behind center link 1,356 lb (615 kg) @ 24 in behind link arms Rear 3-Point Hitch Lift Capacity Not Published 1,356 lb (615 kg) @ 24 in behind link arms ▶ Fluid CapacityCoolant Capacity 4.9 L (1.3 gal) 1.24 gal (4.7 L) Crankcase Capacity 4.5 L (4.7 qt) (with filter) 1.06 gal (4.0 L) Fuel Tank Capacity 7.5 gal (28.5 L) 7.5 U.S. gal (28.5 L) Front Axle Fluid Capacity 3.8 L (1 gal) 3.2 L (3.4 qt) Transmission / Hydraulic System Capacity 20.8 L (5.5 gal) 5.5 gal (21 L) ▶ Loader & AttachmentsLoader Lift Height 84.0 in (2,140 mm) 84 in (2,140 mm) Loader Breakout Force 1,704 lb (760 kg) 1,704 lb (760 kg) Price for Backhoe Option Not Published Not Published Price for Mid-Mount Mower Not Published Not Published Quick Attach Loader System Quick-change attachment carrier Quick-change attachment carrier Loader Lift Capacity (Full Height) 1,186 lb (539 kg) 1,186 lb (539 kg) ▶ Transmission & DrivetrainClutch Not Applicable Not Applicable No. of Speeds Infinite (2-range HST) Not Published Transmission Type Hydrostatic (2-range) Hydrostatic transmission (HST) Max Travel Speed (Forward) Not Published Not Published Max Travel Speed (Reverse) Not Published Not Published Differential Lock & Limited Slip Options Not Published Not Published ▶ Chassis Steering & ControlsBrakes Wet disc Wet disc Steering Power steering Hydrostatic Frame Type Not Published Open operator station (OOS) Front Axle Type 4WD (MFWD) 4WD (MFWD) Drawbar Capacity Not Published Not Published Front Axle Rating Not Published Not Published Seat Suspension & Adjustability Not Published Not Published ▶ Dimensions & ManeuverabilityWheelbase 62.8 in (1,595 mm) 62.8 in (1,595 mm) Overall Width Not Published Not Published Ground Clearance 9.4 in (240 mm) 9.4 in (240 mm) Height to Top of ROPS Not Published Not Published Height to Top of Cab Model Not Applicable Not Applicable Height to Top of ROPS (folded) Not Published Not Published Min. Turn Radius without Brakes 9.4 ft (2.9 m) 9.4 ft (2.9 m) Overall Length with 3-Point Hitch Not Published Not Published ▶ Pricing Financing & WarrantyFinancing Options 0% APR fixed rate for 60 months 0% APR fixed rate for 60 months Base Price with Loader USD $25,760 (base machine) + USD $6,828 (factory-installed 300E loader w/ bucket) Not Published Warranty Length & Coverage 6-year/2,000-hour powertrain; 2-year/2,000-hour basic (full machine) 6-year/2,000-hour powertrain; 2-year/2,000-hour basic (full machine) Base Price with Loader + Cab Not Applicable Not Applicable ▶ SourcesSpec sheet sources [1] deere.com [2] deere.com [3] deere.com [4] explore.deere.com [5] deere.com [6] deere.com [1] deere.com [2] deere.com [3] deere.com [4] deere.com
