John Deere 5075M vs John Deere 4066M Heavy Duty | Side-by-side comparison

ITC Company

Good things come to those who wait.


PTO Power	57.7 hp (43 kW) @2100 rpm (SAE)	51.9 hp (38.7 kW)
Alternator	OOS: 90 A; Cab: 120 A; Field Installed Option: 200 A	12 V, 75 A
Air Cleaner	Dry air cleaner	Dual element
Engine Type	Diesel, turbocharged and air-to-air aftercooled	Diesel
Fuel System	High Pressure Common Rail (HPCR) electronic fuel injection	High-pressure common rail direct injection
Displacement	177 in³ (2,900 cc)	127.6 in³ (2091 cc)
No. of Cylinders	3	4
Rated Engine Speed	2200 rpm	2600 rpm
Cooling System Type	Not Published	Liquid
Engine Manufacturer	John Deere PowerTech™ 3029 EWR	Yanmar
Engine Emissions Constraints	EPA Final Tier 4 (DOC/DPF)	Final Tier 4
Engine Power (Gross vs. Net HP)	Gross: 73.9 hp (55 kW) @2200 rpm (97/68/EC)	Gross: 65 hp (48.5 kW) @ 2600 rpm (SAE J1995); Net: Not Published

Tractor Weight with Loader	Not Published	Not Published
Weight with Cab and Loader	Not Published	Not Applicable
Weight with ROPS and Loader	Not Published	Not Published

Pump Type	Tandem Gear	Single gear
Steering Flow	24 L/min (6.3 gpm)	23.5 L/min (6.2 gpm)
Implement Flow	70 L/min (18.4 gpm)	42.3 L/min (11.2 gpm)
Total Hydraulic Flow	94 L/min (24.7 gpm)	Not Published
Hydraulic System Type	Not Published	Open center
Rear Remote Hydraulic Flow	Not Published	Not Published
Overall Hydraulic Pump Flow	94 L/min (24.7 gpm)	Not Published
No. of Optional Remote Valves	Up to 1 additional (rear) (max 3 total)	Not Published
No. of Standard Remote Valves	2 (rear)	2

R3 Turf - Rear	Not Published	Not Published
R3 Turf - Front	Not Published	Not Published
Tire Size & Options	R1 Ag / R3 Turf / R4 Industrial	R4 Industrial
R4 Industrial - Rear	Not Published	16.9-24 (8PR) or 19.5L-24 (10PR)
R4 Industrial - Front	Not Published	31.5X13.00-16.5 (10PR)
R1 Agricultural - Rear	Not Published	Not Published
R1 Agricultural - Front	Not Published	Not Published

PTO Rear	540 @2100 engine rpm; 540E @1645 engine rpm; 1000 @2100 engine rpm (if equipped)	540 rpm
PTO Type	Independent rear PTO (wet disc clutch, electrohydraulic activation): 540/540E standard; 1000 optional	Independent (electrohydraulic)
Lift Control Type	Mechanical or electrohydraulic (draft control)	Position control
Hitch Lift Capacity	5,305 lb (2,406 kg) @ hitch ball (standard 65 mm cylinders); 6,114 lb (2,773 kg) optional (65 & 75 mm cylinders)	Not Published
Mid-PTO Availability	Not Published	Available
Category, 3-Point Hitch	Category II (convertible to Category I)	Category 1/2 (telescopic)
Hitch Lift Capacity (at 24”)	5,161 lb (2,341 kg) @ 24 in (610 mm) behind lift point (standard); 5,958 lb (2,702 kg) optional	2,500 lb (1,134 kg)
Rear 3-Point Hitch Lift Capacity	5,305 lb (2,406 kg) @ hitch ball (standard); 6,114 lb (2,773 kg) optional	Not Published

Coolant Capacity	OOS: 3.6 gal (13.5 L); Cab: 4.2 gal (16 L)	Open station: 6.8 qt (6.4 L); Cab: 8.0 qt (7.6 L) (if equipped)
Crankcase Capacity	2.2 gal (8.5 L)	5.6 qt (5.3 L) (with filter)
Fuel Tank Capacity	Cab: 48.2 gal (182.6 L); OOS: 44.6 gal (169 L)	Open station: 15.0 gal (56.9 L); Cab: 14.7 gal (55.6 L) (if equipped)
Front Axle Fluid Capacity	Differential housing (MFWD): 1.3 gal (5 L); Wheel hub (each): 0.2 gal (0.8 L)	5.3 qt (5.0 L)
Transmission / Hydraulic System Capacity	Open center: 10.4 gal (39.5 L); Closed center: 12.5 gal (47.5 L)	12.5 gal (47.3 L)

Loader Lift Height	Not Published	112.1 in (2,850 mm)
Loader Breakout Force	Not Published	At pivot: 3,853 lbf (1,743.7 kgf); @ 500 mm ahead of pivot: 2,902 lbf (1,315.4 kgf)
Price for Backhoe Option	Not Published	Not Published
Price for Mid-Mount Mower	Not Published	Not Published
Quick Attach Loader System	Not Published	Rigid mounted with parking kit available; Parking stand kit BW16127 (parkable)
Loader Lift Capacity (Full Height)	Not Published	At pivot: 2,396 lb (1,087 kg); @ 500 mm ahead of pivot: 1,764 lb (800 kg)

Clutch	Not Published	Wet; wet clutch disk diameter 5.08 in (129 mm)
No. of Speeds	16 forward / 16 reverse; 32 forward / 16 reverse (Hi-Lo)	eHydro: Infinitely-variable, 3 range; PowrReverser: 12F/12R
Transmission Type	PowrReverser™ 16F/16R or 32F/16R Hi-Lo	Standard: eHydro (eHST), 3-range hydrostatic; Optional: 12/12 PowrReverser (PRT)
Max Travel Speed (Forward)	Not Published	18.6 mph (30 km/h)
Max Travel Speed (Reverse)	Not Published	18.6 mph (30 km/h)
Differential Lock & Limited Slip Options	Not Published	Differential lock: Yes

Brakes	Hydraulically actuated wet disc brakes	Multi-plate wet disc
Steering	Not Published	Hydrostatic power steering
Frame Type	Not Published	ROPS - Foldable
Front Axle Type	MFWD	Mechanical front wheel drive (MFWD) - Standard; engagement On-the-Go
Drawbar Capacity	Not Published	Max vertical load 500 kg (1103 lb)
Front Axle Rating	6,613 lb (3,000 kg) max permissible front axle load	(Continuous) 1500 kg (3307 lb)
Seat Suspension & Adjustability	Not Published	Not Published

Wheelbase	92.5 in (2,350 mm)	73.0 in (1,855 mm)
Overall Width	74.0 in (1,880 mm) (without fender extension); 85.6 in (2,175 mm) (with fender extension)	71.3 in (1,811 mm)
Ground Clearance	Not Published	Front axle: 15.2 in (386 mm); Drawbar support: 14.5 in (369 mm)
Height to Top of ROPS	Not Published	91.1 in (2,315 mm)
Height to Top of Cab Model	105.3 in (2,677 mm)	Not Applicable
Height to Top of ROPS (folded)	Not Published	65.9 in (1,675 mm)
Min. Turn Radius without Brakes	157.5 in (4,000 mm)	17.1 ft (5.2 m)
Overall Length with 3-Point Hitch	Cab overall length: 157.3 in (3,996 mm)	134.7 in (3,421 mm)

Financing Options	0% APR fixed rate for 60 months	0% APR fixed rate for 60 months
Base Price with Loader	Not Published	Not Published
Warranty Length & Coverage	6-year/2,000-hour powertrain; 2-year/2,000-hour basic (full machine)	6-year/2,000-hour powertrain; 2-year/2,000-hour basic (full machine)
Base Price with Loader + Cab	Not Published	Not Applicable

Spec sheet sources	[1] deere.com [2] manuals.deere.com [3] johndeere.widen.net	[1] deere.com [2] explore.deere.com [3] deere.com

PTO Power

57.7 hp (43 kW) @2100 rpm (SAE)

51.9 hp (38.7 kW)

Alternator

OOS: 90 A; Cab: 120 A; Field Installed Option: 200 A

12 V, 75 A

Air Cleaner

Dry air cleaner

Dual element

Engine Type

Diesel, turbocharged and air-to-air aftercooled

Diesel

Fuel System

High Pressure Common Rail (HPCR) electronic fuel injection

High-pressure common rail direct injection

Displacement

177 in³ (2,900 cc)

127.6 in³ (2091 cc)

No. of Cylinders

Rated Engine Speed

2200 rpm

2600 rpm

Cooling System Type

Not Published

Liquid

Engine Manufacturer

John Deere PowerTech™ 3029 EWR

Yanmar

Engine Emissions Constraints

EPA Final Tier 4 (DOC/DPF)

Final Tier 4

Engine Power (Gross vs. Net HP)

Gross: 73.9 hp (55 kW) @2200 rpm (97/68/EC)

Gross: 65 hp (48.5 kW) @ 2600 rpm (SAE J1995); Net: Not Published

Tractor Weight with Loader

Not Published

Weight with Cab and Loader

Not Published

Not Applicable

Weight with ROPS and Loader

Not Published

Pump Type

Tandem Gear

Single gear

Steering Flow

24 L/min (6.3 gpm)

23.5 L/min (6.2 gpm)

Implement Flow

70 L/min (18.4 gpm)

42.3 L/min (11.2 gpm)

Total Hydraulic Flow

94 L/min (24.7 gpm)

Not Published

Hydraulic System Type

Not Published

Open center

Rear Remote Hydraulic Flow

Not Published

Overall Hydraulic Pump Flow

94 L/min (24.7 gpm)

Not Published

No. of Optional Remote Valves

Up to 1 additional (rear) (max 3 total)

Not Published

No. of Standard Remote Valves

2 (rear)

R3 Turf - Rear

Not Published

R3 Turf - Front

Not Published

Tire Size & Options

R1 Ag / R3 Turf / R4 Industrial

R4 Industrial

R4 Industrial - Rear

Not Published

16.9-24 (8PR) or 19.5L-24 (10PR)

R4 Industrial - Front

Not Published

31.5X13.00-16.5 (10PR)

R1 Agricultural - Rear

Not Published

R1 Agricultural - Front

Not Published

PTO Rear

540 @2100 engine rpm; 540E @1645 engine rpm; 1000 @2100 engine rpm (if equipped)

540 rpm

PTO Type

Independent rear PTO (wet disc clutch, electrohydraulic activation): 540/540E standard; 1000 optional

Independent (electrohydraulic)

Lift Control Type

Mechanical or electrohydraulic (draft control)

Position control

Hitch Lift Capacity

5,305 lb (2,406 kg) @ hitch ball (standard 65 mm cylinders); 6,114 lb (2,773 kg) optional (65 & 75 mm cylinders)

Not Published

Mid-PTO Availability

Not Published

Available

Category, 3-Point Hitch

Category II (convertible to Category I)

Category 1/2 (telescopic)

Hitch Lift Capacity (at 24”)

5,161 lb (2,341 kg) @ 24 in (610 mm) behind lift point (standard); 5,958 lb (2,702 kg) optional

2,500 lb (1,134 kg)

Rear 3-Point Hitch Lift Capacity

5,305 lb (2,406 kg) @ hitch ball (standard); 6,114 lb (2,773 kg) optional

Not Published

Coolant Capacity

OOS: 3.6 gal (13.5 L); Cab: 4.2 gal (16 L)

Open station: 6.8 qt (6.4 L); Cab: 8.0 qt (7.6 L) (if equipped)

Crankcase Capacity

2.2 gal (8.5 L)

5.6 qt (5.3 L) (with filter)

Fuel Tank Capacity

Cab: 48.2 gal (182.6 L); OOS: 44.6 gal (169 L)

Open station: 15.0 gal (56.9 L); Cab: 14.7 gal (55.6 L) (if equipped)

Front Axle Fluid Capacity

Differential housing (MFWD): 1.3 gal (5 L); Wheel hub (each): 0.2 gal (0.8 L)

5.3 qt (5.0 L)

Transmission / Hydraulic System Capacity

Open center: 10.4 gal (39.5 L); Closed center: 12.5 gal (47.5 L)

12.5 gal (47.3 L)

Loader Lift Height

Not Published

112.1 in (2,850 mm)

Loader Breakout Force

Not Published

At pivot: 3,853 lbf (1,743.7 kgf); @ 500 mm ahead of pivot: 2,902 lbf (1,315.4 kgf)

Price for Backhoe Option

Not Published

Price for Mid-Mount Mower

Not Published

Quick Attach Loader System

Not Published

Rigid mounted with parking kit available; Parking stand kit BW16127 (parkable)

Loader Lift Capacity (Full Height)

Not Published

At pivot: 2,396 lb (1,087 kg); @ 500 mm ahead of pivot: 1,764 lb (800 kg)

Clutch

Not Published

Wet; wet clutch disk diameter 5.08 in (129 mm)

No. of Speeds

16 forward / 16 reverse; 32 forward / 16 reverse (Hi-Lo)

eHydro: Infinitely-variable, 3 range; PowrReverser: 12F/12R

Transmission Type

PowrReverser™ 16F/16R or 32F/16R Hi-Lo

Standard: eHydro (eHST), 3-range hydrostatic; Optional: 12/12 PowrReverser (PRT)

Max Travel Speed (Forward)

Not Published

18.6 mph (30 km/h)

Max Travel Speed (Reverse)

Not Published

18.6 mph (30 km/h)

Differential Lock & Limited Slip Options

Not Published

Differential lock: Yes

Brakes

Hydraulically actuated wet disc brakes

Multi-plate wet disc

Steering

Not Published

Hydrostatic power steering

Frame Type

Not Published

ROPS - Foldable

Front Axle Type

MFWD

Mechanical front wheel drive (MFWD) - Standard; engagement On-the-Go

Drawbar Capacity

Not Published

Max vertical load 500 kg (1103 lb)

Front Axle Rating

6,613 lb (3,000 kg) max permissible front axle load

(Continuous) 1500 kg (3307 lb)

Seat Suspension & Adjustability

Not Published

Wheelbase

92.5 in (2,350 mm)

73.0 in (1,855 mm)

Overall Width

74.0 in (1,880 mm) (without fender extension); 85.6 in (2,175 mm) (with fender extension)

71.3 in (1,811 mm)

Ground Clearance

Not Published

Front axle: 15.2 in (386 mm); Drawbar support: 14.5 in (369 mm)

Height to Top of ROPS

Not Published

91.1 in (2,315 mm)

Height to Top of Cab Model

105.3 in (2,677 mm)

Not Applicable

Height to Top of ROPS (folded)

Not Published

65.9 in (1,675 mm)

Min. Turn Radius without Brakes

157.5 in (4,000 mm)

17.1 ft (5.2 m)

Overall Length with 3-Point Hitch

Cab overall length: 157.3 in (3,996 mm)

134.7 in (3,421 mm)

Financing Options

0% APR fixed rate for 60 months

Base Price with Loader

Not Published

Warranty Length & Coverage

6-year/2,000-hour powertrain; 2-year/2,000-hour basic (full machine)

Base Price with Loader + Cab

Not Published

Not Applicable

Spec sheet sources

[1] deere.com [2] manuals.deere.com [3] johndeere.widen.net

[1] deere.com [2] explore.deere.com [3] deere.com
