Tractor Comparison
Pick up to 4tractors and we'll lay every spec sheet out side by side. Same data we publish on the individual model pages, stacked in columns so you can compare numbers at a glance.
No photo
—
KubotaBX2680
No photo
—
MasseyFergusonMF1M.25
Comparison loaded for 2 tractors.
Spec
KubotaBX2680
Massey FergusonMF 1M.25
PTO Power
19.5 hp (14.5 kW)
ROPS: 18.2 hp (13.6 kW); CAB: 16.9 hp (12.6 kW)
Alternator
12 V, 40 A
Not Published
Air Cleaner
Sheet net and replaceable treated paper element, spin on oil filter
Not Published
Engine Type
Liquid cooled, 4-cycle, diesel
3-cylinder diesel
Fuel System
Direct injection
Not Published
Displacement
61.1 in³ (1001 cc)
91.4 in³ (1,498 cc)
No. of Cylinders
3
3
Rated Engine Speed
3200 rpm
2,600 rpm
Cooling System Type
Water with pressurized radiator, reverse air-flow design
Not Published
Engine Manufacturer
Kubota
Massey Ferguson (AGCO)
Engine Emissions Constraints
Not Published
Not Published
Engine Power (Gross vs. Net HP)
Gross: 24.8 hp (18.5 kW)
24.8 hp (18.5 kW)
Tractor Weight with Loader
Not Published
Not Published
Weight with Cab and Loader
Not Applicable
Not Published
Weight with ROPS and Loader
Not Published
Not Published
Pump Type
Open center tandem pump gear type
Not Published
Steering Flow
3.8 L/min (1.0 gpm)
12.3 L/min (3.2 gpm)
Implement Flow
19.7 L/min (5.2 gpm)
20.9 L/min (5.5 gpm)
Total Hydraulic Flow
23.5 L/min (6.2 gpm)
33.2 L/min (8.8 gpm)
Hydraulic System Type
Open center
Open center
Rear Remote Hydraulic Flow
Not Published
Not Published
Overall Hydraulic Pump Flow
23.5 L/min (6.2 gpm)
33.2 L/min (8.8 gpm)
No. of Optional Remote Valves
2 (optional; ISO 7241-1 series A or B)
Not Published
No. of Standard Remote Valves
Not Published
2
R3 Turf - Rear
26X12-12
315X75D-15
R3 Turf - Front
18X8.5-10
24X8.50-12
Tire Size & Options
R1 Agricultural, R3 Turf, R4 Industrial
R1 Agricultural, R3 Turf
R4 Industrial - Rear
26X12-12
Not Published
R4 Industrial - Front
18X8.5-10
Not Published
R1 Agricultural - Rear
26X12-12
9.5-18
R1 Agricultural - Front
18X8.5-10
6.00-12
PTO Rear
STD (540 rpm)
540 rpm
PTO Type
Live independent PTO (with hydraulic clutch)
Independent
Lift Control Type
Not Published
Not Published
Hitch Lift Capacity
Not Published
1,433 lb (650 kg)
Mid-PTO Availability
STD (2500 rpm)
Optional (2,000 rpm)
Category, 3-Point Hitch
SAE Category I Optional
Category I
Hitch Lift Capacity (at 24”)
680 lb (310 kg)
1,091 lb (495 kg)
Rear 3-Point Hitch Lift Capacity
Not Published
1,433 lb (650 kg)
Coolant Capacity
Not Published
Not Published
Crankcase Capacity
Not Published
Not Published
Fuel Tank Capacity
6.6 gal (25 L)
7.4 gal (28 L)
Front Axle Fluid Capacity
Not Published
Not Published
Transmission / Hydraulic System Capacity
Not Published
Not Published
Loader Lift Height
71.0 in (1804 mm)
83 in (2,108 mm)
Loader Breakout Force
1,286 lbf (bucket pivot pin)
1,822 lb (826 kg)
Price for Backhoe Option
Not Applicable
Not Published
Price for Mid-Mount Mower
Not Applicable
Not Published
Quick Attach Loader System
Swift-Tach® Loader (LA344S — Two Lever Quick Attach Bucket)
FL.2106: Skid Steer Tool Carrier
Loader Lift Capacity (Full Height)
739 lb (335 kg)
1,222 lb (554 kg)
Clutch
Dry type single plate - Main clutch 9.45 in.
Not Published
No. of Speeds
2 Range (Low-High)
3 Ranges
Transmission Type
Hydrostatic transmission
Hydrostatic
Max Travel Speed (Forward)
8.1 mph (13.0 km/h)
Not Published
Max Travel Speed (Reverse)
6.2 mph (10.0 km/h)
Not Published
Differential Lock & Limited Slip Options
Rear differential lock standard
Differential lock (LHS pedal)
Brakes
Mechanical, wet disc type
Internal wet disc
Steering
Integral power steering
Not Published
Frame Type
Not Published
Not Published
Front Axle Type
4WD: Bevel gear front axle, non-adjustable tread spacing
Not Published
Drawbar Capacity
Max. drawbar load @ hitch: 550 lb.
Not Published
Front Axle Rating
Not Published
Not Published
Seat Suspension & Adjustability
Not Published
Not Published
Wheelbase
55.1 in (1400 mm)
61.4 in (1,560 mm)
Overall Width
45.1 in (1145 mm)
45.7-52 in (1,160-1,320 mm)
Ground Clearance
6.5 in (165 mm)
9.9-11 in (250-305 mm)
Height to Top of ROPS
83.1 in (2110 mm)
95.3-97.5 in (2,420-2,475 mm)
Height to Top of Cab Model
Not Applicable
80-82.1 in (2,030-2,085 mm)
Height to Top of ROPS (folded)
Not Published
Not Published
Min. Turn Radius without Brakes
7.5 ft (2.3 m)
Not Published
Overall Length with 3-Point Hitch
99.0 in (2515 mm) (w/ Front guard)
115.9 in (2,945 mm)
Financing Options
Check with your local dealer for the best offer.
0% for up to 60 Months* (Offer valid through February 28, 2026)
Non-Commercial Home & Residential Use — Basic Standard Limited: 24 months or 1500 hours; Limited Powertrain: 72 months or 2000 hours. Commercial Use — Basic Standard Limited: 24 months or 1500 hours; Limited Powertrain: 36 months or 2000 hours.
