Pick up to 4tractors and we'll lay every spec sheet out side by side. Same data we publish on the individual model pages, stacked in columns so you can compare numbers at a glance.
No photo
—
JohnDeere3035D
No photo
—
BobcatCT2535
Comparison loaded for 2 tractors.
Spec
John Deere3035D
BobcatCT2535
PTO Power
30.4 hp
29.4 hp (21.9 kW)
Alternator
12 V, 55 A
Not Published
Air Cleaner
Dual element
Not Published
Engine Type
Liquid-cooled diesel, naturally aspirated,
Diesel
Fuel System
High pressure common rail direct injection
Not Published
Displacement
100.2 in³ (1,640 cc)
111.4 in³ (1.8 L)
No. of Cylinders
3
3
Rated Engine Speed
2800 rpm
2,600 rpm
Cooling System Type
Liquid
Not Published
Engine Manufacturer
Yanmar
Not Published
Engine Emissions Constraints
Final Tier 4
Not Published
Engine Power (Gross vs. Net HP)
34.2 hp gross (SAE J1995); Net: Not Published
34.9 hp (26.0 kW) (Gross)
Tractor Weight with Loader
Not Published
Not Published
Weight with Cab and Loader
Not Applicable
Not Published
Weight with ROPS and Loader
Not Published
Not Applicable
Pump Type
Single gear
Not Published
Steering Flow
16.8 L/min (4.4 gpm)
4.5 gpm
Implement Flow
22.4 L/min (5.9 gpm)
6.9 gpm
Total Hydraulic Flow
39.2 L/min (10.3 gpm)
43.2 L/min (11.4 gpm)
Hydraulic System Type
Open center
Not Published
Rear Remote Hydraulic Flow
Not Published
Not Published
Overall Hydraulic Pump Flow
39.2 L/min (10.3 gpm)
Not Published
No. of Optional Remote Valves
Up to two (optional)
2 pairs (rear)
No. of Standard Remote Valves
Not Published
Not Published
R3 Turf - Rear
41X14-20
Not Published
R3 Turf - Front
27X8.5-15
Not Published
Tire Size & Options
R1 Bar, R3 Turf, R4 Industrial
3,585 lb (1,626 kg)
R4 Industrial - Rear
15-19.5
Not Published
R4 Industrial - Front
25X8.5-14
Not Published
R1 Agricultural - Rear
11.2-24
Category 1
R1 Agricultural - Front
7-14
Not Published
PTO Rear
540 rpm at 2400 rpm engine
540 rpm
PTO Type
Mechanical control; transmission clutch; wet disk brake (mid/rear PTO)
Independent
Lift Control Type
Position control
Hydraulic Position Control System
Hitch Lift Capacity
Not Published
1,631 lb (740 kg)
Mid-PTO Availability
Not Published
Optional
Category, 3-Point Hitch
Category 1
Category 1
Hitch Lift Capacity (at 24”)
2081.2 lb (944 kg)
1,631 lb (740 kg)
Rear 3-Point Hitch Lift Capacity
Not Published
1,631 lb (740 kg)
Coolant Capacity
1.2 gal (4.5 L)
Not Published
Crankcase Capacity
1.1 gal (4.3 L)
Not Published
Fuel Tank Capacity
10.0 gal (38 L)
Not Published
Front Axle Fluid Capacity
1.0 gal (3.8 L)
Not Published
Transmission / Hydraulic System Capacity
9.2 gal (35 L)
Not Published
Loader Lift Height
84.0 in (2,140 mm)
Not Published
Loader Breakout Force
1,704 lb (760 kg)
Not Published
Price for Backhoe Option
Not Published
Not Published
Price for Mid-Mount Mower
Not Published
Not Published
Quick Attach Loader System
Quick-change attachment carrier
Not Published
Loader Lift Capacity (Full Height)
1,186 lb (539 kg)
1,389 lb (630 kg)
Clutch
Single dry traction clutch
Wet multi-disc
No. of Speeds
8F/8R
Infinite (3-range HST)
Transmission Type
8F/8R synchromesh shuttle shift gear transmission
Infinite, 3-range hydrostatic (HST)
Max Travel Speed (Forward)
Not Published
14.4 mph (23.1 km/hr.)
Max Travel Speed (Reverse)
Not Published
10.1 mph (16.2 km/hr.)
Differential Lock & Limited Slip Options
Differential lock: Yes; limited slip: Not Published
Std
Brakes
Wet disk
Not Published
Steering
Power steering
Hydrostatic power steering
Frame Type
Not Published
Not Published
Front Axle Type
MFWD (4WD)
Not Published
Drawbar Capacity
Not Published
Not Published
Front Axle Rating
1940 lb (880 kg)
Not Published
Seat Suspension & Adjustability
Not Published
Not Published
Wheelbase
62 in (1,574 mm)
65.7 in (1,670 mm)
Overall Width
57.3 in (1,456 mm) [at 44.5 in (1,130 mm) rear tread]
62.4 in (1,584 mm)
Ground Clearance
13.0 in (331 mm) minimum
12.3 in (311 mm)
Height to Top of ROPS
Not Published
Not Applicable
Height to Top of Cab Model
Not Applicable
91.0 in (2,311 mm)
Height to Top of ROPS (folded)
Not Published
Not Applicable
Min. Turn Radius without Brakes
Not Published
106.3 in (2,700 mm)
Overall Length with 3-Point Hitch
Not Published
120.9 in (3,070 mm)
Financing Options
0% APR fixed rate for 60 months
0% for 84 months for as low as $453/month OR Free Front-end Loader
