▶ EnginePTO Power 57.6 hp (43.0 kW) (OOS); 57.6 hp (43.0 kW) (Cab) 60.0 hp (44.7 kW) (manufacturer’s estimated PTO horsepower) Alternator 12 V, 60 A (OOS); 12 V, 110 A (Cab) 12 V, 75 A Air Cleaner Dry type air cleaner with safety element Dry type with safety element Engine Type Diesel, turbocharged and aftercooled Diesel, turbocharged and aftercooled Fuel System Electronically controlled, high-pressure common rail High pressure common-rail direct injection Displacement 179 in³ (2,933 cc) 127.6 in³ (2091 cc) No. of Cylinders 3 4 Rated Engine Speed 2100 rpm 2600 rpm Cooling System Type Liquid-cooled Liquid-cooled Engine Manufacturer John Deere PowerTech™ 3029 EWR Yanmar Engine Emissions Constraints EPA Final Tier 4 Final Tier 4 Engine Power (Gross vs. Net HP) Gross: 74.8 hp (55.0 kW) @2100 rpm (97/68/EC) Gross: 74.6 hp (55.6 kW); Net: Not Published ▶ WeightTractor Weight with Loader Not Published Not Published Weight with Cab and Loader Not Published Not Published Weight with ROPS and Loader Not Published Not Published ▶ HydraulicsPump Type Tandem gear pump (implement + steering) Open center Steering Flow 25.7 L/min (6.8 gpm) 23.48 L/min (6.2 gpm) Implement Flow 43.1 L/min (11.4 gpm) 42.6 L/min (11.2 gpm) Total Hydraulic Flow 68.8 L/min (18.2 gpm) 66.0 L/min (17.4 gpm) Hydraulic System Type Open center Open center Rear Remote Hydraulic Flow 43.1 L/min (11.4 gpm) at a single rear SCV Not Published Overall Hydraulic Pump Flow 68.8 L/min (18.2 gpm) 66.0 L/min (17.4 gpm) No. of Optional Remote Valves 2 Up to 6 rear remotes available No. of Standard Remote Valves 1 Not Published ▶ Tire OptionsR3 Turf - Rear 41X14.00-20 4PR R3; 44X18.00-20 4PR R3 (Premium) 44X18-20 or 22.5LL-16.1 R3 Turf - Front 33X15.50-15 6PR R3; 33X12.50-15 6PR R3; 29X12.5-15 4PR R3 (Premium) 27X10.5-15 or 27X12LL-15 Tire Size & Options R1 Ag / R3 Turf / R4 Industrial / Snow R1 Ag / R3 Turf / R4 Industrial / Snow R4 Industrial - Rear 17.5L-24 8PR R4; 19.5L-24 8PR R4; 16.9-30 10PR R4; 43X16.00-20 R4; 43X16.00-20 R4 (Premium); 18.4-30 10PR R4 16.9LX24 R4 Industrial - Front 27/12LL-15 6PR R4; 10-16.5 8PR R4; 28X8.50-15 8PR R4; 12.5/80-18 12PR R4 10-16.5 R1 Agricultural - Rear 14.9-28 6PR R1; 16.9-28 6PR R1; 16.9-30 6PR R1; 18.4-30 6PR R1; 460/85R30 R1; 460/85R30 R1W 13.6-28 R1 Agricultural - Front 9.5-24 10PR R1; 12.4-24 8PR R1; 320/85R24 R1; 320/85R24 R1W 8-16 ▶ Pto & HitchPTO Rear 540 @ 2083 engine rpm; 540E @ 1588 engine rpm 540 rpm @ 2600 rpm (540E optional) PTO Type Independent PTO: 540 (SyncShuttle); 540/540E (PowrReverser) Independent (wet disc clutch); PTO brake for mid & rear PTO Lift Control Type Position and draft control; adjustable rate of drop Position control (draft sensing) Hitch Lift Capacity 3,968 lb (1,800 kg) @ hitch points 3,079 lb (1,397 kg) at hitch balls Mid-PTO Availability Not Applicable Not Published Category, 3-Point Hitch Category II; convertible to Category I Limited Category 1 Hitch Lift Capacity (at 24”) 3,197 lb (1,450 kg) @ 24 in behind hitch balls 2,709 lb (1,229 kg) @ 24 in behind Rear 3-Point Hitch Lift Capacity 3,968 lb (1,800 kg) @ hitch points 3,079 lb (1,397 kg) at hitch balls ▶ Fluid CapacityCoolant Capacity Open operator station: 2.85 gal (13 L); Cab: 3.08 gal (14 L) 8.0 qt (7.6 L) Crankcase Capacity 9.0 qt (8.5 L) (with filter) 5.7 qt (5.4 L) (with filter) Fuel Tank Capacity Open operator station: 15.6 ± 0.44 gal (71 ± 2 L); Cab: 17.59 ± 0.44 gal (80 ± 2 L) 14.7 gal (55.6 L) Front Axle Fluid Capacity DANA: 1.18 gal (4.5 L) diff + 0.21 gal (0.8 L) per hub; Carraro: 1.03 gal (3.9 L) diff + 0.15 gal (0.6 L) per side 5.8 qt (5.5 L) Transmission / Hydraulic System Capacity 8.36 gal (38 L) (9x3); 9.46 gal (43 L) (12x12) 12.5 gal (47.3 L) ▶ Loader & AttachmentsLoader Lift Height 124 in (3,150 mm) 110 in (2,796 mm) Loader Breakout Force 4,354 lb (1,975 kg) (measured at pivot) 3,835 lbf (1,743.7 kgf) @ pivot Price for Backhoe Option Not Published Not Published Price for Mid-Mount Mower Not Published Not Published Quick Attach Loader System Parkable loader (parking system; no tools required for removal/installation); optional John Deere skid steer attachment carrier (tool-free attachment changes) Quick-Park Loader System; Quik-Change Attachment Carrier Loader Lift Capacity (Full Height) 3,225 lb (1,463 kg) (measured at pivot) 2,313 lb (1,006 kg) @ pivot ▶ Transmission & DrivetrainClutch Dual clutch, 11 in (PowrReverser) Not Applicable (hydrostatic transmission) No. of Speeds 9 forward / 3 reverse (SyncShuttle); 12 forward / 12 reverse (PowrReverser) Infinitely variable / 3 range Transmission Type SyncShuttle™ 9F/3R (standard); PowrReverser™ 12F/12R (optional) eHydro / 3-range hydrostatic Max Travel Speed (Forward) 15.5 mph (25.0 km/h) (SyncShuttle); 20.5 mph (32.9 km/h) (PowrReverser) 18.7 mph (30.1 km/h) Max Travel Speed (Reverse) 14.2 mph (22.8 km/h) (SyncShuttle); 22.3 mph (36.0 km/h) (PowrReverser) 18.7 mph (30.1 km/h) Differential Lock & Limited Slip Options Mechanical differential lock (pedal) Differential lock: Yes ▶ Chassis Steering & ControlsBrakes Hydraulically actuated wet disk brakes (self-equalizing and self-adjusting) Multi-plate wet disc Steering Hydrostatic power steering Hydrostatic power steering Frame Type Not Published Not Published Front Axle Type 2WD (standard) or MFWD (optional) MFWD (4WD) Drawbar Capacity 1,675 lb (760 kg) (fully extended); 2,470 lb (1,120 kg) (short position) Not Published Front Axle Rating Up to 9,612 lb (4,360 kg) (max permissible MFWD axle load w/ loader; varies by tire) 3,307 lb (1,500 kg) continuous Seat Suspension & Adjustability Mechanical suspension with weight adjustment; fore/aft and backrest angle adjustment Air suspension with swivel seat ▶ Dimensions & ManeuverabilityWheelbase 80.7 in (2,050 mm) 73.0 in (1,855 mm) Overall Width Not Published 78.3 in (1,989 mm) Ground Clearance Not Published 13.8 in (351 mm) Height to Top of ROPS Not Published 104.3 in (2,650 mm) Height to Top of Cab Model Not Published 97.4 in (2,474 mm) Height to Top of ROPS (folded) Not Published 80.0 in (2,033 mm) Min. Turn Radius without Brakes 137.8 in (3,500 mm) (2WD); 183.1 in (4,650 mm) (4WD) 126.0 in (3,200 mm) Overall Length with 3-Point Hitch 143.3 in (3,639 mm) 133.4 in (3,390 mm) ▶ Pricing Financing & WarrantyFinancing Options 0% APR fixed rate for 60 months 0% APR fixed rate for 48 months Base Price with Loader Not Published Not Published Warranty Length & Coverage 6-year/2,000-hour powertrain; 2-year/2,000-hour basic (full machine) 6-year/2,000-hour powertrain; 2-year/2,000-hour basic (full machine) Base Price with Loader + Cab Not Published Not Published ▶ SourcesSpec sheet sources [1] deere.com [2] johndeere.widen.net [3] deere.com [1] deere.com [2] johndeere.widen.net [3] deere.com [4] deere.com
