▶ EnginePTO Power 45.2 hp (33.7 kW) 43.1 hp (32.1 kW) Alternator 12 V, 50 A Not Published Air Cleaner Not Published Not Published Engine Type Turbocharged diesel, liquid-cooled Diesel Fuel System In-line pump system; mechanical control; indirect injection Not Published Displacement 134.1 in³ (2,198 cc) 111.4 in³ (1,826 cc) No. of Cylinders 4 3 Rated Engine Speed 2,600 rpm 2,750 rpm Cooling System Type Liquid-cooled Not Published Engine Manufacturer KIOTI (Daedong) Not Published Engine Emissions Constraints Tier IV Interim Not Published Engine Power (Gross vs. Net HP) Gross: 55 hp (41.0 kW) 55.0 hp (41.0 kW) (Gross) ▶ WeightTractor Weight with Loader Not Published Not Published Weight with Cab and Loader Not Published Not Published Weight with ROPS and Loader Not Published Not Applicable ▶ HydraulicsPump Type Tandem gear Not Published Steering Flow 15.9 L/min (4.2 gpm) 31.1 L/min (8.2 gpm) Implement Flow 37.5 L/min (9.9 gpm) 36.3 L/min (9.6 gpm) Total Hydraulic Flow 53.7 L/min (14.2 gpm) 67.6 L/min (17.8 gpm) Hydraulic System Type Not Published Not Published Rear Remote Hydraulic Flow Not Published Not Published Overall Hydraulic Pump Flow 53.7 L/min (14.2 gpm) 67.6 L/min (17.8 gpm) No. of Optional Remote Valves Not Published 2 No. of Standard Remote Valves 2 1 ▶ Tire OptionsR3 Turf - Rear 21.5LX16.1/4 Not Published R3 Turf - Front 29X12.5X15/6 Not Published Tire Size & Options R1 Agricultural, R3 Turf, R4 Industrial Not Published R4 Industrial - Rear 17.5X24/8 Not Published R4 Industrial - Front 12X16.5/6 Not Published R1 Agricultural - Rear 14.9-28 Not Published R1 Agricultural - Front 9.5-20/6 Not Published ▶ Pto & HitchPTO Rear 540/1000 RPM 540 rpm PTO Type Independent Independent Lift Control Type Top link draft sensing Position with Draft Control Hitch Lift Capacity 2,643 lbs (1,198 kg) at 24 in 3,177 lb (1,441 kg) Mid-PTO Availability Not Published Optional: 2,103 rpm Category, 3-Point Hitch Category II/I Category 1 Hitch Lift Capacity (at 24”) 2,643 lbs (1,198 kg) 3,177 lb (1,441 kg) Rear 3-Point Hitch Lift Capacity 2,643 lbs (1,198 kg) at 24 in 3,177 lb (1,441 kg) ▶ Fluid CapacityCoolant Capacity Not Published Not Published Crankcase Capacity Not Published Not Published Fuel Tank Capacity 18 gal (68.1 L) 14.8 gal (56.0 L) Front Axle Fluid Capacity Not Published Not Published Transmission / Hydraulic System Capacity Not Published Not Published ▶ Loader & AttachmentsLoader Lift Height Not Published Not Published Loader Breakout Force Not Published Not Published Price for Backhoe Option Not Published Not Published Price for Mid-Mount Mower Not Published Not Published Quick Attach Loader System Not Published Not Published Loader Lift Capacity (Full Height) Not Published 2,346 lb (1,064 kg) ▶ Transmission & DrivetrainClutch Dry disc Not Applicable No. of Speeds 12F/12R Not Applicable Transmission Type Synchronized shuttle Infinite, 3 Range Hydrostatic (Servo control valve with Electric sol.) Max Travel Speed (Forward) 16.4 mph (26.4 km/h) 17.5 mph (28.2 km/hr) Max Travel Speed (Reverse) Not Published 17.5 mph (28.2 km/hr) Differential Lock & Limited Slip Options Mechanical rear differential lock Std ▶ Chassis Steering & ControlsBrakes Wet disc brakes Wet Multi-Disc Steering Power steering Hydrostatic power steering Frame Type Not Published Not Published Front Axle Type Not Published Not Published Drawbar Capacity Not Published Not Published Front Axle Rating Not Published Not Published Seat Suspension & Adjustability Not Published Not Published ▶ Dimensions & ManeuverabilityWheelbase 76.8 in (1,950 mm) 75.6 in (1,920 mm) Overall Width 69.3 in (1,760 mm) 74.2 in (1,885 mm) Ground Clearance 17.5 in (440 mm) 13.0 in (330 mm) Height to Top of ROPS 106.5 in (2,705 mm) Not Applicable Height to Top of Cab Model 104 in (2,640 mm) 94.2 in (2,393 mm) Height to Top of ROPS (folded) 85.5 in (2,170 mm) Not Applicable Min. Turn Radius without Brakes Not Published 117.6 in (2,990 mm) Overall Length with 3-Point Hitch 130.5 in (3,316 mm) 139.6 in (3,547 mm) ▶ Pricing Financing & WarrantyFinancing Options Available through KIOTI dealers 0% for 72 months for as low as $729/month USD OR Free Front-end Loader. Offers end February 28, 2026. Base Price with Loader Not Published $52,436 USD Warranty Length & Coverage Limited: Tractors (Non-Commercial Application) 24 months parts & labor; Extended (driveline): 48 months parts & labor 24 months / 1,500 hours (whichever occurs first) Base Price with Loader + Cab Not Published $52,436 USD (cab standard) ▶ SourcesSpec sheet sources [1] tractordata.com [2] tractorgearbox.com [1] bobcat.com [2] res.cloudinary.com [3] ds-cdn-media.cwsplatform.com
