Tractor Comparison
Pick up to 4tractors and we'll lay every spec sheet out side by side. Same data we publish on the individual model pages, stacked in columns so you can compare numbers at a glance.
No photo
—
KubotaBX2380
No photo
—
TYMT224
Comparison loaded for 2 tractors.
Spec
KubotaBX2380
TYMT224
PTO Power
17.7 hp (13.2 kW)
15.1 hp (11.3 kW)
Alternator
12 V, 40 A
12 V, 40 A
Air Cleaner
Sheet net and replaceable treated paper element, spin on oil filter
Single dry
Engine Type
Liquid cooled, 4-cycle, diesel
3-cylinder, naturally aspirated diesel
Fuel System
Direct injection
IDI
Displacement
54.8 in³ (898 cc)
60.6 in³ (993 cc)
No. of Cylinders
3
3
Rated Engine Speed
3200 rpm
3,200 rpm
Cooling System Type
Water with pressurized radiator, reverse air-flow design
Water-cooled
Engine Manufacturer
Kubota
Yanmar
Engine Emissions Constraints
Not Published
Tier 4 certified
Engine Power (Gross vs. Net HP)
Gross: 21.6 hp (16.1 kW)
Gross: 21.5 hp (16 kW)
Tractor Weight with Loader
Not Published
Not Published
Weight with Cab and Loader
Not Applicable
Not Published
Weight with ROPS and Loader
Not Published
Not Published
Pump Type
Open center tandem pump gear type
Single gear pump
Steering Flow
3.8 L/min (1.0 gpm)
8 L/min (2.1 gpm)
Implement Flow
19.7 L/min (5.2 gpm)
17.4 L/min (4.6 gpm)
Total Hydraulic Flow
23.5 L/min (6.2 gpm)
25.4 L/min (6.7 gpm)
Hydraulic System Type
Open center
Open center
Rear Remote Hydraulic Flow
Not Published
Not Published
Overall Hydraulic Pump Flow
23.5 L/min (6.2 gpm)
25.4 L/min (6.7 gpm)
No. of Optional Remote Valves
2 (optional; ISO 7241-1 series A or B)
1
No. of Standard Remote Valves
Not Published
Not Published
R3 Turf - Rear
26X12-12
Turf Master 24x12.00-12 NHS TL 4PR
R3 Turf - Front
18X8.5-10
Turf Master 16x7.50-8 NHS TL 4PR
Tire Size & Options
R1 Agricultural, R3 Turf, R4 Industrial
R1 Agricultural, R3 Turf, R4 Industrial
R4 Industrial - Rear
26X12-12
WT300 26x12.00-12 NHS TL 4PR
R4 Industrial - Front
18X8.5-10
WT300 18x8.5-10 NHS TL 4PR
R1 Agricultural - Rear
26X12-12
BAR R 24x12.00-12
R1 Agricultural - Front
18X8.5-10
BAR F 16x6.50-8
PTO Rear
STD (540 rpm)
540 rpm
PTO Type
Live independent PTO (with hydraulic clutch)
Independent
Lift Control Type
Not Published
Position control
Hitch Lift Capacity
Not Published
1,100 lb (499 kg)
Mid-PTO Availability
STD (2500 rpm)
Available
Category, 3-Point Hitch
SAE Category I Optional
Category I (Narrow)
Hitch Lift Capacity (at 24”)
680 lb (310 kg)
679 lb (308 kg)
Rear 3-Point Hitch Lift Capacity
Not Published
1,100 lb (499 kg)
Coolant Capacity
Not Published
3.7 qt (3.5 L)
Crankcase Capacity
Not Published
1.9 qt (1.8 L)
Fuel Tank Capacity
6.6 gal (25 L)
6.6 gal (25 L)
Front Axle Fluid Capacity
Not Published
2.6 qt (2.5 L)
Transmission / Hydraulic System Capacity
Not Published
3.6 gal (13.6 L)
Loader Lift Height
71.0 in (1804 mm)
71.3 in (1810 mm)
Loader Breakout Force
1,286 lbf (bucket pivot pin)
1,235 lb (560 kg)
Price for Backhoe Option
Not Applicable
TB50
Price for Mid-Mount Mower
Not Applicable
MM54
Quick Attach Loader System
Swift-Tach® Loader (LA344S — Two Lever Quick Attach Bucket)
TX22H: Quick attach mechanism
Loader Lift Capacity (Full Height)
739 lb (335 kg)
617 lb (280 kg)
Clutch
Dry type single plate - Main clutch 9.45 in.
Not applicable
No. of Speeds
2 Range (Low-High)
Infinite 2-Range
Transmission Type
Hydrostatic transmission
HST
Max Travel Speed (Forward)
8.1 mph (13.0 km/h)
8.4 mph (13.5 km/h)
Max Travel Speed (Reverse)
6.2 mph (10.0 km/h)
Not Published
Differential Lock & Limited Slip Options
Rear differential lock standard
Differential lock
Brakes
Mechanical, wet disc type
Wet disc
Steering
Integral power steering
Hydrostatic
Frame Type
Not Published
Not Published
Front Axle Type
4WD: Bevel gear front axle, non-adjustable tread spacing
Not Published
Drawbar Capacity
Max. drawbar load @ hitch: 550 lb.
Not Published
Front Axle Rating
Not Published
Not Published
Seat Suspension & Adjustability
Not Published
Not Published
Wheelbase
55.1 in (1400 mm)
53.1 in (1350 mm)
Overall Width
45.1 in (1145 mm)
44.5 in (1130 mm)
Ground Clearance
6.5 in (165 mm)
8.3 in (210 mm)
Height to Top of ROPS
83.1 in (2110 mm)
86.6 in (2200 mm)
Height to Top of Cab Model
Not Applicable
Not Published
Height to Top of ROPS (folded)
Not Published
Not Published
Min. Turn Radius without Brakes
7.5 ft (2.3 m)
86.6 in (2200 mm)
Overall Length with 3-Point Hitch
99.0 in (2515 mm) (w/ Front guard)
94.2 in (2394 mm)
Financing Options
Check with your local dealer for the best offer.
0% financing for up to 72 months and instant cash rebates. Contact dealer for more information.
Non-Commercial Home & Residential Use — Basic Standard Limited: 24 months or 1500 hours; Limited Powertrain: 72 months or 2000 hours. Commercial Use — Basic Standard Limited: 24 months or 1500 hours; Limited Powertrain: 36 months or 2000 hours.
Up to 2 years or until the 2,000 hours mark, bumper-to-bumper warranty; 3000 hours maximum coverage period for parts and labour on drivetrains or powertrains; 12-months warranty period for implements, including loaders and backhoes.
