LS Tractor MT242HE vs LS Tractor MT242E | Side-by-side comparison | ITC Resource Center
ITC Resource Center
Tractor Comparison
Pick up to 4tractors and we'll lay every spec sheet out side by side. Same data we publish on the individual model pages, stacked in columns so you can compare numbers at a glance.
No photo
—
LSMT242HE
No photo
—
LSMT242E
Comparison loaded for 2 tractors.
Spec
LS TractorMT242HE
LS TractorMT242E
PTO Power
34.8 hp (26.0 kW)
35.4 hp (26.4 kW)
Alternator
12 V, 55 A
12 V, 55 A
Air Cleaner
Dry
Dry
Engine Type
4-cylinder, Liquid-cooled, Diesel, NA, CRDI
4-cylinder, Liquid-cooled, Diesel, NA, CRDI
Fuel System
CRDI
CRDI
Displacement
133.6 in³ (2189 cc)
133.6 in³ (2189 cc)
No. of Cylinders
4
4
Rated Engine Speed
2,600 rpm
2,600 rpm
Cooling System Type
Liquid-cooled
Liquid-cooled
Engine Manufacturer
YANMAR
YANMAR
Engine Emissions Constraints
Tier 4
Tier 4
Engine Power (Gross vs. Net HP)
Gross: 42.5 hp (31.7 kW)
Gross: 42.5 hp (31.7 kW)
Tractor Weight with Loader
Not Published
Not Published
Weight with Cab and Loader
Not Published
Not Published
Weight with ROPS and Loader
Not Published
Not Published
Pump Type
Gear pump
Gear pump
Steering Flow
18.9 L/min (5.0 gpm)
18.9 L/min (5.0 gpm)
Implement Flow
25.4 L/min (6.7 gpm)
28.0 L/min (7.4 gpm)
Total Hydraulic Flow
44.3 L/min (11.7 gpm)
46.9 L/min (12.4 gpm)
Hydraulic System Type
Open center
Open center
Rear Remote Hydraulic Flow
Not Published
Not Published
Overall Hydraulic Pump Flow
44.3 L/min (11.7 gpm)
46.9 L/min (12.4 gpm)
No. of Optional Remote Valves
1
1
No. of Standard Remote Valves
0
0
R3 Turf - Rear
41X14.00-20
41X14.00-20
R3 Turf - Front
25X8.50-14
25X8.50-14
Tire Size & Options
R1 Agricultural, R3 Turf, R4 Industrial
R1 Agricultural, R3 Turf, R4 Industrial
R4 Industrial - Rear
43X16.00-20
43X16.00-20
R4 Industrial - Front
27X8.50-15
27X8.50-15
R1 Agricultural - Rear
11.2-24
11.2-24
R1 Agricultural - Front
7-14
7-14
PTO Rear
540 rpm
540 rpm
PTO Type
Independent
Independent
Lift Control Type
Position control
Position control
Hitch Lift Capacity
1808 lb (820 kg)
1808 lb (820 kg)
Mid-PTO Availability
Available (option)
Available (option)
Category, 3-Point Hitch
Category I
Category I
Hitch Lift Capacity (at 24”)
1433 lb (650 kg)
1433 lb (650 kg)
Rear 3-Point Hitch Lift Capacity
1808 lb (820 kg)
1808 lb (820 kg)
Coolant Capacity
Not Published
Not Published
Crankcase Capacity
Not Published
Not Published
Fuel Tank Capacity
10.6 gal (40.1 L)
10.6 gal (40.1 L)
Front Axle Fluid Capacity
Not Published
Not Published
Transmission / Hydraulic System Capacity
Not Published
Not Published
Loader Lift Height
94.3 in (2395 mm)
94.3 in (2395 mm)
Loader Breakout Force
3,723 lb
3,723 lb
Price for Backhoe Option
Not Published
Not Published
Price for Mid-Mount Mower
Not Published
Not Published
Quick Attach Loader System
LL3003: ISO 24410 Quick Attaching Coupler
LL3003: ISO 24410 Quick Attaching Coupler
Loader Lift Capacity (Full Height)
2,506 lb
2,506 lb
Clutch
Not Applicable
Dry Single
No. of Speeds
3 ranges
F12 x R12
Transmission Type
Hydrostatic Drive
Synchro Shuttle
Max Travel Speed (Forward)
Not Published
Not Published
Max Travel Speed (Reverse)
Not Published
Not Published
Differential Lock & Limited Slip Options
Mechanical differential lock (pedal)
Mechanical differential lock (pedal)
Brakes
Wet, Multi-disc
Wet, Multi-disc
Steering
Hydrostatic power steering
Hydrostatic power steering
Frame Type
Not Published
Not Published
Front Axle Type
Not Published
Not Published
Drawbar Capacity
Not Published
Not Published
Front Axle Rating
Not Published
Not Published
Seat Suspension & Adjustability
Not Published
Not Published
Wheelbase
74 in (1880 mm)
74 in (1880 mm)
Overall Width
66 in (1676 mm)
66 in (1676 mm)
Ground Clearance
Not Published
Not Published
Height to Top of ROPS
95 in (2413 mm)
95 in (2413 mm)
Height to Top of Cab Model
Not Applicable
Not Applicable
Height to Top of ROPS (folded)
Not Published
Not Published
Min. Turn Radius without Brakes
11.8 ft (3.6 m)
11.8 ft (3.6 m)
Overall Length with 3-Point Hitch
125 in (3175 mm)
125 in (3175 mm)
Financing Options
0% financing up to 96 months on select models; cash rebate incentive (offers vary)
0% financing up to 96 months on select models; cash rebate incentive (offers vary)
