▶ PtoPTO Power 19.4 hp — Mid PTO (Type / RPM) 2500 RPM (LX2620), 2460 RPM (LX3520/LX4020, optional) — Rear PTO (Type / RPM) 540 RPM — ▶ HitchThree-Point Hitch Category Category I — Lift Capacity at 24 in Behind LX2620: 1,819 lbs; LX3520/LX4020: 1,962 lbs — ▶ EnginePTO Power 28.7 (21.4) HP (kW) 18.8 hp Air Cleaner LX2620: 4.5 inch paper filter (with dual filter); LX3520/LX4020: 6 inch paper filter (with dual element) Single element Engine Type Indirect injection, vertical, water-cooled, 4-cycle diesel and Direct injection, vertical, water-cooled, 4-cycle diesel with turbocharger Water cooled, 4-cycle diesel Fuel System Common Rail (CRS) diesel Injection pump (indirect) Displacement 77 in³ 77.3 in³ No. of Cylinders 4 3 Rated Engine Speed 2500 rpm 3000 rpm Cooling System Type Pressurized radiator with radial air flow fan Water cooled, forced circulation Engine Manufacturer Kubota Yanmar Engine Power (Gross) 23.3 hp 24.6 hp Alternator — 40 A, 12 V Engine Emissions Constraints — Not Published ▶ WeightTractor Weight (Base) LX2620: 1,775 lbs; LX3520DTN: 2,154 lbs; LX3520: 2,191 lbs; LX4020: 2,624 lbs — Tractor Weight with Loader — Not Published Weight with Cab and Loader — Not Applicable Weight with ROPS and Loader — 1,610 lb ▶ HydraulicsPump Type Dual pump Gear pump Pump Flow (Total) LX2620: 8.7 gpm (33.1 ℓ/min); LX3520: 9.1 gpm (34.5 ℓ/min); LX4020: 9.5 gpm (35.8 ℓ/min) — Total Hydraulic Flow 9.1 (34.5) gpm (l/min.) 7.0 gpm Hydraulic System Type Open center Power Assisted Hydro-Static System Operating Pressure Open center system — Overall Hydraulic Pump Flow 9.1 (34.5) gpm (l/min.) 6.95 gpm Steering Flow — 2.8 gpm Implement Flow — 4.2 gpm Rear Remote Hydraulic Flow — Not Applicable No. of Optional Remote Valves — Not Published No. of Standard Remote Valves — Not Applicable ▶ DimensionsWheelbase LX2620: 65.6 in.; LX3520: 61.0 in.; LX4020: 66.7 in. — Overall Width LX2620/LX4020: 53.7 in.; LX3520 Narrow: 39.4 in. — Overall Length LX2620: 101.8 in.; LX3520DTN: 98.2 in.; LX3520/LX4020: 101.6-103.9 in. (2580-103.9 in) — Ground Clearance LX2620: 14.6 in.; LX3520: 12.8 in.; LX3520 Narrow: 12.8 in.; LX4020: 8.9 in. — Height to Top of ROPS LX3520 Narrow: 56.7 in. (folded) — ▶ PTO & HitchPTO Rear 540 rpm 540 rpm @ 2,893 engine rpm PTO Type Independent Independent Lift Control Type Position control valve Position control Hitch Lift Capacity 2348 (1065) lbs. (kg) 1,323 lb Mid-PTO Availability 2460 RPM Yes (2,000 rpm @ 2,875 engine rpm) Category, 3-Point Hitch Category I Category I (N) Hitch Lift Capacity (at 24”) — 1,101 lb @ 24 in behind lift point ▶ Tire OptionsR3 Turf - Rear 16.6-16 29X12.5-15 R3 Turf - Front 24x8.5-14 20X8-10 Tire Size & Options Front R1: 7-12; R4: 23×8.50-12; R4 large: 25×8.50-14; R14: 23×8.50-12; R14 large: 25×8.50-14; TURF: 24×8.50-14; Rear R1: 12.4-16; R4: 14-17.5; R14: 14-17.5; TURF: 13.6-16; R4 large: 15-19.5; R14 large: 15-19.5 R1 (Ag) / R3 (Turf) / R4 (Industrial) R4 Industrial - Rear 14-17.5 or 15-19.5 27X12-16.5 R4 Industrial - Front 23x8.5-12 or 25x8.5-14 23X8.5-12 R1 Agricultural - Rear 320/85D16 9.5-16 R1 Agricultural - Front 180/85D12 6-12 ▶ TransmissionNumber of Speeds 3 ranges (Low, Mid, High) — Transmission Type HST (Hydrostatic) with 3 ranges — ▶ Fluid CapacityCoolant Capacity LX2620: 4.5 qts (4.3 ℓ); LX3520/LX4020: 5.7 qts (5.4 ℓ) 0.96 gal Crankcase Capacity LX2620: 4.2 qts (4.0 ℓ); LX3520/LX4020: 5.0 qts (4.7 ℓ) 0.71 gal Fuel Tank Capacity LX2620: 7.1 gal (27 ℓ); LX3520/LX4020: 8.5 gal (32 ℓ) 5.81 gal Transmission/Hydraulic Capacity LX2620: 4.0 gal (15 ℓ); LX3520/LX4020: 5.5 gal (21.0 ℓ) — Transmission / Hydraulic System Capacity 5.5 (21.0) gal (ℓ) 3.83 gal Front Axle Fluid Capacity — 0.85 gal ▶ Loader & AttachmentsLoader Lift Height 87.6 (2226) in. (mm) 75.5 in (pivot pin) Quick Attach Loader System 2-Lever Quick Coupler (Standard); Swift-Tach (Optional) Yes (quick attach) Loader Lift Capacity (Full Height) 1100 (499) lbs. (kg) 992 lb (pivot pin) Loader Breakout Force — 1,531 lb (pivot pin, ground level) Price for Backhoe Option — Not Published Price for Mid-Mount Mower — Not Published ▶ Transmission & DrivetrainClutch N/A No No. of Speeds HST (3 range) 2 range (Low/High) Transmission Type HST (3 ranges) HST (Hydro Max) Max Travel Speed (Forward) 17.0 (0-27.4) mph (km/h) 10.5 mph (H range, Ag tires) Max Travel Speed (Reverse) 13.0 (0-20.8) mph (km/h) Not Published Differential Lock & Limited Slip Options Standard Differential lock ▶ Chassis, Steering & ControlsBrakes Multi-plate wet disk — Steering Hydrostatic power steering — Seat Suspension & Adjustability Deluxe suspension seat (high back, designed to absorb shock) — ▶ Dimensions & ManeuverabilityWheelbase 66.7 (1695) in. (mm) 57.5 in Overall Width 53.7 (1365) in. (mm) 45.8 in Ground Clearance 12.8 (325) in. (mm) 9.4 in Height to Top of ROPS (folded) 56.7 (1440) in. (mm) Not Published Min. Turn Radius without Brakes 7.5 (2.3) feet (m) Front drive disengaged Not Published Overall Length with 3-Point Hitch 101.8 (2586) in. (mm) 104.0 in Height to Top of ROPS — 91.3 in Height to Top of Cab Model — Not Applicable ▶ Pricing, Financing & WarrantyWarranty Length & Coverage Full warranty: 2 years / 2,000 hours | Powertrain warranty: 6 years / 2,000 hours — ▶ Chassis Steering & ControlsBrakes — Wet disc, foot-operated Steering — Power steering (hydrostatic) Frame Type — Sub-compact tractor; selectable 4WD Front Axle Type — Not Published Drawbar Capacity — Not Published Front Axle Rating — Not Published Seat Suspension & Adjustability — Not Published ▶ Pricing Financing & WarrantyFinancing Options — Payments as low as $213.00/month Base Price with Loader — Not Published Warranty Length & Coverage — Engine & Powertrain: 84 months (7 years) or 2,000 hours Base Price with Loader + Cab — Not Applicable ▶ ITC Company AccessoriesAccessories that fit
