▶ EnginePTO Power 46.5 hp (34.7 kW) GST (4WD): 41.0 hp (30.6 kW); HST (4WD), HSTC (4WD, CAB): 39.5 hp (29.5 kW) Alternator ROPS: 12 V, 45 A; CAB: 12 V, 60 A GST (4WD), HST (4WD): 12 V, 40 A; HSTC (4WD, CAB): 12 V, 60 A Air Cleaner Dry-dual element Dry paper, dual element Engine Type Liquid-cooled, diesel, 4-cylinder, Turbocharged Liquid-cooled, 4-cycle multi valve, diesel, Naturally Aspirated Fuel System Not Published Electronic CRS (Common Rail System) Displacement 148.6 (2434) 148.5 in³ (2,434 cc) No. of Cylinders 4 4 Rated Engine Speed 2700 rpm GST (4WD): 2700 rpm; HST (4WD), HSTC (4WD, CAB): 2600 rpm Cooling System Type Liquid-cooled Liquid-cooled Engine Manufacturer Kubota Kubota Engine Emissions Constraints Not Published EPA Tier 4 Final (DPF muffler + EGR) Engine Power (Gross vs. Net HP) DT (2WD/4WD): Gross: 55.5 hp (41.4 kW); Net: 53.0 hp (39.5 kW); HST (4WD): Gross: 57.0 hp (42.5 kW); Net: 53.8 hp (40.1 kW) Gross: 49.0 hp (36.6 kW); Net: 47.0 hp (35.1 kW) ▶ WeightTractor Weight with Loader Not Published Not Published Weight with Cab and Loader Not Published Not Published Weight with ROPS and Loader Not Published Not Published ▶ HydraulicsPump Type Gear Tandem pump - gear type Steering Flow 18.6 L/min (4.9 gpm) GST (4WD): 4.9 gpm (18.6 L/min); HST (4WD), HSTC (4WD, CAB): 4.7 gpm (17.9 L/min) Implement Flow 35.8 L/min (9.5 gpm) GST (4WD): 9.8 gpm (37.0 L/min); HST (4WD), HSTC (4WD, CAB): 9.4 gpm (35.6 L/min) Total Hydraulic Flow 54.4 L/min (14.4 gpm) GST (4WD): 14.7 gpm (55.6 L/min); HST (4WD), HSTC (4WD, CAB): 14.1 gpm (53.5 L/min) Hydraulic System Type Open Center Open center Rear Remote Hydraulic Flow Not Published Not Published Overall Hydraulic Pump Flow 54.4 L/min (14.4 gpm) GST (4WD): 14.7 gpm (55.6 L/min); HST (4WD), HSTC (4WD, CAB): 14.1 gpm (53.5 L/min) No. of Optional Remote Valves Maximum 3 (opt) Optional, up to 3 (double-acting valve or float detent valve options, any position) No. of Standard Remote Valves Not Published Not Published ▶ Tire OptionsR3 Turf - Rear Not Published 44X18-20 R3 Turf - Front Not Published 29X12.50-15 Tire Size & Options Standard tire size Standard R1; Option 1 R4; Option 2 R3; LSW option (R3) R4 Industrial - Rear Not Published 17.5L-24 R4 Industrial - Front Not Published 10-16.5 R1 Agricultural - Rear 14.9-26 14.9-24 R1 Agricultural - Front DT (2WD): 7.5L-15; DT (4WD), HST (4WD): 9.5-16 8.3-16 ▶ Pto & HitchPTO Rear 540 rpm GST (4WD): 540 rpm @ 2550 engine rpm; HST (4WD), HSTC (4WD, CAB): 540 rpm @ 2475 engine rpm PTO Type Live independent, hydraulic PTO with PTO brake, wet clutch Live independent (hydraulic clutch) Lift Control Type Position (std), Draft (opt) Position control Hitch Lift Capacity Not Published 3,858 lb Mid-PTO Availability Not Published Optional Category, 3-Point Hitch I & II SAE Category 1 Hitch Lift Capacity (at 24”) 2310 lbs (1050 kg) 2,756 lb Rear 3-Point Hitch Lift Capacity Not Published 3,858 lb ▶ Fluid CapacityCoolant Capacity Not Published 8.7 qt (8.2 L) Crankcase Capacity Not Published 8.7 qt (8.2 L) Fuel Tank Capacity ROPS: 13.5 gal (51 L); CAB: 11.9 gal (45 L) 13.5 gal (51 L) Front Axle Fluid Capacity Not Published Not Published Transmission / Hydraulic System Capacity Not Published 11.4 gal (43 L) ▶ Loader & AttachmentsLoader Lift Height 111.2 in (2824 mm) 112.7 in (2862 mm) Loader Breakout Force 3102 lb (13798 N) 3171 lb (14107 N) Price for Backhoe Option BH92: $11,078 MSRP BH92: $11,078 MSRP Price for Mid-Mount Mower Not Published Not Published Quick Attach Loader System 1065A: 2-Lever Quick Coupler for Loader Attachment Mechanical 2-Lever Quick Coupler (standard); Hydraulic 2-Lever Quick Coupler (optional); Single Lever Hose Quick Coupler (optional) Loader Lift Capacity (Full Height) 2275 lb (1032 kg) 2361 lb (1071 kg) ▶ Transmission & DrivetrainClutch DT (2WD/4WD): Dry single plate; HST (4WD): No clutch GST (4WD): Dry type single stage; HST (4WD), HSTC (4WD, CAB): N/A No. of Speeds DT (2WD/4WD): 8F/8R; HST (4WD): 3-range GST (4WD): 12Fx8R; HST (4WD), HSTC (4WD, CAB): 3-range, 6 speeds (H-DS), infinitely variable in each Transmission Type DT (2WD/4WD): 8-speed gear-drive (synchronized shuttle); HST (4WD): 3-range hydrostatic (HST) GST (4WD): Glide Shift; HST (4WD), HSTC (4WD, CAB): Hydrostatic Max Travel Speed (Forward) DT (2WD/4WD): 17.3 mph (27.9 km/h); HST (4WD): 17.7 mph (28.5 km/h) GST (4WD): 16.0 mph; HST (4WD), HSTC (4WD, CAB): 16.8 mph Max Travel Speed (Reverse) DT (2WD/4WD): 15.9 mph (25.6 km/h); HST (4WD): 16.0 mph (25.8 km/h) GST (4WD): 15.2 mph; HST (4WD), HSTC (4WD, CAB): 15.1 mph Differential Lock & Limited Slip Options Rear differential lock standard (mechanical) Rear differential lock, standard ▶ Chassis Steering & ControlsBrakes Mechanical wet disc Wet disc type, mechanically activated Steering Hydrostatic power steering Hydrostatic power steering Frame Type Not Published Not Published Front Axle Type Not Published 4WD: Bevel gear front axle, non-adjustable tread spacing Drawbar Capacity Not Published 1,433 lbs. Front Axle Rating Not Published Not Published Seat Suspension & Adjustability High-back suspension seat (optional arm rests) Not Published ▶ Dimensions & ManeuverabilityWheelbase 74.6 in (1895 mm) 74.6 in (1895 mm) Overall Width 69.7 in (1770 mm) 66.5 in (1689 mm) Ground Clearance 15.2 in (385 mm) 14.4 in (366 mm) Height to Top of ROPS 95.7 in (2430 mm) GST (4WD), HST (4WD): 97.6 in (2479 mm); HSTC (4WD, CAB): Not Applicable Height to Top of Cab Model 92.7 in (2355 mm) GST (4WD), HST (4WD): Not Applicable; HSTC (4WD, CAB): 91.9 in (2334 mm) Height to Top of ROPS (folded) Not Published GST (4WD), HST (4WD): 91.1 in (2314 mm); HSTC (4WD, CAB): Not Applicable Min. Turn Radius without Brakes Not Published 8.9 ft (2.7 m) Overall Length with 3-Point Hitch Not Published 129.5 in (3289 mm) ▶ Pricing Financing & WarrantyFinancing Options Check with your local dealer for the best offer. Check with your local dealer for the best offer. Base Price with Loader DT (2WD): Tractor Starting MSRP $28,930 + LOADER $5,971 = $34,901 MSRP; DT (4WD): Tractor Starting MSRP $36,406 + LOADER $5,971 = $42,377 MSRP; HST (4WD): Tractor Starting MSRP $38,387 + LOADER $5,971 = $44,358 MSRP GST (4WD): Tractor Starting MSRP $39,225 + LA1055 $6,710 = $45,935 MSRP; HST (4WD): Tractor Starting MSRP $39,687 + LA1055 $6,710 = $46,397 MSRP; HSTC (4WD, CAB): Tractor Starting MSRP $50,093 + LA1055 $6,710 = $56,803 MSRP Warranty Length & Coverage Non-Commercial Home & Residential Use — Basic Standard Limited: 24 months or 1500 hours; Limited Powertrain: 72 months or 2000 hours. Commercial Use — Basic Standard Limited: 24 months or 1500 hours; Limited Powertrain: 36 months or 2000 hours. Non-Commercial Home & Residential Use — Basic Standard Limited: 24 months or 1500 hours; Limited Powertrain: 72 months or 2000 hours. Commercial Use — Basic Standard Limited: 24 months or 1500 hours; Limited Powertrain: 36 months or 2000 hours. Base Price with Loader + Cab DT (4WD): Tractor Starting MSRP $46,306 + LOADER $5,971 = $52,277 MSRP; HST (4WD): Tractor Starting MSRP $48,266 + LOADER $5,971 = $54,237 MSRP GST (4WD): Not Applicable; HST (4WD): Not Applicable; HSTC (4WD, CAB): Tractor Starting MSRP $50,093 + LA1055 $6,710 = $56,803 MSRP ▶ ITC Company AccessoriesAccessories that fit None tagged yet ▶ SourcesSpec sheet sources [1] kubotausa.com [2] kubotausa.com [3] kubotausa.com [1] kubotausa.com [2] kubotausa.com [3] kubotausa.com [4] kubotausa.com
