▶ EnginePTO Power 46.5 hp (34.7 kW) DT (2WD/4WD), DTN (4WD): 40.5 hp (30.2 kW); HST (4WD): 39.0 hp (29.1 kW) Alternator HST (4WD): 12 V, 45 A; HSTC (4WD, CAB): 12 V, 60 A Not Published Air Cleaner Dry paper, dual element Not Published Engine Type Liquid-cooled, 4-cycle multi valve, diesel, Turbocharged Direct injection, vertical, water-cooled 4-cycle, diesel Fuel System Electronic Common Rail System (CRS) Direct injection Displacement 148.5 in³ (2,434 cc) 148.5 in³ (2434 cc) No. of Cylinders 4 4 Rated Engine Speed 2600 rpm 2600 rpm Cooling System Type Liquid-cooled Water-cooled Engine Manufacturer Kubota Kubota Engine Emissions Constraints EPA Tier 4 Final (DPF muffler + EGR) Not Published Engine Power (Gross vs. Net HP) Gross: 56.0 hp (41.8 kW); Net: 54.0 hp (40.3 kW) Gross: 48.4 hp (36.1 kW); Net: 46.0 hp (34.3 kW) ▶ WeightTractor Weight with Loader Not Published Not Published Weight with Cab and Loader Not Published Not Applicable Weight with ROPS and Loader Not Published Not Published ▶ HydraulicsPump Type Tandem pump - gear type Not Published Steering Flow 4.7 gpm (17.9 L/min) 17.9 L/min (4.7 gpm) Implement Flow 9.4 gpm (35.6 L/min) 29.4 L/min (7.8 gpm) Total Hydraulic Flow 14.1 gpm (53.5 L/min) 47.3 L/min (12.5 gpm) Hydraulic System Type Open center Not Published Rear Remote Hydraulic Flow Not Published Not Published Overall Hydraulic Pump Flow 14.1 gpm (53.5 L/min) 47.3 L/min (12.5 gpm) No. of Optional Remote Valves Optional, up to 3 (double-acting valve or float detent valve options, any position) Not Published No. of Standard Remote Valves Not Published Not Published ▶ Tire OptionsR3 Turf - Rear 44X18-20 DT (2WD/4WD), HST (4WD): 44X18-20; DTN (4WD): Not Applicable R3 Turf - Front 29X12.50-15 DT (2WD): 27X8.50-15; DT (4WD), HST (4WD): 27X10.5-15; DTN (4WD): Not Applicable Tire Size & Options Standard R1; Option 1 R4; Option 2 R3; LSW option (R3) R1 Agricultural; R3 Turf; R4 Industrial R4 Industrial - Rear 17.5L-24 DT (2WD), DTN (4WD): Not Applicable; DT (4WD), HST (4WD): 17.5L-24 R4 Industrial - Front 10-16.5 DT (2WD), DTN (4WD): Not Applicable; DT (4WD), HST (4WD): 10.0-16.5 R1 Agricultural - Rear 14.9-26; 13.6-28 DT (2WD/4WD), HST (4WD): 14.9-24; DTN (4WD): 11.2-24 R1 Agricultural - Front 9.5-16 DT (2WD): 7.5L-15; DT (4WD), HST (4WD): 8.3-16; DTN (4WD): 7.2-16 ▶ Pto & HitchPTO Rear 540 rpm @ 2400 engine rpm 540 rpm PTO Type Live independent (hydraulic clutch) Live independent PTO with hydraulic clutch Lift Control Type Position control Position control Hitch Lift Capacity 3,858 lb 2870 lb (1300 kg) Mid-PTO Availability Optional Not Published Category, 3-Point Hitch SAE Category 1 & 2 SAE Category I Hitch Lift Capacity (at 24”) 2,976 lb 2320 lb (1053 kg) Rear 3-Point Hitch Lift Capacity 3,858 lb 2870 lb (1300 kg) ▶ Fluid CapacityCoolant Capacity 8.7 qt Not Published Crankcase Capacity 9.9 qt Not Published Fuel Tank Capacity 13.5 gal 13.5 gal (51 L) Front Axle Fluid Capacity Not Published Not Published Transmission / Hydraulic System Capacity 11.9 gal Not Published ▶ Loader & AttachmentsLoader Lift Height 112.7 in (2862 mm) DT (2WD/4WD), HST (4WD): 105.2 in (2672 mm); DTN (4WD): Not Applicable Loader Breakout Force 3171 lb (14107 N) Not Published Price for Backhoe Option BH92: $11,078 MSRP DT (2WD/4WD), HST (4WD): BH92: $11,078 MSRP; DTN (4WD): Not Applicable Price for Mid-Mount Mower Not Published Not Applicable Quick Attach Loader System Mechanical 2-Lever Quick Coupler (standard); Hydraulic 2-Lever Quick Coupler (optional); Single Lever Hose Quick Coupler (optional) DT (2WD/4WD), HST (4WD): LA766 2-Lever Quick Coupler; DTN (4WD): Not Applicable Loader Lift Capacity (Full Height) 2361 lb (1071 kg) DT (2WD/4WD), HST (4WD): 1675 lb (760 kg); DTN (4WD): Not Applicable ▶ Transmission & DrivetrainClutch N/A DT (2WD/4WD), DTN (4WD): Dry type single stage; HST (4WD): Not Applicable No. of Speeds 3-range, 6 speeds (H-DS), infinitely variable in each DT (2WD/4WD), DTN (4WD): 8 forward, 8 reverse; HST (4WD): 3-range Transmission Type Hydrostatic transmission DT (2WD/4WD), DTN (4WD): Constant mesh with synchronized shuttle; HST (4WD): Hydrostatic transmission (3-range) Max Travel Speed (Forward) 16.8 mph DT (2WD/4WD): 14.9 mph (24.0 km/h); DTN (4WD): 12.9 mph (20.8 km/h); HST (4WD): 15.8 mph (25.4 km/h) Max Travel Speed (Reverse) 15.2 mph DT (2WD/4WD): 14.3 mph (23.0 km/h); DTN (4WD): 12.4 mph (20.0 km/h); HST (4WD): 14.2 mph (22.9 km/h) Differential Lock & Limited Slip Options Rear differential lock, standard Not Published ▶ Chassis Steering & ControlsBrakes Wet disc type, mechanically activated Mechanical, wet disc type Steering Hydrostatic power steering Hydrostatic power steering Frame Type Not Published Not Published Front Axle Type 4WD: Bevel gear front axle, non-adjustable tread spacing Not Published Drawbar Capacity 1,433 lbs. Not Published Front Axle Rating Not Published Not Published Seat Suspension & Adjustability Not Published Not Published ▶ Dimensions & ManeuverabilityWheelbase 75.4 in (1915 mm) 72.6 in (1845 mm) Overall Width 67.3 in (1709 mm) DT (2WD/4WD), HST: 62.2 in (1580 mm); DTN (4WD): 53.7 in (1365 mm) Ground Clearance 15.4 in (391 mm) DT (2WD/4WD), HST: 15.2 in (385 mm); DTN (4WD): 11.6 in (295 mm) Height to Top of ROPS HST (4WD): 98.0 in (2489 mm); HSTC (4WD, CAB): Not Applicable DTN (4WD): 94.9 in (2410 mm); DT (2WD/4WD), HST (4WD): 91.7 in (2330 mm) Height to Top of Cab Model HST (4WD): Not Applicable; HSTC (4WD, CAB): 92.5 in (2350 mm) Not Applicable Height to Top of ROPS (folded) HST (4WD): 92.5 in (2350 mm); HSTC (4WD, CAB): Not Applicable DTN (4WD): 61.2 in (1555 mm) Min. Turn Radius without Brakes 9.2 ft (2.8 m) Not Published Overall Length with 3-Point Hitch 135.0 in (3429 mm) DT (2WD): 122.8 in (3120 mm); DT (4WD), HST (4WD): 120.3 in (3055 mm); DTN (4WD): 117.7 in (2990 mm) ▶ Pricing Financing & WarrantyFinancing Options Check with your local dealer for the best offer. Check with your local dealer for the best offer. Base Price with Loader HST (4WD): Tractor Starting MSRP $42,046 + LA1055 $6,710 = $48,756 MSRP; HSTC (4WD, CAB): Tractor Starting MSRP $52,452 + LA1055 $6,710 = $59,162 MSRP DT (4WD): Tractor Starting MSRP $32,016 + LA766 $7,300 = $39,316 MSRP; HST (4WD): Tractor Starting MSRP $33,906 + LA766 $7,300 = $41,206 MSRP; DT (2WD): Tractor Starting MSRP $24,925 + LA766 $7,300 = $32,225 MSRP; DTN (4WD): Tractor Starting MSRP $34,460 + LA766 $7,300 = $41,760 MSRP Warranty Length & Coverage Non-Commercial Home & Residential Use — Basic Standard Limited: 24 months or 1500 hours; Limited Powertrain: 72 months or 2000 hours. Commercial Use — Basic Standard Limited: 24 months or 1500 hours; Limited Powertrain: 36 months or 2000 hours. Non-Commercial Home & Residential Use — Basic Standard Limited: 24 months or 1500 hours; Limited Powertrain: 72 months or 2000 hours. Commercial Use — Basic Standard Limited: 24 months or 1500 hours; Limited Powertrain: 36 months or 2000 hours. Base Price with Loader + Cab HST (4WD): Not Applicable; HSTC (4WD, CAB): Tractor Starting MSRP $52,452 + LA1055 $6,710 = $59,162 MSRP Not Applicable ▶ SourcesSpec sheet sources [1] kubotausa.com [2] kubotausa.com [3] kubotausa.com [4] kubotausa.com [1] kubotausa.com [2] kubotausa.com [3] kubotausa.com
