Pick up to 4tractors and we'll lay every spec sheet out side by side. Same data we publish on the individual model pages, stacked in columns so you can compare numbers at a glance.
No photo
—
KiotiDK50
No photo
—
TYMT474C
Comparison loaded for 2 tractors.
Spec
KiotiDK50
TYMT474C
PTO Power
41.5 hp (30.9 kW)
35.9 hp (26.4 kW)
Alternator
12 V, 50 A
12 V, 70 A
Air Cleaner
Not Published
Single dry
Engine Type
Turbocharged diesel, liquid-cooled
4-cylinder, naturally aspirated diesel
Fuel System
Indirect injection
IDI
Displacement
122.0 in³ (2,000 cc)
139.5 in³ (2,286 cc)
No. of Cylinders
4
4
Rated Engine Speed
2,600 rpm
2,600 rpm
Cooling System Type
Liquid-cooled
Not Published
Engine Manufacturer
KIOTI (Daedong)
TYM
Engine Emissions Constraints
Not Published
Stage V
Engine Power (Gross vs. Net HP)
Gross: 49 hp (36.5 kW)
Gross: 48.3 hp (36 kW)
Tractor Weight with Loader
Not Published
4,628 lb (2,099 kg)
Weight with Cab and Loader
Not Published
4,628 lb (2,099 kg)
Weight with ROPS and Loader
Not Published
Not Applicable
Pump Type
Not Published
Dual gear pump
Steering Flow
Not Published
16.1 L/min (4.2 gpm)
Implement Flow
Not Published
29 L/min (7.7 gpm)
Total Hydraulic Flow
Not Published
45.1 L/min (11.9 gpm)
Hydraulic System Type
Open center
Open center
Rear Remote Hydraulic Flow
Not Published
Not Published
Overall Hydraulic Pump Flow
53.7 L/min (14.2 gpm)
45.1 L/min (11.9 gpm)
No. of Optional Remote Valves
Not Published
Not Published
No. of Standard Remote Valves
Not Published
1
R3 Turf - Rear
21.5X16.1
12.5x20
R3 Turf - Front
29X12.50-15
Multi-Trac CS 27x10.5-15 NHS TL 4PR
Tire Size & Options
R1 Agricultural, R3 Turf, R4 Industrial
R1 Agricultural, R3 Turf, R4 Industrial
R4 Industrial - Rear
17.5X24
Xtra Grip 43x16.00-20 NHS TL 6PR
R4 Industrial - Front
12X16.5
Trac Chief 10-16.50 NHS TL 6PR
R1 Agricultural - Rear
14.9-24
Farm Specialist 12.4-24 NHS TL 6PR
R1 Agricultural - Front
9.5-16
Farm Specialist 8.0-16 NHS TL 6PR
PTO Rear
540 rpm (1.375)
540 rpm
PTO Type
Independent
Independent
Lift Control Type
Position and draft control
Position control
Hitch Lift Capacity
2,646 lb (1,200 kg) (at 24 in)
2,689.6 lb (1,220 kg)
Mid-PTO Availability
Not Published
Available (Mid-PTO kit)
Category, 3-Point Hitch
Category I/II
Category I
Hitch Lift Capacity (at 24”)
2,646 lb (1,200 kg)
1,764 lb (673 kg)
Rear 3-Point Hitch Lift Capacity
2,646 lb (1,200 kg) (at 24 in)
2,689.6 lb (1,220 kg)
Coolant Capacity
9.4 qt (8.9 L)
6.9 qt (6.5 L)
Crankcase Capacity
7.4 qt (7.0 L)
6.8 qt (6.4 L)
Fuel Tank Capacity
10.6 gal (40.1 L)
9.0 gal (34 L)
Front Axle Fluid Capacity
Not Published
8.7 qt (8.2 L)
Transmission / Hydraulic System Capacity
9.9 gal (37.5 L)
8.5 gal (32.2 L)
Loader Lift Height
Not Published
105.6 in (2,683 mm)
Loader Breakout Force
Not Published
3,198 lb (1,450.8 kg)
Price for Backhoe Option
Not Published
BY75
Price for Mid-Mount Mower
Not Published
Not Published
Quick Attach Loader System
Not Published
TX47: Quick attachment (Skid/Euro type)
Loader Lift Capacity (Full Height)
Not Published
2,152 lb (976.2 kg)
Clutch
Dry disc
Dry single plate
No. of Speeds
12F/12R
F12 x R12
Transmission Type
Synchronized shuttle
Mechanical
Max Travel Speed (Forward)
15.3 mph (24.6 km/h)
14.9 mph (24 km/h)
Max Travel Speed (Reverse)
15.3 mph (24.6 km/h)
Not Published
Differential Lock & Limited Slip Options
Mechanical rear differential lock
Not Published
Brakes
Wet disc
Wet disc
Steering
Power steering
Hydrostatic
Frame Type
Not Published
Not Published
Front Axle Type
4WD (MFWD)
Not Published
Drawbar Capacity
Not Published
Not Published
Front Axle Rating
Not Published
Not Published
Seat Suspension & Adjustability
Not Published
Not Published
Wheelbase
71.6 in (1,819 mm)
69.7 in (1,770 mm)
Overall Width
61 in (1,549 mm)
54.5 in (1,385 mm)
Ground Clearance
14.6 in (371 mm)
12.8 in (325 mm)
Height to Top of ROPS
88 in (2,235 mm)
Not Applicable
Height to Top of Cab Model
92 in (2,337 mm)
92.5 in (2,350 mm)
Height to Top of ROPS (folded)
Not Published
Not Applicable
Min. Turn Radius without Brakes
Not Published
117.5 in (2,985 mm)
Overall Length with 3-Point Hitch
130.8 in (3,320 mm)
131 in (3,320 mm)
Financing Options
Available through Kioti dealers
0% financing for up to 72 months and instant cash rebates. Contact dealer for more information.
Base Price with Loader
Not Published
Not Published
Warranty Length & Coverage
Limited: Tractors (Non-Commercial Application) 24 months parts & labor; Extended (driveline): 48 months parts & labor
Up to 2 years or until the 2,000 hours mark, bumper-to-bumper warranty; 3000 hours maximum coverage period for parts and labour on drivetrains or powertrains; 12-months warranty period for implements, including loaders and backhoes.
