▶ EnginePTO Power 16.5 hp 15.4 hp Alternator Not Published 40 A, 12 V Air Cleaner Not Published Single dry Engine Type Liquid-cooled, diesel 3 Cylinder, Water-Cooled, Diesel (Natural aspiration) Fuel System Not Published Indirect fuel injection Displacement 56.6 in³ 60.6 in³ No. of Cylinders 3 3 Rated Engine Speed 2800 rpm 3200 rpm Cooling System Type Liquid-cooled Water-cooled Engine Manufacturer KIOTI (Daedong) Yanmar Engine Power (Gross) 21 hp 21.5 hp Engine Emissions Constraints Not Published Tier 4 ▶ WeightTractor Weight with Loader Not Published Not Published Weight with Cab and Loader Not Applicable Not Published Weight with ROPS and Loader Not Published 1,433 lb ▶ HydraulicsPump Type Not Published Single gear pump with flow divider Steering Flow Not Published 2.11 gpm Implement Flow Not Published 4.17 gpm Total Hydraulic Flow 7.66 gpm 6.97 gpm (max total flow) Hydraulic System Type Not Published Not Published Rear Remote Hydraulic Flow Not Published Not Published Overall Hydraulic Pump Flow 7.66 gpm 6.97 gpm (max total flow) No. of Optional Remote Valves 1 Up to 1 No. of Standard Remote Valves 0 Not Published ▶ PTO & HitchPTO Rear 540 rpm 540 rpm PTO Type Transmission Independent Lift Control Type Not Published Position Hitch Lift Capacity 1,631 lb 1,100 lb Mid-PTO Availability Yes (2,000 rpm) Optional (2,500 rpm) Category, 3-Point Hitch Category 1 Category I (N) Hitch Lift Capacity (at 24”) 1,109 lb 679 lb ▶ Tire OptionsR3 Turf - Rear 33X12.5-16.5 TURF R 16X12.00-12 R3 Turf - Front 24X8.50-12/4 TURF F 16X7.50-8 Tire Size & Options R1 Agricultural, R3 Turf, R4 Industrial R1 (BAR) / R3 (TURF) / R4 (IND) R4 Industrial - Rear 12-16.5 26X12-12 R4 Industrial - Front 24X8.50-12/4 18X8.50-10 R1 Agricultural - Rear 9.5-16 BAR R 24X12.00-12 R1 Agricultural - Front 6.0-12 BAR F 16X7.50-9 ▶ Fluid CapacityCoolant Capacity Not Published 3.7 qt Crankcase Capacity Not Published 2.1 qt (with filter) Fuel Tank Capacity 5.28 gal 6.6 gal Front Axle Fluid Capacity Not Published 2.6 qt Transmission / Hydraulic System Capacity Not Published 3.6 gal ▶ Loader & AttachmentsLoader Lift Height 88.0 in 72.7 in (under level bucket); 78.5 in (pivot pin) Loader Breakout Force 1,515 lb 1,531 lb (at pivot pin, ground level) Price for Backhoe Option Not Published Not Published Price for Mid-Mount Mower Not Published Optional 54 in mid-mount mower deck Quick Attach Loader System Not Published Yes (quick attach) Loader Lift Capacity (Full Height) 1,076 lb 992 lb (at pivot pin) ▶ Transmission & DrivetrainClutch Not Published Dry single plate No. of Speeds 6F/2R 2 Range Transmission Type Partially synchronized HST Max Travel Speed (Forward) 10.1 mph 7.8 mph Max Travel Speed (Reverse) Not Published Not Published Differential Lock & Limited Slip Options Not Published Mechanical rear differential lock ▶ Chassis, Steering & ControlsBrakes Wet disc Wet disc Steering Power steering Hydrostatic Frame Type Not Published Sub-compact tractor, 4WD Front Axle Type Not Published Center pin front axle Drawbar Capacity Not Published Not Published Front Axle Rating Not Published Not Published Seat Suspension & Adjustability Not Published Standard adjustable seat ▶ Dimensions & ManeuverabilityWheelbase 57.9 in 53.1 in Overall Width 44.1 in 44.5 in Ground Clearance 12.2 in 8.3 in Height to Top of ROPS 77.5 in 86.6 in Height to Top of Cab Model Not Applicable Not Published Height to Top of ROPS (folded) Not Published Not Published Min. Turn Radius without Brakes Not Published Not Published Overall Length with 3-Point Hitch 105.7 in 94.2 in ▶ Pricing, Financing & WarrantyFinancing Options Available through KIOTI dealers Payments as low as $180.00/month Base Price with Loader Not Published Not Published Warranty Length & Coverage Limited: Tractors (Non-Commercial Application) 24 months parts & labor; Extended (driveline): 48 months parts & labor 7-year powertrain warranty Base Price with Loader + Cab Not Applicable Not Published ▶ ITC Company AccessoriesAccessories that fit
