▶ EnginePTO Power 17.1 hp (12.8 kW) 19.3 hp (14.4 kW) Alternator 12 V, 50 A 12 V, 50 A Air Cleaner Dry Dry Engine Type 3-cylinder, Liquid-cooled, Diesel, NA, IDI 3-cylinder, Indirect Injection (IDI), Swirl chamber Fuel System IDI In-line injection pump Displacement 80.4 in³ (1318 cc) 77.3 in³ (1267 cc) No. of Cylinders 3 3 Rated Engine Speed 2,500 rpm 2800 rpm Cooling System Type Liquid-cooled Not Published Engine Manufacturer MHI YANMAR Engine Emissions Constraints Tier 4 Tier 4 Engine Power (Gross vs. Net HP) Gross: 24.6 hp (18.3 kW) Gross: 24.7 hp (18.4 kW) ▶ WeightTractor Weight with Loader Not Published Not Published Weight with Cab and Loader Not Published Not Applicable Weight with ROPS and Loader Not Published Not Published ▶ HydraulicsPump Type Gear pump Engine-driven Steering Flow 17.4 L/min (4.6 gpm) 14.1 L/min (3.7 gpm) Implement Flow 26.9 L/min (7.1 gpm) 21.1 L/min (5.6 gpm) Total Hydraulic Flow 44.3 L/min (11.7 gpm) 35.2 L/min (9.3 gpm) Hydraulic System Type Open center Open center Rear Remote Hydraulic Flow Not Published Not Published Overall Hydraulic Pump Flow 44.3 L/min (11.7 gpm) 35.2 L/min (9.3 gpm) No. of Optional Remote Valves 1 1 pair (optional) No. of Standard Remote Valves 0 Not Applicable ▶ Tire OptionsR3 Turf - Rear 41X14.00-20 31X15.50-15 R3 Turf - Front 25X8.50-14 22X8.50-12 Tire Size & Options R1 Agricultural, R3 Turf, R4 Industrial R1 Agricultural, R3 Turf, R4 Industrial R4 Industrial - Rear 43X16.00-20 12-16.5 R4 Industrial - Front 27X8.50-15 23X8.50-12 R1 Agricultural - Rear 11.2-24 11.2-16 R1 Agricultural - Front 7-14 7-12 ▶ Pto & HitchPTO Rear 540 rpm 540 rpm PTO Type Independent Independent Lift Control Type Position control Position control Hitch Lift Capacity 1808 lb (820 kg) 1,896 lb (850 kg) Mid-PTO Availability Available (option) Optional (2500 rpm) Category, 3-Point Hitch Category I Category I Hitch Lift Capacity (at 24”) 1433 lb (650 kg) 1,323 lb (600 kg) Rear 3-Point Hitch Lift Capacity 1808 lb (820 kg) 1,896 lb (850 kg) ▶ Fluid CapacityCoolant Capacity Not Published 0.9 gal (3.3 L) Crankcase Capacity Not Published 0.8 gal (2.9 L) Fuel Tank Capacity 10.6 gal (40.1 L) 6.6 gal (25 L) Front Axle Fluid Capacity Not Published 0.8 gal (3.0 L) Transmission / Hydraulic System Capacity Not Published 4.5 gal (17 L) ▶ Loader & AttachmentsLoader Lift Height 94.3 in (2395 mm) 84.4 in (2144 mm) Loader Breakout Force 2,962 lb LL2300: 2,290 lb; LL2001: Not Published Price for Backhoe Option Not Published Not Published Price for Mid-Mount Mower Not Published Not Published Quick Attach Loader System LL3001, LL3002: ISO 24410 Quick Attaching Coupler LL2300: Bobcat-type (skid-steer style) quick attach bucket carrier; LL2001: Not Published Loader Lift Capacity (Full Height) 1,965 lb LL2300: 1,067 lb; LL2001: 955 lb ▶ Transmission & DrivetrainClutch Not Applicable Not Applicable No. of Speeds 3 ranges 3 ranges Transmission Type Hydrostatic Drive Hydrostatic Drive Max Travel Speed (Forward) Not Published Not Published Max Travel Speed (Reverse) Not Published Not Published Differential Lock & Limited Slip Options Mechanical differential lock (pedal) Mechanical differential lock (pedal) ▶ Chassis Steering & ControlsBrakes Wet, Multi-disc Wet, multi-disc Steering Hydrostatic power steering Hydrostatic power steering Frame Type Not Published Not Published Front Axle Type Not Published Not Published Drawbar Capacity Not Published Not Published Front Axle Rating Not Published Not Published Seat Suspension & Adjustability Not Published Not Published ▶ Dimensions & ManeuverabilityWheelbase 66 in (1676 mm) 63.4 in (1610 mm) Overall Width 66 in (1676 mm) 48.7 in (1237 mm) Ground Clearance Not Published Not Published Height to Top of ROPS 95 in (2413 mm) 86.4 in (2195 mm) Height to Top of Cab Model Not Applicable Not Applicable Height to Top of ROPS (folded) Not Published Not Published Min. Turn Radius without Brakes 11.5 ft (3.5 m) Not Published Overall Length with 3-Point Hitch 119 in (3023 mm) 111.9 in (2842 mm) ▶ Pricing Financing & WarrantyFinancing Options 0% financing up to 96 months on select models; cash rebate incentive (offers vary) 0% financing for up to 96 months on select models; cash rebate incentive may be available (limited time; subject to approved credit) Base Price with Loader Not Published Not Published Warranty Length & Coverage 6-year limited powertrain warranty; 2-year bumper-to-bumper warranty 6-year limited powertrain warranty; 2-year bumper-to-bumper warranty Base Price with Loader + Cab Not Published Not Applicable ▶ SourcesSpec sheet sources [1] lstractorusa.com [2] lstractorusa.com [3] lstractorusa.com [4] lstractorusa.com [5] lstractorusa.com [6] lstractorusa.com [7] lstractorusa.com [1] lstractorusa.com [2] lstractorusa.com [3] lstractorusa.com [4] lstractorusa.com [5] lstractorusa.com [6] lstractorusa.com [7] lstractorusa.com
