Tractor Comparison
Pick up to 4tractors and we'll lay every spec sheet out side by side. Same data we publish on the individual model pages, stacked in columns so you can compare numbers at a glance.
No photo
—
KiotiCS2510
No photo
—
KiotiCS2220
Comparison loaded for 2 tractors.
Spec
KiotiCS2510
KiotiCS2220
PTO Power
19.4 hp (14.5 kW)
16.3 hp (12.2 kW)
Alternator
12 V, 40 A
12 V, 50 A
Air Cleaner
Dry type (cyclone type)
Not Published
Engine Type
Liquid-cooled, diesel
In-line vertical, water-cooled turbo, diesel
Fuel System
Injection pump type: Bosch; nozzle type: Throttle
Injection pump
Displacement
69.0 in³ (1,131 cc)
61.5 in³ (1,007 cc)
No. of Cylinders
3
3
Rated Engine Speed
3,000 rpm
3,200 rpm
Cooling System Type
Liquid-cooled
Water-cooled
Engine Manufacturer
Shibaura (S773L-F21)
KIOTI (Daedong)
Engine Emissions Constraints
Not Published
U.S. EPA non-road emission regulation
Engine Power (Gross vs. Net HP)
Gross: 24.5 hp (18.3 kW)
Gross: 21 hp (15.7 kW)
Tractor Weight with Loader
Not Published
2,127 lb (964 kg)
Weight with Cab and Loader
Not Applicable
Not Applicable
Weight with ROPS and Loader
Not Published
2,127 lb (964 kg)
Pump Type
Not Published
Gear
Steering Flow
Not Published
Not Published
Implement Flow
Not Published
26.5 L/min (7.0 gpm)
Total Hydraulic Flow
6.5 gpm (24.6 L/min)
26.4 L/min (6.97 gpm)
Hydraulic System Type
Open center
Open center
Rear Remote Hydraulic Flow
Not Published
Not Published
Overall Hydraulic Pump Flow
6.5 gpm (24.6 L/min)
26.4 L/min (6.97 gpm)
No. of Optional Remote Valves
Not Published
Not Published
No. of Standard Remote Valves
Not Published
1
R3 Turf - Rear
26X12.00-12
26X12.00-12
R3 Turf - Front
18X8.5-8
18X8.50-10
Tire Size & Options
TractorData lists industrial tire sizes (see R4 rows); other tire options not specified.
R1 Agricultural, R3 Turf, R4 Industrial
R4 Industrial - Rear
26X12.00-12
26X12.00-12
R4 Industrial - Front
18X8.50-10
18X8.50-10
R1 Agricultural - Rear
Not Applicable
26X12.00-12
R1 Agricultural - Front
Not Applicable
18X8.50-10
PTO Rear
540 rpm
540 rpm
PTO Type
Independent
Independent (wet multi disc clutch)
Lift Control Type
Position control
Inching
Hitch Lift Capacity
Not Published
1,580 lb (715 kg)
Mid-PTO Availability
Available (2,200 rpm)
Standard
Category, 3-Point Hitch
Category 1
SAE Category I
Hitch Lift Capacity (at 24”)
700 lbs (318 kg)
700 lb (318 kg)
Rear 3-Point Hitch Lift Capacity
700 lbs (318 kg) (at 24 in)
1,580 lb (715 kg)
Coolant Capacity
3.7 qt (3.5 L)
0.87 gal (3.3 L)
Crankcase Capacity
3.2 qt (3.0 L)
1.0 gal (3.8 L)
Fuel Tank Capacity
6.7 gal (25.5 L)
6.7 gal (25.5 L)
Front Axle Fluid Capacity
0.5 gal (2.0 L)
0.53 gal (2.0 L)
Transmission / Hydraulic System Capacity
3.4 gal (13.0 L)
2.75 gal (10.4 L)
Loader Lift Height
70.9 in (1,800.9 mm)
73.7 in (1,872 mm)
Loader Breakout Force
1,435.2 lb (651.0 kg)
1,329.0 lb (603.0 kg)
Price for Backhoe Option
Not Published
SB2420: $8,882 MSRP (KIOTI notes subframe & bucket are sold separately)
