▶ EnginePTO Power 53.0 hp (39.5 kW) 43 hp (32 kW) (OOS); 42.9 hp (32 kW) (Cab) Alternator HST (4WD): 12 V, 45 A; HSTC (4WD, CAB): 12 V, 60 A 12 V, 60 A (OOS); 12 V, 110 A (Cab) Air Cleaner Dry paper, dual element Dry type air cleaner with safety element Engine Type Liquid-cooled, 4-cycle multi valve, diesel, Turbocharged Diesel, turbocharged and aftercooled Fuel System Electronic Common Rail System (CRS) Electronically controlled, high-pressure common rail Displacement 148.5 in³ (2,434 cc) 179 in³ (2,933 cc) No. of Cylinders 4 3 Rated Engine Speed 2600 rpm 2100 rpm Cooling System Type Liquid-cooled Liquid-cooled Engine Manufacturer Kubota John Deere PowerTech™ 3029 EWR Engine Emissions Constraints EPA Tier 4 Final (DPF muffler + EGR) EPA Final Tier 4 Engine Power (Gross vs. Net HP) Gross: 62.0 hp (46.3 kW); Net: 60.0 hp (44.8 kW) Gross: 61.2 hp (45 kW) @ 2100 rpm (97/68/EC) ▶ WeightTractor Weight with Loader Not Published Not Published Weight with Cab and Loader Not Published Not Published Weight with ROPS and Loader Not Published Not Published ▶ HydraulicsPump Type Tandem pump - gear type Tandem gear pump (implement + steering) Steering Flow 4.7 gpm (17.9 L/min) 25.7 L/min (6.8 gpm) Implement Flow 9.4 gpm (35.6 L/min) 43.1 L/min (11.4 gpm) Total Hydraulic Flow 14.1 gpm (53.5 L/min) 68.8 L/min (18.2 gpm) Hydraulic System Type Open center Open center Rear Remote Hydraulic Flow Not Published 43.1 L/min (11.4 gpm) at a single rear SCV Overall Hydraulic Pump Flow 14.1 gpm (53.5 L/min) 68.8 L/min (18.2 gpm) No. of Optional Remote Valves Optional, up to 3 (double-acting valve or float detent valve options, any position) 2 No. of Standard Remote Valves Not Published 1 ▶ Tire OptionsR3 Turf - Rear 44X18-20 41X14.00-20 4PR R3; 44X18.00-20 4PR R3 (Premium) R3 Turf - Front 29X12.50-15 33X15.50-15 6PR R3; 33X12.50-15 6PR R3; 29X12.5-15 4PR R3 (Premium) Tire Size & Options Standard R1; Option 1 R4; Option 2 R3; LSW option (R3) R1 Ag / R3 Turf / R4 Industrial / Snow R4 Industrial - Rear 17.5L-24 17.5L-24 8PR R4; 19.5L-24 8PR R4; 16.9-30 10PR R4; 43X16.00-20 R4; 43X16.00-20 R4 (Premium); 18.4-30 10PR R4 R4 Industrial - Front 10-16.5 27/12LL-15 6PR R4; 10-16.5 8PR R4; 28X8.50-15 8PR R4; 12.5/80-18 12PR R4 R1 Agricultural - Rear 14.9-26; 13.6-28 14.9-28 6PR R1; 16.9-28 6PR R1; 16.9-30 6PR R1; 18.4-30 6PR R1; 460/85R30 R1; 460/85R30 R1W R1 Agricultural - Front 9.5-16 9.5-24 10PR R1; 12.4-24 8PR R1; 320/85R24 R1; 320/85R24 R1W ▶ Pto & HitchPTO Rear 540 rpm @ 2400 engine rpm 540 @ 2083 engine rpm; 540E @ 1588 engine rpm (PowrReverser) PTO Type Live independent (hydraulic clutch) Independent PTO: 540 (SyncShuttle); 540/540E (PowrReverser) Lift Control Type Position control Position control with draft control; adjustable rate of drop Hitch Lift Capacity 3,858 lb 3,968 lb (1,800 kg) @ hitch points Mid-PTO Availability Optional Not Applicable Category, 3-Point Hitch SAE Category 1 & 2 Category II; convertible to Category I Hitch Lift Capacity (at 24”) 2,976 lb 3,197 lb (1,450 kg) @ 24 in behind hitch balls Rear 3-Point Hitch Lift Capacity 3,858 lb 3,968 lb (1,800 kg) @ hitch points ▶ Fluid CapacityCoolant Capacity 8.7 qt Open operator station: 2.85 gal (13 L); Cab: 3.08 gal (14 L) Crankcase Capacity 9.9 qt 9.0 qt (8.5 L) (with filter) Fuel Tank Capacity 13.5 gal Open operator station: 15.6 ± 0.44 gal (71 ± 2 L); Cab: 17.59 ± 0.44 gal (80 ± 2 L) Front Axle Fluid Capacity Not Published DANA: 1.18 gal (4.5 L) diff + 0.21 gal (0.8 L) per hub; Carraro: 1.03 gal (3.9 L) diff + 0.15 gal (0.6 L) per side Transmission / Hydraulic System Capacity 11.9 gal 8.36 gal (38 L) (9x3); 9.46 gal (43 L) (12x12) ▶ Loader & AttachmentsLoader Lift Height 112.7 in (2862 mm) 124 in (3,150 mm) Loader Breakout Force 3171 lb (14107 N) 4,354 lb (1,975 kg) (measured at pivot) Price for Backhoe Option BH92: $11,078 MSRP Not Published Price for Mid-Mount Mower Not Published Not Applicable Quick Attach Loader System Mechanical 2-Lever Quick Coupler (standard); Hydraulic 2-Lever Quick Coupler (optional); Single Lever Hose Quick Coupler (optional) Parkable loader (parking system; no tools required for removal/installation); optional John Deere skid steer attachment carrier (tool-free attachment changes) Loader Lift Capacity (Full Height) 2361 lb (1071 kg) 3,225 lb (1,463 kg) (measured at pivot) ▶ Transmission & DrivetrainClutch N/A Dual clutch, 11 in (PowrReverser) No. of Speeds 3-range, 6 speeds (H-DS), infinitely variable in each 9 forward / 3 reverse (SyncShuttle); 12 forward / 12 reverse (PowrReverser) Transmission Type Hydrostatic transmission SyncShuttle 9F/3R (standard); PowrReverser 12F/12R (optional) Max Travel Speed (Forward) 16.8 mph 15.5 mph (25.0 km/h) (SyncShuttle); 20.5 mph (32.9 km/h) (PowrReverser) Max Travel Speed (Reverse) 15.2 mph 14.2 mph (22.8 km/h) (SyncShuttle); 22.3 mph (36.0 km/h) (PowrReverser) Differential Lock & Limited Slip Options Rear differential lock, standard Mechanical differential lock (pedal) ▶ Chassis Steering & ControlsBrakes Wet disc type, mechanically activated Hydraulically actuated wet disk brakes (oil-immersed) Steering Hydrostatic power steering Hydrostatic power steering Frame Type Not Published Not Published Front Axle Type 4WD: Bevel gear front axle, non-adjustable tread spacing 2WD (standard) or MFWD (optional) Drawbar Capacity 1,433 lbs. 1,675 lb (760 kg) (fully extended); 2,470 lb (1,120 kg) (short position) Front Axle Rating Not Published Up to 9,612 lb (4,360 kg) (max permissible MFWD axle load w/ loader; varies by tire) Seat Suspension & Adjustability Not Published Mechanical suspension with weight adjustment; fore/aft and backrest angle adjustment ▶ Dimensions & ManeuverabilityWheelbase 75.4 in (1915 mm) 80.7 in (2,050 mm) Overall Width 67.3 in (1709 mm) Not Published Ground Clearance 15.4 in (391 mm) Not Published Height to Top of ROPS HST (4WD): 98.0 in (2489 mm); HSTC (4WD, CAB): Not Applicable Not Published Height to Top of Cab Model HST (4WD): Not Applicable; HSTC (4WD, CAB): 92.5 in (2350 mm) Not Published Height to Top of ROPS (folded) HST (4WD): 92.5 in (2350 mm); HSTC (4WD, CAB): Not Applicable Not Published Min. Turn Radius without Brakes 9.2 ft (2.8 m) 137.8 in (3,500 mm) (2WD); 183.1 in (4,650 mm) (4WD); 153.5 in (3,900 mm) (4WD, Carraro axle) Overall Length with 3-Point Hitch 135.0 in (3429 mm) 143.3 in (3,639 mm) ▶ Pricing Financing & WarrantyFinancing Options Check with your local dealer for the best offer. 0% APR fixed rate for 60 months Base Price with Loader HST (4WD): Tractor Starting MSRP $44,440 + LA1055 $6,710 = $51,150 MSRP; HSTC (4WD, CAB): Tractor Starting MSRP $54,848 + LA1055 $6,710 = $61,558 MSRP Not Published Warranty Length & Coverage Non-Commercial Home & Residential Use — Basic Standard Limited: 24 months or 1500 hours; Limited Powertrain: 72 months or 2000 hours. Commercial Use — Basic Standard Limited: 24 months or 1500 hours; Limited Powertrain: 36 months or 2000 hours. 6-year/2,000-hour powertrain; 2-year/2,000-hour basic (full machine) Base Price with Loader + Cab HST (4WD): Not Applicable; HSTC (4WD, CAB): Tractor Starting MSRP $54,848 + LA1055 $6,710 = $61,558 MSRP Not Published ▶ SourcesSpec sheet sources [1] kubotausa.com [2] kubotausa.com [3] kubotausa.com [4] kubotausa.com [1] deere.com [2] johndeere.widen.net [3] deere.com
