▶ EnginePTO Power DT (4WD), GST (4WD): 29.5 hp (22.0 kW); HST (4WD), HSTC (4WD, CAB): 28.0 hp (20.9 kW) DT (4WD): 28.0 hp (20.9 kW); HST (4WD): 26.1 hp (19.5 kW) Alternator DT (4WD), GST (4WD), HST (4WD): 12 V, 40 A; HSTC (4WD, CAB): 12 V, 60 A Not Published Air Cleaner Dry paper, dual element Not Published Engine Type Liquid-cooled, 4-cycle multi valve, diesel, Naturally Aspirated Direct injection, vertical, water-cooled 4-cycle, diesel Fuel System Electronic CRS (Common Rail System) Direct injection Displacement 111.4 in³ (1,826 cc) 111.4 in³ (1826 cc) No. of Cylinders 3 3 Rated Engine Speed DT (4WD), GST (4WD): 2700 rpm; HST (4WD), HSTC (4WD, CAB): 2600 rpm 2700 rpm Cooling System Type Liquid-cooled Water-cooled Engine Manufacturer Kubota Kubota Engine Emissions Constraints EPA Tier 4 Final (DPF muffler + EGR) Not Published Engine Power (Gross vs. Net HP) Gross: 37.0 hp (27.6 kW); Net: 35.0 hp (26.1 kW) Gross: 33.0 hp (24.6 kW); Net: 31.8 hp (23.7 kW) ▶ WeightTractor Weight with Loader Not Published Not Published Weight with Cab and Loader Not Published Not Applicable Weight with ROPS and Loader Not Published Not Published ▶ HydraulicsPump Type Tandem pump - gear type Not Published Steering Flow DT (4WD), GST (4WD): 4.9 gpm (18.6 L/min); HST (4WD), HSTC (4WD, CAB): 4.7 gpm (17.9 L/min) 14.5 L/min (3.8 gpm) Implement Flow DT (4WD), GST (4WD): 8.3 gpm (31.5 L/min); HST (4WD), HSTC (4WD, CAB): 8.1 gpm (30.4 L/min) 23.9 L/min (6.3 gpm) Total Hydraulic Flow DT (4WD), GST (4WD): 13.2 gpm (50.1 L/min); HST (4WD), HSTC (4WD, CAB): 12.8 gpm (48.3 L/min) 38.4 L/min (10.1 gpm) Hydraulic System Type Open center Not Published Rear Remote Hydraulic Flow Not Published Not Published Overall Hydraulic Pump Flow DT (4WD), GST (4WD): 13.2 gpm (50.1 L/min); HST (4WD), HSTC (4WD, CAB): 12.8 gpm (48.3 L/min) 38.4 L/min (10.1 gpm) No. of Optional Remote Valves Optional, up to 3 (double-acting valve or float detent valve options, any position) Not Published No. of Standard Remote Valves Not Published Not Published ▶ Tire OptionsR3 Turf - Rear 41X18LL-16.1 13.6-16 R3 Turf - Front 27X10.50-15 25X8.50-14 Tire Size & Options R1 Agricultural; R3 Turf; R4 Industrial R1 Agricultural; R3 Turf; R4 Industrial R4 Industrial - Rear 420/70-24 15-19.5 R4 Industrial - Front 10-16.5 27X8.50-15 R1 Agricultural - Rear 12.4-24 11.2-24 R1 Agricultural - Front 7.2-16 7.2-16 ▶ Pto & HitchPTO Rear DT (4WD), GST (4WD): 540 rpm @ 2550 engine rpm; HST (4WD), HSTC (4WD, CAB): 540 rpm @ 2476 engine rpm 540 rpm PTO Type Live independent (hydraulic clutch) DT (4WD): Transmission driven with overrunning clutch; HST (4WD): Live independent PTO with hydraulic clutch Lift Control Type Position control Position control Hitch Lift Capacity 3,858 lb 1998 lb (906 kg) Mid-PTO Availability Optional Not Published Category, 3-Point Hitch SAE Category 1 SAE Category I Hitch Lift Capacity (at 24”) 2,756 lb 1435 lb (651 kg) Rear 3-Point Hitch Lift Capacity 3,858 lb 1998 lb (906 kg) ▶ Fluid CapacityCoolant Capacity 7.9 qt (7.5 L) Not Published Crankcase Capacity 7.1 qt (6.7 L) Not Published Fuel Tank Capacity 13.5 gal (51 L) 13.5 gal (51 L) Front Axle Fluid Capacity Not Published Not Published Transmission / Hydraulic System Capacity 11.1 gal (42 L) Not Published ▶ Loader & AttachmentsLoader Lift Height LA555: 96.4 in (2448 mm); LA805: 104.7 in (2659 mm) 94.3 in (2394 mm) Loader Breakout Force LA555: 2030 lb (9029 N); LA805: 2549 lb (11341 N) Not Published Price for Backhoe Option DT (4WD), GST (4WD), HST (4WD): BH77: $9,803 MSRP; BH92: $11,078 MSRP; HSTC (4WD, CAB): BH92: $11,078 MSRP BH77: $9,803 MSRP Price for Mid-Mount Mower Not Published Not Applicable Quick Attach Loader System LA555: Mechanical 2-Lever Quick Coupler (standard); LA805: Mechanical 2-Lever Quick Coupler (standard); Hydraulic 2-Lever Quick Coupler (optional); Single Lever Hose Quick Coupler (optional) Front Loader (LA526 — 2 Lever Quick Coupler (OPT)) Loader Lift Capacity (Full Height) LA555: 1190 lb (540 kg); LA805: 1715 lb (778 kg) 1144.4 lb (519 kg) ▶ Transmission & DrivetrainClutch DT (4WD), GST (4WD): Dry type single stage; HST (4WD), HSTC (4WD, CAB): N/A DT (4WD): Dry type single stage; HST (4WD): Not Applicable No. of Speeds DT (4WD): 8Fx8R; GST (4WD): 12Fx8R; HST (4WD), HSTC (4WD, CAB): 3-Range, 6 speeds (H-DS), infinitely variable in each DT (4WD): 8 forward, 8 reverse; HST (4WD): 3-range Transmission Type DT (4WD): Gear; GST (4WD): Glide Shift; HST (4WD), HSTC (4WD, CAB): Hydrostatic DT (4WD): Gear shift with synchronized shuttle; HST (4WD): Hydrostatic transmission (3-range) Max Travel Speed (Forward) DT (4WD), GST (4WD): 16.0 mph; HST (4WD), HSTC (4WD, CAB): 16.8 mph DT (4WD): 13.2 mph (21.2 km/h); HST (4WD): 14.1 mph (22.7 km/h) Max Travel Speed (Reverse) DT (4WD), GST (4WD): 15.2 mph; HST (4WD), HSTC (4WD, CAB): 15.1 mph DT (4WD): 13.2 mph (21.2 km/h); HST (4WD): 12.7 mph (20.5 km/h) Differential Lock & Limited Slip Options Rear differential lock, standard Not Published ▶ Chassis Steering & ControlsBrakes Wet disc type, mechanically activated Mechanical, wet disc type Steering Hydrostatic power steering Integral type power steering Frame Type Not Published Not Published Front Axle Type 4WD: Bevel gear front axle, non-adjustable tread spacing Not Published Drawbar Capacity 1,433 lbs. Not Published Front Axle Rating Not Published Not Published Seat Suspension & Adjustability Not Published Not Published ▶ Dimensions & ManeuverabilityWheelbase 74.6 in (1895 mm) 63.4 in (1610 mm) Overall Width 66.5 in (1689 mm) 55.1 in (1400 mm) Ground Clearance 15.9 in (404 mm) 13.4 in (340 mm) Height to Top of ROPS DT (4WD), GST (4WD), HST (4WD): 97.6 in (2479 mm); HSTC (4WD, CAB): Not Applicable 91.7 in (2330 mm) Height to Top of Cab Model DT (4WD), GST (4WD), HST (4WD): Not Applicable; HSTC (4WD, CAB): 91.1 in (2314 mm) Not Applicable Height to Top of ROPS (folded) DT (4WD), GST (4WD), HST (4WD): 90.6 in (2301 mm); HSTC (4WD, CAB): Not Applicable Not Published Min. Turn Radius without Brakes 8.9 ft (2.7 m) Not Published Overall Length with 3-Point Hitch 129.5 in (3289 mm) 108.5 in (2755 mm) ▶ Pricing Financing & WarrantyFinancing Options Check with your local dealer for the best offer. Check with your local dealer for the best offer. Base Price with Loader DT (4WD): Tractor Starting MSRP $29,407 + LA555 $5,142 = $34,549 MSRP; Tractor Starting MSRP $29,407 + LA805 $6,147 = $35,554 MSRP; GST (4WD): Tractor Starting MSRP $30,855 + LA555 $5,142 = $35,997 MSRP; Tractor Starting MSRP $30,855 + LA805 $6,147 = $37,002 MSRP; HST (4WD): Tractor Starting MSRP $31,298 + LA555 $5,142 = $36,440 MSRP; Tractor Starting MSRP $31,298 + LA805 $6,147 = $37,445 MSRP; HSTC (4WD, CAB): Tractor Starting MSRP $41,705 + LA555 $5,142 = $46,847 MSRP; Tractor Starting MSRP $41,705 + LA805 $6,147 = $47,852 MSRP DT (4WD): Tractor Starting MSRP $23,941 + LA526 $6,227 = $30,168 MSRP; HST (4WD): Tractor Starting MSRP $25,298 + LA526 $6,227 = $31,525 MSRP Warranty Length & Coverage Non-Commercial Home & Residential Use — Basic Standard Limited: 24 months or 1500 hours; Limited Powertrain: 72 months or 2000 hours. Commercial Use — Basic Standard Limited: 24 months or 1500 hours; Limited Powertrain: 36 months or 2000 hours. Non-Commercial Home & Residential Use — Basic Standard Limited: 24 months or 1500 hours; Limited Powertrain: 72 months or 2000 hours. Commercial Use — Basic Standard Limited: 24 months or 1500 hours; Limited Powertrain: 36 months or 2000 hours. Base Price with Loader + Cab DT (4WD): Not Applicable; GST (4WD): Not Applicable; HST (4WD): Not Applicable; HSTC (4WD, CAB): Tractor Starting MSRP $41,705 + LA555 $5,142 = $46,847 MSRP; Tractor Starting MSRP $41,705 + LA805 $6,147 = $47,852 MSRP Not Applicable ▶ SourcesSpec sheet sources [1] kubotausa.com [2] kubotausa.com [3] kubotausa.com [4] kubotausa.com [1] kubotausa.com [2] kubotausa.com [3] kubotausa.com
