Kubota LX2610 vs Kubota B2601HSD | Side-by-side comparison | ITC Resource Center
ITC Resource Center
Tractor Comparison
Pick up to 4tractors and we'll lay every spec sheet out side by side. Same data we publish on the individual model pages, stacked in columns so you can compare numbers at a glance.
—
KubotaLX2610
—
KubotaB2601HSD
Comparison loaded for 2 tractors.
Spec
KubotaLX2610
KubotaB2601HSD
PTO Power
19.5 hp
19.5 hp
Alternator
Not Published
Not Published
Air Cleaner
4.5 inch Dual paper element
Dual paper element
Engine Type
E-TVCS, liquid cooled, 3-cylinder, diesel
E-TVCS, liquid cooled, 3-cylinder diesel
Fuel System
Not Published
diesel
Displacement
77 in³
61.1 in³
No. of Cylinders
3
3
Rated Engine Speed
2500 rpm
2800 rpm
Cooling System Type
Pressurized radiator
Pressurized radiator
Engine Manufacturer
Kubota
Kubota
Engine Power (Gross)
24.8 hp
24.3 hp
Engine Emissions Constraints
Not Published
Tier 4
Tractor Weight with Loader
Not Published
1632 lbs.
Weight with Cab and Loader
Not Applicable
Not Applicable
Weight with ROPS and Loader
Not Published
Not explicitly published as a combined ROPS+loader figure in sources found. Tractor-only weight is 1,632 lb (740 kg).
Pump Type
Dual pump
Dual pump
Steering Flow
Not Published
Not Published
Implement Flow
Not Published
8.3 gal/min total - open center dual pump system shared between steering and implement circuits; individual split not published
Total Hydraulic Flow
8.7 gpm
8.3 gpm 31.4 lpm
Hydraulic System Type
Open center
open center
Rear Remote Hydraulic Flow
Not Published
8.3 gal/min (total system - individual remote valve flow not separately published)
Overall Hydraulic Pump Flow
8.7 gpm
8.3 gpm
No. of Optional Remote Valves
Not Published
1 (single rear remote is optional)
No. of Standard Remote Valves
Not Published
Not Published
PTO Rear
540 rpm
540
PTO Type
Independent
Independent
Lift Control Type
Position control valve
position control
Hitch Lift Capacity
2139 lb
1808 lbs.
Mid-PTO Availability
2500 rpm
independent, 2500
Category, 3-Point Hitch
Category I
I
Hitch Lift Capacity (at 24”)
1676 lb
1290 lb
R3 Turf - Rear
Not Published
22x8.50-12
R3 Turf - Front
Not Published
22x8.50-12
Tire Size & Options
R1 Agricultural, R4 Industrial
Ag (R1): 7-12 front / 11.2-16 rear; Turf (R3): 22x8.50-12 front / 22x8.50-12 rear; Industrial (R4): 23x8.50-12 front / 12-16.5 rear; also Goodyear R14 hybrid multi-purpose tire available
R4 Industrial - Rear
12.4-16 / 15-19.5
12-16.5
R4 Industrial - Front
23X8.50-14 / 25X8.50-14
23x8.50-12
R1 Agricultural - Rear
12.4-16
11.2-16
R1 Agricultural - Front
7.0-12
7-12
Coolant Capacity
4.5 qt
4.0 qts.
Crankcase Capacity
4.2 qt
3.3 qts.
Fuel Tank Capacity
7.1 gal
6.1 gal
Front Axle Fluid Capacity
Not Published
Not Published
Transmission / Hydraulic System Capacity
4.0 gal
4.0 gal
Loader Lift Height
84 in
78.5 in.
Loader Breakout Force
2245 lb
2146 lbs.
Price for Backhoe Option
BH77: $9,803 MSRP
BH70: $8,463 MSRP
Price for Mid-Mount Mower
RCK60-30BB: $3,803 MSRP; RCK72-30BB: $4,556 MSRP
RCK54-32: $2,898 MSRP; RCK60-32: $3,514 MSRP
Quick Attach Loader System
Front Loader (LA535 - 2 Lever Quick Coupler (STD); Swift-tach (OPT))
LA435 Swift-Tach Loader (1-lever Quick Coupler)
Loader Lift Capacity (Full Height)
1067 lb
948 lbs.
Clutch
N/A
N/A
No. of Speeds
3 ranges
3 ranges (HST)
Transmission Type
Hydrostatic transmission
HST (3 ranges)
Max Travel Speed (Forward)
11.2 mph
0-12.7 mph (0-12.7 mph)
Max Travel Speed (Reverse)
8.4 mph
0-9.5 mph (0-9.5 mph)
Differential Lock & Limited Slip Options
Differential lock standard
Standard
Brakes
Multi-plate wet disc
Wet disc brakes
Steering
Hydraulic power steering
Power steering
Frame Type
Not Published
Not explicitly published in sources found. Tractor uses standard compact utility tractor chassis construction.
Front Axle Type
Not Published
Four-wheel drive
Drawbar Capacity
Not Published
Drawbar included as standard; rated capacity not published in sources found
Front Axle Rating
Not Published
Not Published
Seat Suspension & Adjustability
Deluxe high-back suspension seat
High-back seat with armrests; adjustable tilt-steering wheel; seat is not described as having mechanical suspension
Wheelbase
65.6 in
61.4 inches 61 in
Overall Width
53.7 in
49 in.
Ground Clearance
14.6 in
12.8 in.
Height to Top of ROPS
88.4 in
85.0 in.
Height to Top of Cab Model
Not Applicable
Not Applicable
Height to Top of ROPS (folded)
Not Published
85 in - this is the standing/unfolded height; folded height not separately published in sources found
Non-Commercial Home & Residential Use - Basic Standard Limited: 24 months or 1500 hours; Limited Powertrain: 72 months or 2000 hours. Commercial Use - Basic Standard Limited: 24 months or 1500 hours; Limited Powertrain: 36 months or 2000 hours.
Non-Commercial Home & Residential Use - Basic Standard Limited: 24 months or 1500 hours; Limited Powertrain: 72 months or 2000 hours. Commercial Use - Basic Standard Limited: 24 months or 1500 hours; Limited Powertrain: 36 months or 2000 hours.
