▶ EnginePTO Power 33.9 hp (25.3 kW) 36.6 hp (27.3 kW) Alternator Not Published Not Published Air Cleaner Not Published Not Published Engine Type In-Line Vertical, Water-cooled 4-Cycle Turbo Diesel, CRDI In-line Vertical, Water-cooled 4-cycle Turbo Diesel, CRDI (Engine model: 3HT-S4TM45A) Fuel System Common Rail Direct Injection (CRDI) Common Rail Direct Injection (CRDI) Displacement 111.40 in³ (1,826 cc) 111.4 in³ (1,826 cc) No. of Cylinders 3 3 Rated Engine Speed 2,600 rpm 2,600 rpm Cooling System Type Water-cooled Water-cooled Engine Manufacturer KIOTI (Daedong) KIOTI (Daedong) Engine Emissions Constraints Tier 4 Tier 4 Engine Power (Gross vs. Net HP) Gross: 45 hp (33.6 kW) Gross: 45 hp (33.6 kW) ▶ WeightTractor Weight with Loader Not Published Not Published Weight with Cab and Loader Not Applicable Not Applicable Weight with ROPS and Loader 4,000 lb (1,814.4 kg) 4,027.0 (1,827.0) (Weight w/AG tires) ▶ HydraulicsPump Type Gear Gear Steering Flow 31.2 L/min (8.2 gpm) 26 L/min (6.87 gpm) Implement Flow 36.4 L/min (9.6 gpm) 36.4 L/min (9.61 gpm) Total Hydraulic Flow 67.60 L/min (17.90 gpm) 62.4 L/min (16.48 gpm) Hydraulic System Type Open Center Open Center Rear Remote Hydraulic Flow Not Published Not Published Overall Hydraulic Pump Flow 67.60 L/min (17.90 gpm) 62.4 L/min (16.48 gpm) No. of Optional Remote Valves 1 1 No. of Standard Remote Valves 1 1 ▶ Tire OptionsR3 Turf - Rear 21.5lx16.1 21.5L-16.1 R3 Turf - Front 29x12.5-15 29X12.5-15 Tire Size & Options R1 Agricultural, R3 Turf, R4 Industrial R1 Agricultural, R3 Turf, R4 Industrial R4 Industrial - Rear 14.9-24 14.9-24 R4 Industrial - Front 10-16.5 10-16.5 R1 Agricultural - Rear 13.6-24 13.6-24 R1 Agricultural - Front 8.0-16 8.0-16 ▶ Pto & HitchPTO Rear 540 rpm 540 rpm PTO Type Independent Independent Lift Control Type Position with Draft Control Position, Draft, Mixed Control Hitch Lift Capacity Not Published 2,940 lb (1,334 kg) Mid-PTO Availability Optional (2,000 rpm) Optional (2,000 rpm) Category, 3-Point Hitch Category I Category I Hitch Lift Capacity (at 24”) 3,177 lbs (1,441 kg) 2,493 lb (1,131 kg) Rear 3-Point Hitch Lift Capacity 3,177 lbs (1,441 kg) (at 24 in) 2,940 lb (1,334 kg) ▶ Fluid CapacityCoolant Capacity 2.0 gal (7.7 L) 2.03 gal (7.7 L) Crankcase Capacity 1.58 gal (6.0 L) 1.95 gal (7.4 L) Fuel Tank Capacity 14.8 gal (56 L) 13.2 gal (50 L) Front Axle Fluid Capacity 1.8 gal (7.0 L) 2.25 gal (8.5 L) Transmission / Hydraulic System Capacity 11.89 gal (45 L) 11.36 gal (43 L) ▶ Loader & AttachmentsLoader Lift Height 108.3 in (2,750 mm) 106.30 in (2,700 mm) Loader Breakout Force 3,727 lb (1,691 kg) 3,896 lb (1,767 kg) Price for Backhoe Option KB2485: $9,504 MSRP (KIOTI notes subframe & bucket sold separately) KB2485: $9,504 MSRP (KIOTI notes subframe and bucket sold separately) Price for Mid-Mount Mower Not Applicable Not Applicable Quick Attach Loader System Built-in parking stand; quick attach/detach; single-lever joystick control with float; bucket level indicator Built-in parking stand; designed to be quickly and easily attached/detached Loader Lift Capacity (Full Height) 2,761 lb (1,252 kg) 2,621 lb (1,189 kg) ▶ Transmission & DrivetrainClutch None Dry type single stage No. of Speeds 3 Range F12 X R12 Transmission Type Hydrostatic Synchro shuttle Max Travel Speed (Forward) 16.52 mph (26.59 km/h) 16.7 mph (26.8 km/h) Max Travel Speed (Reverse) 16.52 mph (26.59 km/h) 14.8 mph (23.8 km/h) Differential Lock & Limited Slip Options Differential Lock: Rear (Standard) Mechanical differential lock: rear standard ▶ Chassis Steering & ControlsBrakes Wet Multi Disc Wet disc type Steering Hydrostatic Power Steering Hydrostatic power steering Frame Type Not Published Not Published Front Axle Type Not Published Not Published Drawbar Capacity Not Published Not Published Front Axle Rating Not Published Not Published Seat Suspension & Adjustability Adjustable Seat Deluxe suspension seat ▶ Dimensions & ManeuverabilityWheelbase 75.6 in (1,920 mm) 75.5 in (1,918 mm) Overall Width 65.6 in (1,665 mm) 67.1 in (1,704.3 mm) Ground Clearance 13.7 in (350 mm) 13.4 in (340.4 mm) Height to Top of ROPS 103.1 in (2,618 mm) 98.4 (2,499.4) w/o Beacon Height to Top of Cab Model Not Applicable Not Applicable Height to Top of ROPS (folded) Not Published Not Published Min. Turn Radius without Brakes 9.81 ft (2.99 m) Not Published Overall Length with 3-Point Hitch 139.6 in (3,547 mm) 136.4 in (3,465 mm) ▶ Pricing Financing & WarrantyFinancing Options NX Series offers listed: up to $4,000 cash offer OR 0% APR up to 36 months OR 6.99% interest rate Available through KIOTI dealers Base Price with Loader Tractor Starting MSRP $33,024 + LOADER $7,535 = $40,559 MSRP Tractor Starting MSRP $32,038 + LOADER $8,048 = $40,086 MSRP Warranty Length & Coverage Tractors (Non-Commercial Application): 24 months parts & labor; Tractors (Non-Commercial Application and driveline): 48 months parts & labor; eligible purchases may receive total 6 years (72 months) extended powertrain warranty coverage (limited time) Limited: Tractors (Non-Commercial Application) 24 months parts & labor; Extended (driveline): 48 months parts & labor Base Price with Loader + Cab Not Applicable Not Applicable ▶ SourcesSpec sheet sources [1] kioti.com [2] kioti-api.files.svdcdn.com [3] daedong-kioti.com [1] kioti.com [2] kioti-api.files.svdcdn.com [3] kioti-api.files.svdcdn.com
