▶ EnginePTO Power 60.9 hp (45.4 kW) 63 hp (47 kW) Alternator Not Published Not Published Air Cleaner Not Published Not Published Engine Type In-Line Vertical, Water-cooled 4-Cycle Turbo Diesel, CRDI (4H243T) In-Line Vertical, Water-cooled 4-Cycle Turbo Diesel, CRDI (4F243T) Fuel System Common Rail Direct Injection (CRDI) Common Rail Direct Injection (CRDI) Displacement 148.6 in³ (2,435 cc) 148.6 in³ (2,435 cc) No. of Cylinders 4 4 Rated Engine Speed 2,600 rpm 2,600 rpm Cooling System Type Water-cooled Water-cooled Engine Manufacturer KIOTI KIOTI Engine Emissions Constraints Tier 4 Tier 4 Engine Power (Gross vs. Net HP) Gross: 73.1 hp (54.5 kW) Gross: 73 hp (54.4 kW) ▶ WeightTractor Weight with Loader 6,814 lb (3,091 kg) 6,162 lb (2,795 kg) Weight with Cab and Loader 6,814 lb (3,091 kg) 6,162 lb (2,795 kg) Weight with ROPS and Loader Not Applicable Not Applicable ▶ HydraulicsPump Type Tandem Gear Gear Steering Flow 31.2 L/min (8.2 gpm) 31.2 L/min (8.2 gpm) Implement Flow 46.8 L/min (12.4 gpm) 41.6 L/min (11.0 gpm) Total Hydraulic Flow 78.0 L/min (20.6 gpm) 72.8 L/min (19.2 gpm) Hydraulic System Type Open center Open center Rear Remote Hydraulic Flow Not Published Not Published Overall Hydraulic Pump Flow 78.0 L/min (20.6 gpm) 72.8 L/min (19.2 gpm) No. of Optional Remote Valves 2 2 No. of Standard Remote Valves 1 1 ▶ Tire OptionsR3 Turf - Rear Not Applicable 44X18.00-20 R3 Turf - Front Not Applicable 31X13.50-15 Tire Size & Options R1 Agricultural, R4 Industrial R1 Agricultural, R3 Turf, R4 Industrial R4 Industrial - Rear 18.4-24/8 18.4-24/8 R4 Industrial - Front 12.5/80-18 12.5/80-18 R1 Agricultural - Rear 16.9-30 14.9-28/8 R1 Agricultural - Front 11.2-24 9.5-20/8 ▶ Pto & HitchPTO Rear 540 / 540E rpm 540 / 540E rpm PTO Type Independent Independent Lift Control Type Electronic Control Position, Draft, Mixed Control Hitch Lift Capacity 5,584.3 lb (2,533 kg) 4,974 lb (2,256 kg) Mid-PTO Availability Not Applicable Not Applicable Category, 3-Point Hitch Category II Category II Hitch Lift Capacity (at 24”) 4,327.7 lb (1,963 kg) 3,898 lb (1,768 kg) Rear 3-Point Hitch Lift Capacity 5,584.3 lb (2,533 kg) 4,974 lb (2,256 kg) ▶ Fluid CapacityCoolant Capacity 2.51 gal (9.5 L) 2.40 gal (9.1 L) Crankcase Capacity 2.83 gal (10.7 L) 2.20 gal (8.3 L) Fuel Tank Capacity 26.40 gal (100 L) 25.10 gal (95 L) Front Axle Fluid Capacity 2.60 gal (10 L) 2.20 gal (8.5 L) Transmission / Hydraulic System Capacity 11.75 gal (44.5 L) 15.90 gal (60 L) ▶ Loader & AttachmentsLoader Lift Height 127.1 in (3,229.0 mm) (to pivot pin) 133.9 in (3,401.1 mm) (to pivot pin) Loader Breakout Force 5,875.3 lb (2,665.0 kg) (at pivot pins) 5,359.0 lb (2,430.8 kg) (at pivot pins) Price for Backhoe Option Not Applicable Not Applicable Price for Mid-Mount Mower Not Applicable Not Applicable Quick Attach Loader System Built-in parking stand; designed to be quickly and easily attached and detached. Built-in parking stand; designed to be quickly and easily attached and detached. Loader Lift Capacity (Full Height) 3,300.0 lb (1,497.0 kg) (to full height at pivot pins) 3,384.0 lb (1,535.0 kg) (to full height at pivot pins) ▶ Transmission & DrivetrainClutch Wet Disc Wet Disc No. of Speeds 20 forward / 20 reverse 12 forward / 12 reverse Transmission Type Manual: Power Shuttle Manual: Power Shuttle Max Travel Speed (Forward) 22.01 mph (35.43 km/h) 23.53 mph (37.86 km/h) Max Travel Speed (Reverse) 21.92 mph (35.28 km/h) 23.13 mph (37.23 km/h) Differential Lock & Limited Slip Options Rear differential lock (standard) Rear differential lock (standard) ▶ Chassis Steering & ControlsBrakes Wet Multi Disc Wet Multi Disc Steering Hydrostatic Power Steering Hydrostatic Power Steering Frame Type Not Published Not Published Front Axle Type Not Published Not Published Drawbar Capacity Not Published Not Published Front Axle Rating Not Published Not Published Seat Suspension & Adjustability Adjustable Air-Ride Seat Adjustable Seat ▶ Dimensions & ManeuverabilityWheelbase 85.40 in (2,170 mm) 83.90 in (2,131 mm) Overall Width 82.10 in (2,085 mm) 77.20 in (1,961 mm) Ground Clearance 15.70 in (400 mm) 17.30 in (439 mm) Height to Top of ROPS Not Applicable Not Applicable Height to Top of Cab Model 105.30 in (2,675 mm) 104.50 in (2,655 mm) Height to Top of ROPS (folded) Not Applicable Not Applicable Min. Turn Radius without Brakes 12.80 ft (3.90 m) 11.20 ft (3.42 m) Overall Length with 3-Point Hitch 150.30 in (3,817 mm) 146.30 in (3,715 mm) ▶ Pricing Financing & WarrantyFinancing Options RX Series: up to $4,000 cash offer; 0% up to 36 months; 6.99% interest rate (offers subject to change). RX Series: up to $4,000 cash offer; 0% up to 36 months; 6.99% interest rate (offers subject to change). Base Price with Loader Tractor Starting MSRP $55,627 + Front End Loader KL7340 $9,579 = $65,206 MSRP Tractor Starting MSRP $50,639 + Front End Loader KL7320 $9,978 = $60,617 MSRP Warranty Length & Coverage Tractors (Non-Commercial Application): 24 months parts & labor; Extended (Non-Commercial, driveline/powertrain): 48 months parts & labor; Limited time: eligible units receive total 6 years (72 months) extended powertrain warranty coverage. Tractors (Non-Commercial Application): 24 months parts & labor; Extended (Non-Commercial, driveline/powertrain): 48 months parts & labor; Limited time: eligible units receive total 6 years (72 months) extended powertrain warranty coverage. Base Price with Loader + Cab Tractor Starting MSRP $55,627 + Front End Loader KL7340 $9,579 = $65,206 MSRP Tractor Starting MSRP $50,639 + Front End Loader KL7320 $9,978 = $60,617 MSRP ▶ SourcesSpec sheet sources [1] kioti.com [2] kioti-api.files.svdcdn.com [3] kioti-api.files.svdcdn.com [4] kioti.com [1] kioti.com [2] kioti-api.files.svdcdn.com [3] kioti-api.files.svdcdn.com [4] kioti.com
