▶ EnginePTO Power 28.3 hp (21.1 kW) (claimed) 34.9 hp (26.0 kW) Alternator 12 V, 50 A 12 V, 75 A Air Cleaner Not Published Not Published Engine Type 4-cycle, liquid-cooled, diesel In-line vertical, water-cooled 4-cycle diesel, CRDI Fuel System Not Published Common rail direct injection (CRDI) Displacement 100.5 in³ (1,647 cc) 111.4 in³ (1,826 cc) No. of Cylinders 3 3 Rated Engine Speed 2,700 rpm 2,600 rpm Cooling System Type Liquid-cooled Water-cooled Engine Manufacturer KIOTI (Daedong) KIOTI (Daedong) Engine Emissions Constraints Not Published Not Published Engine Power (Gross vs. Net HP) Gross: 35 hp (26.1 kW); Net: Not Published Gross: 39.6 hp (29.5 kW) ▶ WeightTractor Weight with Loader Not Published Not Published Weight with Cab and Loader Not Published Not Published Weight with ROPS and Loader Not Published Not Published ▶ HydraulicsPump Type Not Published Gear Steering Flow 17.8 L/min (4.7 gpm) Not Published Implement Flow 29.5 L/min (7.8 gpm) Not Published Total Hydraulic Flow 47.3 L/min (12.5 gpm) 44.4 L/min (11.7 gpm) Hydraulic System Type Not Published Open center Rear Remote Hydraulic Flow Not Published Not Published Overall Hydraulic Pump Flow 47.3 L/min (12.5 gpm) 44.4 L/min (11.7 gpm) No. of Optional Remote Valves 1 Not Published No. of Standard Remote Valves 0 Optional (2 valves/4 ports) ▶ Tire OptionsR3 Turf - Rear 41X14-20 41X14-20/4 R3 Turf - Front 27X8.50-15 28X8.5-15/6 Tire Size & Options R1 Agricultural, R3 Turf, R4 Industrial R1 Agricultural, R3 Turf, R4 Industrial R4 Industrial - Rear 14.9X24 15-19.5 R4 Industrial - Front 10X16.5 27X8.5-15 R1 Agricultural - Rear 12.4-24 11.2-24 R1 Agricultural - Front 7-16 7-16 ▶ Pto & HitchPTO Rear 540 rpm 540 rpm (1.375) PTO Type Independent Live Lift Control Type Position and draft control Position control Hitch Lift Capacity 2,270 lb (1,029 kg) (listed as “at ends”) Not Published Mid-PTO Availability Optional (2000 rpm) Optional, 2,000 rpm Category, 3-Point Hitch Category I Category I Hitch Lift Capacity (at 24”) 2,425 lb (1,099 kg) 1,631 lb (740 kg) Rear 3-Point Hitch Lift Capacity 2,425 lb (1,099 kg) (at 24 in) 1,631 lb (740 kg) at 24 in (610 mm) ▶ Fluid CapacityCoolant Capacity Not Published Not Published Crankcase Capacity Not Published Not Published Fuel Tank Capacity 11.5 gal (43.5 L) 9.0 gal (34.0 L) Front Axle Fluid Capacity 10 qt (9.5 L) Not Published Transmission / Hydraulic System Capacity 7.8 gal (29.5 L) Not Published ▶ Loader & AttachmentsLoader Lift Height Not Published 98.4 in (2,500 mm) Loader Breakout Force Not Published 3,464 lb (1,571 kg) Price for Backhoe Option Not Published Not Published Price for Mid-Mount Mower Not Published Not Published Quick Attach Loader System Not Published Not Published Loader Lift Capacity (Full Height) Not Published 1,835 lb (832 kg) ▶ Transmission & DrivetrainClutch Not Published Dry dual stage No. of Speeds 8F/8R 9F/3R Transmission Type Synchronized shuttle Manual Max Travel Speed (Forward) Not Published 14.63 mph (23.56 km/h) Max Travel Speed (Reverse) Not Published 9.56 mph (15.39 km/h) Differential Lock & Limited Slip Options Not Published Rear differential lock (standard) ▶ Chassis Steering & ControlsBrakes Wet disc Wet multi disc Steering Hydrostatic power steering Hydrostatic power steering Frame Type 4x4 MFWD 4WD Not Published Front Axle Type 4WD (MFWD) 4WD Drawbar Capacity Not Published Not Published Front Axle Rating Not Published Not Published Seat Suspension & Adjustability Not Published Not Published ▶ Dimensions & ManeuverabilityWheelbase 65.7 in (1,660 mm) 65.7 in (1,670 mm) Overall Width 57.1 in (1,450 mm) 55.1 in (1,400 mm) (R1); 63.1 in (1,600 mm) (R4) Ground Clearance 11.4 in (280 mm) 13.4 in (340 mm) Height to Top of ROPS 92.5 in (2,340 mm) 99.2 in (2,520 mm) Height to Top of Cab Model Not Published 91.7 in (2,330 mm) Height to Top of ROPS (folded) Not Published Not Published Min. Turn Radius without Brakes Not Published Not Published Overall Length with 3-Point Hitch 126.3 in (3,200 mm) 120.9 in (3,070 mm) ▶ Pricing Financing & WarrantyFinancing Options Available through Kioti dealers Available through Kioti dealers Base Price with Loader Not Published Not Published Warranty Length & Coverage Limited: Tractors (Non-Commercial Application) 24 months parts & labor; Extended (driveline): 48 months parts & labor Limited: Tractors (Non-Commercial Application) 24 months parts & labor; Extended (driveline): 48 months parts & labor Base Price with Loader + Cab Not Applicable Not Published ▶ SourcesSpec sheet sources [1] tractordata.com [1] tractordata.com [2] tractorgearbox.com [3] agro-specs.com [4] payeur.com
