▶ EnginePTO Power 57.6 hp (43 kW) 51.9 hp (38.7 kW) Alternator Not Published 12 V, 75 A Air Cleaner Not Published Dual element Engine Type In-Line Vertical, Water-cooled 4-Cycle Turbo Diesel, CRDI (4F243T) Diesel Fuel System Common Rail Direct Injection (CRDI) High-pressure common rail direct injection Displacement 148.6 in³ (2,435 cc) 127.6 in³ (2091 cc) No. of Cylinders 4 4 Rated Engine Speed 2,600 rpm 2600 rpm Cooling System Type Water-cooled Liquid Engine Manufacturer KIOTI Yanmar Engine Emissions Constraints Tier 4 Final Tier 4 Engine Power (Gross vs. Net HP) Gross: 66 hp (49.2 kW) Gross: 65 hp (48.5 kW) @ 2600 rpm (SAE J1995); Net: Not Published ▶ WeightTractor Weight with Loader 5,148 lb (2,335 kg) Not Published Weight with Cab and Loader Not Applicable Not Applicable Weight with ROPS and Loader 5,148 lb (2,335 kg) Not Published ▶ HydraulicsPump Type Gear Single gear Steering Flow 26.0 L/min (6.9 gpm) 23.5 L/min (6.2 gpm) Implement Flow 41.6 L/min (11.0 gpm) 42.3 L/min (11.2 gpm) Total Hydraulic Flow 67.6 L/min (17.9 gpm) Not Published Hydraulic System Type Open center Open center Rear Remote Hydraulic Flow Not Published Not Published Overall Hydraulic Pump Flow 67.6 L/min (17.9 gpm) Not Published No. of Optional Remote Valves 2 Not Published No. of Standard Remote Valves 1 2 ▶ Tire OptionsR3 Turf - Rear 44X18.00-20 Not Published R3 Turf - Front 31X13.50-15 Not Published Tire Size & Options R1 Agricultural, R3 Turf, R4 Industrial R4 Industrial R4 Industrial - Rear 18.4-24/8 16.9-24 (8PR) or 19.5L-24 (10PR) R4 Industrial - Front 12.5/80-18 31.5X13.00-16.5 (10PR) R1 Agricultural - Rear 14.9-28/8 Not Published R1 Agricultural - Front 9.5-20/8 Not Published ▶ Pto & HitchPTO Rear 540 / 540E rpm 540 rpm PTO Type Independent Independent (electrohydraulic) Lift Control Type Position, Draft, Mixed Control Position control Hitch Lift Capacity 4,575 lb (2,075 kg) Not Published Mid-PTO Availability Not Applicable Available Category, 3-Point Hitch Category II Category 1/2 (telescopic) Hitch Lift Capacity (at 24”) 3,594 lb (1,630 kg) 2,500 lb (1,134 kg) Rear 3-Point Hitch Lift Capacity 4,575 lb (2,075 kg) Not Published ▶ Fluid CapacityCoolant Capacity 2.40 gal (9.1 L) Open station: 6.8 qt (6.4 L); Cab: 8.0 qt (7.6 L) (if equipped) Crankcase Capacity 2.20 gal (8.3 L) 5.6 qt (5.3 L) (with filter) Fuel Tank Capacity 22.50 gal (85 L) Open station: 15.0 gal (56.9 L); Cab: 14.7 gal (55.6 L) (if equipped) Front Axle Fluid Capacity 2.20 gal (8.5 L) 5.3 qt (5.0 L) Transmission / Hydraulic System Capacity 15.90 gal (60 L) 12.5 gal (47.3 L) ▶ Loader & AttachmentsLoader Lift Height 133.9 in (3,401.1 mm) (to pivot pin) 112.1 in (2,850 mm) Loader Breakout Force 5,359.0 lb (2,430.8 kg) (at pivot pins) At pivot: 3,853 lbf (1,743.7 kgf); @ 500 mm ahead of pivot: 2,902 lbf (1,315.4 kgf) Price for Backhoe Option KB2485: $10,365 MSRP Not Published Price for Mid-Mount Mower Not Applicable Not Published Quick Attach Loader System Built-in parking stand; designed to be quickly and easily attached and detached. Rigid mounted with parking kit available; Parking stand kit BW16127 (parkable) Loader Lift Capacity (Full Height) 3,384.0 lb (1,535.0 kg) (to full height at pivot pins) At pivot: 2,396 lb (1,087 kg); @ 500 mm ahead of pivot: 1,764 lb (800 kg) ▶ Transmission & DrivetrainClutch Wet Disc Wet; wet clutch disk diameter 5.08 in (129 mm) No. of Speeds 12 forward / 12 reverse eHydro: Infinitely-variable, 3 range; PowrReverser: 12F/12R Transmission Type Manual: Power Shuttle Standard: eHydro (eHST), 3-range hydrostatic; Optional: 12/12 PowrReverser (PRT) Max Travel Speed (Forward) 21.79 mph (35.07 km/h) 18.6 mph (30 km/h) Max Travel Speed (Reverse) 21.42 mph (34.48 km/h) 18.6 mph (30 km/h) Differential Lock & Limited Slip Options Rear differential lock Differential lock: Yes ▶ Chassis Steering & ControlsBrakes Wet Multi Disc Multi-plate wet disc Steering Hydrostatic Power Steering Hydrostatic power steering Frame Type Not Published ROPS - Foldable Front Axle Type Not Published Mechanical front wheel drive (MFWD) - Standard; engagement On-the-Go Drawbar Capacity Not Published Max vertical load 500 kg (1103 lb) Front Axle Rating Not Published (Continuous) 1500 kg (3307 lb) Seat Suspension & Adjustability Adjustable Seat Not Published ▶ Dimensions & ManeuverabilityWheelbase 82.70 in (2,100 mm) 73.0 in (1,855 mm) Overall Width 70.90 in (1,801 mm) 71.3 in (1,811 mm) Ground Clearance 16.50 in (419 mm) Front axle: 15.2 in (386 mm); Drawbar support: 14.5 in (369 mm) Height to Top of ROPS 105.50 in (2,680 mm) 91.1 in (2,315 mm) Height to Top of Cab Model Not Applicable Not Applicable Height to Top of ROPS (folded) Not Published 65.9 in (1,675 mm) Min. Turn Radius without Brakes 10.20 ft (3.12 m) 17.1 ft (5.2 m) Overall Length with 3-Point Hitch 145.0 in (3,684 mm) 134.7 in (3,421 mm) ▶ Pricing Financing & WarrantyFinancing Options RX Series: up to $4,000 cash offer; 0% up to 36 months; 6.99% interest rate (offers subject to change). 0% APR fixed rate for 60 months Base Price with Loader Tractor Starting MSRP $41,355 + Front End Loader KL7320 $9,641 = $50,996 MSRP Not Published Warranty Length & Coverage Tractors (Non-Commercial Application): 24 months parts & labor; Extended (Non-Commercial, driveline/powertrain): 48 months parts & labor; Limited time: eligible units receive total 6 years (72 months) extended powertrain warranty coverage. 6-year/2,000-hour powertrain; 2-year/2,000-hour basic (full machine) Base Price with Loader + Cab Not Applicable Not Applicable ▶ SourcesSpec sheet sources [1] kioti.com [2] kioti-api.files.svdcdn.com [3] kioti-api.files.svdcdn.com [4] kioti.com [1] deere.com [2] explore.deere.com [3] deere.com
