Pick up to 4tractors and we'll lay every spec sheet out side by side. Same data we publish on the individual model pages, stacked in columns so you can compare numbers at a glance.
No photo
—
KubotaBX2680
No photo
—
KubotaBX23S
Comparison loaded for 2 tractors.
Spec
KubotaBX2680
KubotaBX23S
PTO Power
19.5 hp (14.5 kW)
17.7 hp (13.2 kW)
Alternator
12 V, 40 A
12 V, 40 A
Air Cleaner
Sheet net and replaceable treated paper element, spin on oil filter
Sheet net and replaceable treated paper element, spin on oil filter
Engine Type
Liquid cooled, 4-cycle, diesel
Liquid cooled, 4-cycle, diesel
Fuel System
Direct injection
Direct injection
Displacement
61.1 in³ (1001 cc)
54.8 in³ (898 cc)
No. of Cylinders
3
3
Rated Engine Speed
3200 rpm
3200 rpm
Cooling System Type
Water with pressurized radiator, reverse air-flow design
Water with pressurized radiator, reverse air-flow design
Engine Manufacturer
Kubota
Kubota
Engine Emissions Constraints
Not Published
Not Published
Engine Power (Gross vs. Net HP)
Gross: 24.8 hp (18.5 kW)
Gross: 21.6 hp (16.1 kW)
Tractor Weight with Loader
Not Published
Not Published
Weight with Cab and Loader
Not Applicable
Not Applicable
Weight with ROPS and Loader
Not Published
Not Published
Pump Type
Open center tandem pump gear type
Open center tandem pump gear type
Steering Flow
3.8 L/min (1.0 gpm)
3.8 L/min (1.0 gpm)
Implement Flow
19.7 L/min (5.2 gpm)
19.7 L/min (5.2 gpm)
Total Hydraulic Flow
23.5 L/min (6.2 gpm)
23.5 L/min (6.2 gpm)
Hydraulic System Type
Open center
Open center
Rear Remote Hydraulic Flow
Not Published
Not Published
Overall Hydraulic Pump Flow
23.5 L/min (6.2 gpm)
23.5 L/min (6.2 gpm)
No. of Optional Remote Valves
2 (optional; ISO 7241-1 series A or B)
2 (optional; ISO 7241-1 series A or B)
No. of Standard Remote Valves
Not Published
Not Published
R3 Turf - Rear
26X12-12
26X12-12
R3 Turf - Front
18X8.5-10
18X8.5-10
Tire Size & Options
R1 Agricultural, R3 Turf, R4 Industrial
R3 Turf, R4 Industrial
R4 Industrial - Rear
26X12-12
26X12-12
R4 Industrial - Front
18X8.5-10
18X8.5-10
R1 Agricultural - Rear
26X12-12
Not Applicable
R1 Agricultural - Front
18X8.5-10
Not Applicable
PTO Rear
STD (540 rpm)
STD (540 rpm)
PTO Type
Live independent PTO (with hydraulic clutch)
Live independent PTO (with hydraulic clutch)
Lift Control Type
Not Published
Not Published
Hitch Lift Capacity
Not Published
Not Published
Mid-PTO Availability
STD (2500 rpm)
STD (2500 rpm)
Category, 3-Point Hitch
SAE Category I Optional
SAE Category I Optional
Hitch Lift Capacity (at 24”)
680 lb (310 kg)
680 lb (310 kg)
Rear 3-Point Hitch Lift Capacity
Not Published
Not Published
Coolant Capacity
Not Published
Not Published
Crankcase Capacity
Not Published
Not Published
Fuel Tank Capacity
6.6 gal (25 L)
6.6 gal (25 L)
Front Axle Fluid Capacity
Not Published
Not Published
Transmission / Hydraulic System Capacity
Not Published
Not Published
Loader Lift Height
71.0 in (1804 mm)
71.0 in (1804 mm)
Loader Breakout Force
1,286 lbf (bucket pivot pin)
1,286 lbf (bucket pivot pin)
Price for Backhoe Option
Not Applicable
Already included in base model
Price for Mid-Mount Mower
Not Applicable
Not Published
Quick Attach Loader System
Swift-Tach® Loader (LA344S — Two Lever Quick Attach Bucket)
Swift-Tach® Loader (LA340S — Two Lever Quick Attach Bucket)
Loader Lift Capacity (Full Height)
739 lb (335 kg)
613 lb (278 kg)
Clutch
Dry type single plate - Main clutch 9.45 in.
Dry type single plate - Main clutch 9.45 in.
No. of Speeds
2 Range (Low-High)
2 Range (Low-High)
Transmission Type
Hydrostatic transmission
Hydrostatic transmission
Max Travel Speed (Forward)
8.1 mph (13.0 km/h)
8.4 mph (13.5 km/h)
Max Travel Speed (Reverse)
6.2 mph (10.0 km/h)
6.5 mph (10.5 km/h)
Differential Lock & Limited Slip Options
Rear differential lock standard
Rear differential lock standard
Brakes
Mechanical, wet disc type
Mechanical, wet disc type
Steering
Integral power steering
Integral power steering
Frame Type
Not Published
Not Published
Front Axle Type
4WD: Bevel gear front axle, non-adjustable tread spacing
4WD: Bevel gear front axle, non-adjustable tread spacing
$27,603 MSRP as low as (BX23S model offering includes front loader)
Warranty Length & Coverage
Non-Commercial Home & Residential Use — Basic Standard Limited: 24 months or 1500 hours; Limited Powertrain: 72 months or 2000 hours. Commercial Use — Basic Standard Limited: 24 months or 1500 hours; Limited Powertrain: 36 months or 2000 hours.
Non-Commercial Home & Residential Use — Basic Standard Limited: 24 months or 1500 hours; Limited Powertrain: 72 months or 2000 hours. Commercial Use — Basic Standard Limited: 24 months or 1500 hours.
