Pick up to 4tractors and we'll lay every spec sheet out side by side. Same data we publish on the individual model pages, stacked in columns so you can compare numbers at a glance.
—
KiotiDK5520
—
BobcatCT5555
Comparison loaded for 2 tractors.
Spec
KiotiDK5520
BobcatCT5555
PTO Power
46.4 hp
43.1 hp
Alternator
Not Published
Not Published
Air Cleaner
Not Published
Not Published
Engine Type
Diesel, 4-cycle, water-cooled engine
Diesel
Fuel System
Not Published
Not Published
Displacement
111.4 in³
111.4 in³
No. of Cylinders
3
3
Rated Engine Speed
2600 rpm
2750 rpm
Cooling System Type
Water-cooled
Not Published
Engine Manufacturer
KIOTI (Daedong)
Not Published
Engine Power (Gross)
55 hp
55 hp
Engine Emissions Constraints
Not Published
Not Published
Tractor Weight with Loader
Not Published
Not Published
Weight with Cab and Loader
Not Published
Not Published
Weight with ROPS and Loader
Not Published
Not Applicable
Pump Type
Gear
Not Published
Steering Flow
4.94 gpm
8.2 gpm
Implement Flow
9.62 gpm
9.6 gpm
Total Hydraulic Flow
14.56 gpm
17.8 gpm
Hydraulic System Type
Not Published
Not Published
Rear Remote Hydraulic Flow
Not Published
Not Published
Overall Hydraulic Pump Flow
14.56 gpm
17.8 gpm
No. of Optional Remote Valves
2 (Optional)
2
No. of Standard Remote Valves
Not Published
1
PTO Rear
540 rpm
540 rpm
PTO Type
Independent
Independent
Lift Control Type
Position
Position with Draft Control
Hitch Lift Capacity
2,998 lb
3,177 lb
Mid-PTO Availability
Optional
Optional: 2,103 rpm
Category, 3-Point Hitch
Category II
Category 1
Hitch Lift Capacity (at 24”)
2,716 lb
3,177 lb
R3 Turf - Rear
5.7 gal-16.1
Not Published
R3 Turf - Front
29X12.50-15
Not Published
Tire Size & Options
R1 Agricultural, R3 Turf, R4 Industrial
Not Published
R4 Industrial - Rear
14.9-24
Not Published
R4 Industrial - Front
10-16.5
Not Published
R1 Agricultural - Rear
13.6-24
Not Published
R1 Agricultural - Front
8.0-16
Not Published
Coolant Capacity
0.89 gal (engine only)
Not Published
Crankcase Capacity
1.95 gal
Not Published
Fuel Tank Capacity
11.9 gal
14.8 gal
Front Axle Fluid Capacity
1.48 gal
Not Published
Transmission / Hydraulic System Capacity
11.4 gal
Not Published
Loader Lift Height
107.7 in (to pivot point)
Not Published
Loader Breakout Force
3,895 lb (at pivot pins)
Not Published
Price for Backhoe Option
KB2485: $9,504 MSRP (subframe & bucket sold separately)
Not Published
Price for Mid-Mount Mower
Not Published
Not Published
Quick Attach Loader System
Quick attach (QA) bucket
Not Published
Loader Lift Capacity (Full Height)
2,474 lb @ 59.84 in pivot pin height
2,346 lb
Clutch
Dry single stage
Not Applicable
No. of Speeds
8F/8R
Not Applicable
Transmission Type
Synchro shuttle
Infinite, 3 Range Hydrostatic (Servo control valve with Electric sol.)
Max Travel Speed (Forward)
16.71 mph
17.5 mph (28.2 km/hr)
Max Travel Speed (Reverse)
16.28 mph
17.5 mph (28.2 km/hr)
Differential Lock & Limited Slip Options
Rear differential lock (standard)
Std
Brakes
Wet disc type
Wet Multi-Disc
Steering
Hydrostatic Power Steering
Hydrostatic power steering
Frame Type
Not Published
Not Published
Front Axle Type
Mechanical 4WD
Not Published
Drawbar Capacity
1,655 lb (Vertical Load)
Not Published
Front Axle Rating
Not Published
Not Published
Seat Suspension & Adjustability
Not Published
Not Published
Wheelbase
71.3 in
75.6 in
Overall Width
62.8 in
74.2 in
Ground Clearance
14.5 in
13.0 in
Height to Top of ROPS
96.8 in
Not Applicable
Height to Top of Cab Model
Not Published
94.2 in
Height to Top of ROPS (folded)
Not Published
Not Applicable
Min. Turn Radius without Brakes
Not Published
117.6 in
Overall Length with 3-Point Hitch
124.8 in
139.6 in
Financing Options
Available through KIOTI dealers
0% for 72 months for as low as $729/month USD OR Free Front-end Loader. Offers end February 28, 2026.
