▶ EnginePTO Power 44.0 hp (32.8 kW) 32.5 hp (24.2 kW) Alternator 12 V, 45 A HST-LE (4WD, ROPS): 12 V, 40 A; HSTC-LE (4WD, CAB): 12 V, 60 A Air Cleaner Dry paper, dual element Dry paper, dual element Engine Type Liquid-cooled, 4-cycle multi valve, diesel, Turbocharged Liquid-cooled, 4-cycle multi valve, diesel, Naturally Aspirated Fuel System Electronic Common Rail System (CRS) Electronic CRS (Common Rail System) Displacement 148.5 in³ (2,434 cc) 148.5 in³ (2,434 cc) No. of Cylinders 4 4 Rated Engine Speed 2700 rpm 2600 rpm Cooling System Type Liquid-cooled Liquid-cooled Engine Manufacturer Kubota Kubota Engine Emissions Constraints EPA Tier 4 Final (DPF muffler + EGR) EPA Tier 4 Final (DPF muffler + EGR) Engine Power (Gross vs. Net HP) Gross: 52.0 hp (38.8 kW); Net: 50.0 hp (37.3 kW) Gross: 42.0 hp (31.3 kW); Net: 40.0 hp (29.8 kW) ▶ WeightTractor Weight with Loader Not Published Not Published Weight with Cab and Loader Not Published Not Published Weight with ROPS and Loader Not Published Not Published ▶ HydraulicsPump Type Tandem pump - gear type Not Published Steering Flow 4.9 gpm (18.6 L/min) 4.7 gpm (17.9 L/min) Implement Flow 9.8 gpm (37.0 L/min) 9.4 gpm (35.6 L/min) Total Hydraulic Flow 14.7 gpm (55.6 L/min) 14.1 gpm (53.5 L/min) Hydraulic System Type Open center Not Published Rear Remote Hydraulic Flow Not Published Not Published Overall Hydraulic Pump Flow 14.7 gpm (55.6 L/min) 14.1 gpm (53.5 L/min) No. of Optional Remote Valves Optional, up to 3 (double-acting valve or float detent valve options, any position) Optional, up to 3 No. of Standard Remote Valves Not Published Not Published ▶ Tire OptionsR3 Turf - Rear 44X18-20 Not Published R3 Turf - Front 29X12.50-15 Not Published Tire Size & Options Standard R1; Option 1 R4; Option 2 R3; LSW option (R3) Agricultural, Turf or Industrial tires (options) R4 Industrial - Rear 17.5L-24 Not Published R4 Industrial - Front 10-16.5 Not Published R1 Agricultural - Rear 14.9-26; 13.6-28 12.4-24 R1 Agricultural - Front 9.5-16 7.0-16 ▶ Pto & HitchPTO Rear 540 rpm @ 2550 engine rpm 1 speed: 540 rpm PTO Type Live independent (hydraulic clutch) Independent Lift Control Type Position control Position control Hitch Lift Capacity 3,858 lb Not Published Mid-PTO Availability Optional Optional Category, 3-Point Hitch SAE Category 1 & 2 Category I Hitch Lift Capacity (at 24”) 2,976 lb 2,760 lb (1,250 kg) Rear 3-Point Hitch Lift Capacity 3,858 lb Not Published ▶ Fluid CapacityCoolant Capacity 8.7 qt Not Published Crankcase Capacity 9.9 qt Not Published Fuel Tank Capacity 13.5 gal 13.5 gal (51 L) Front Axle Fluid Capacity Not Published Not Published Transmission / Hydraulic System Capacity 11.9 gal Not Published ▶ Loader & AttachmentsLoader Lift Height 112.7 in (2862 mm) 104.7 in (2659 mm) Loader Breakout Force 3171 lb (14107 N) 2549 lb (11341 N) Price for Backhoe Option BH92: $11,078 MSRP BH92: $11,078 MSRP Price for Mid-Mount Mower Not Published Not Applicable Quick Attach Loader System Mechanical 2-Lever Quick Coupler (standard); Hydraulic 2-Lever Quick Coupler (optional); Single Lever Hose Quick Coupler (optional) LA805: Mechanical 2-Lever Quick Coupler (standard); Hydraulic 2-Lever Quick Coupler (optional); Single Lever Hose Quick Coupler (optional) Loader Lift Capacity (Full Height) 2361 lb (1071 kg) 1715 lb (778 kg) ▶ Transmission & DrivetrainClutch Dry type single stage N/A No. of Speeds 12Fx8R 3 ranges Transmission Type Glide Shift Hydrostatic (HST Plus) Max Travel Speed (Forward) 16.5 mph 16.8 mph (27.0 km/h) Max Travel Speed (Reverse) 15.8 mph 15.1 mph (24.3 km/h) Differential Lock & Limited Slip Options Rear differential lock, standard Not Published ▶ Chassis Steering & ControlsBrakes Wet disc type, mechanically activated Wet disc type Steering Hydrostatic power steering Hydrostatic power steering Frame Type Not Published Not Published Front Axle Type 4WD: Bevel gear front axle, non-adjustable tread spacing Not Published Drawbar Capacity 1,433 lbs. Not Published Front Axle Rating Not Published Not Published Seat Suspension & Adjustability Not Published Not Published ▶ Dimensions & ManeuverabilityWheelbase 75.4 in (1915 mm) 74.6 in (1895 mm) Overall Width 67.3 in (1709 mm) 66.5 in (1690 mm) Ground Clearance 15.4 in (391 mm) 14.2 in (360 mm) Height to Top of ROPS 98.0 in (2489 mm) HST-LE (4WD, ROPS): 97.6 in (2480 mm); HSTC-LE (4WD, CAB): Not Applicable Height to Top of Cab Model Not Applicable HST-LE (4WD, ROPS): Not Applicable; HSTC-LE (4WD, CAB): Not Published Height to Top of ROPS (folded) Not Published HST-LE (4WD, ROPS): 91.1 in (2315 mm); HSTC-LE (4WD, CAB): Not Applicable Min. Turn Radius without Brakes 9.2 ft (2.8 m) 8.9 ft (2.7 m) Overall Length with 3-Point Hitch 135.0 in (3429 mm) Not Published ▶ Pricing Financing & WarrantyFinancing Options Check with your local dealer for the best offer. Check with your local dealer for the best offer. Base Price with Loader GST (4WD): Tractor Starting MSRP $44,271 + LA1055 $6,710 = $50,981 MSRP HST-LE (4WD, ROPS): Tractor Starting MSRP $33,612 + LA805 $6,147 = $39,759 MSRP; HSTC-LE (4WD, CAB): Tractor Starting MSRP $42,419 + LA805 $6,147 = $48,566 MSRP Warranty Length & Coverage Non-Commercial Home & Residential Use — Basic Standard Limited: 24 months or 1500 hours; Limited Powertrain: 72 months or 2000 hours. Commercial Use — Basic Standard Limited: 24 months or 1500 hours; Limited Powertrain: 36 months or 2000 hours. Non-Commercial Home & Residential Use — Basic Standard Limited: 24 months or 1500 hours; Limited Powertrain: 72 months or 2000 hours. Commercial Use — Basic Standard Limited: 24 months or 1500 hours; Limited Powertrain: 36 months or 2000 hours. Base Price with Loader + Cab Not Applicable HST-LE (4WD, ROPS): Not Applicable; HSTC-LE (4WD, CAB): Tractor Starting MSRP $42,419 + LA805 $6,147 = $48,566 MSRP ▶ SourcesSpec sheet sources [1] kubotausa.com [2] kubotausa.com [3] kubotausa.com [4] kubotausa.com [1] kubotausa.com [2] kubotausa.com [3] kubotausa.com [4] kubotausa.com [5] kubotausa.com
