▶ EnginePTO Power 62.9 hp (46.9 kW) 63 hp (47 kW) Alternator 12 V, 70 A Not Published Air Cleaner Dry Not Published Engine Type In-line vertical, water cooled 4-cycle diesel, CRDI In-Line Vertical, Water-cooled 4-Cycle Turbo Diesel, CRDI (4F243T) Fuel System Delphi, CRDI Common Rail Direct Injection (CRDI) Displacement 152.86 in³ (2505 cc) 148.6 in³ (2,435 cc) No. of Cylinders 4 4 Rated Engine Speed 2,500 rpm 2,600 rpm Cooling System Type Water-cooled Water-cooled Engine Manufacturer LS Mtron KIOTI Engine Emissions Constraints Tier 4 Tier 4 Engine Power (Gross vs. Net HP) Gross: 73.0 hp (54.4 kW) Gross: 73 hp (54.4 kW) ▶ WeightTractor Weight with Loader 6,613 lb (3,000 kg) 6,162 lb (2,795 kg) Weight with Cab and Loader Not Applicable 6,162 lb (2,795 kg) Weight with ROPS and Loader 6,613 lb (3,000 kg) Not Applicable ▶ HydraulicsPump Type Gear type, engine drive Gear Steering Flow 25.7 L/min (6.8 gpm) 31.2 L/min (8.2 gpm) Implement Flow 56.4 L/min (14.9 gpm) 41.6 L/min (11.0 gpm) Total Hydraulic Flow 82.1 L/min (21.7 gpm) 72.8 L/min (19.2 gpm) Hydraulic System Type Open center Open center Rear Remote Hydraulic Flow Not Published Not Published Overall Hydraulic Pump Flow 82.1 L/min (21.7 gpm) 72.8 L/min (19.2 gpm) No. of Optional Remote Valves Not Published 2 No. of Standard Remote Valves 2 Pairs (Front), 2 Pairs (Rear) 1 ▶ Tire OptionsR3 Turf - Rear Not Published 44X18.00-20 R3 Turf - Front Not Published 31X13.50-15 Tire Size & Options Multiple options available (Standard Ag, Industrial, Large Ag, R14) R1 Agricultural, R3 Turf, R4 Industrial R4 Industrial - Rear 19.5LX24 18.4-24/8 R4 Industrial - Front 10.5/80X18 12.5/80-18 R1 Agricultural - Rear 16.9-30 14.9-28/8 R1 Agricultural - Front 11.2-24 9.5-20/8 ▶ Pto & HitchPTO Rear 540 / 540E 540 / 540E rpm PTO Type Independent Independent Lift Control Type Position & Draft Position, Draft, Mixed Control Hitch Lift Capacity 4,079 lbs 4,974 lb (2,256 kg) Mid-PTO Availability Not Published Not Applicable Category, 3-Point Hitch Category II Category II Hitch Lift Capacity (at 24”) 3,483 lbs 3,898 lb (1,768 kg) Rear 3-Point Hitch Lift Capacity 4,079 lbs 4,974 lb (2,256 kg) ▶ Fluid CapacityCoolant Capacity 3.0 gal (11.5 L) 2.40 gal (9.1 L) Crankcase Capacity 1.8 gal (7.0 L) 2.20 gal (8.3 L) Fuel Tank Capacity 24.3 gal (92 L) 25.10 gal (95 L) Front Axle Fluid Capacity 2.3 gal (8.6 L) 2.20 gal (8.5 L) Transmission / Hydraulic System Capacity 16.8 gal (63.5 L) 15.90 gal (60 L) ▶ Loader & AttachmentsLoader Lift Height 132.9 in (3376 mm) 133.9 in (3,401.1 mm) (to pivot pin) Loader Breakout Force Not Published 5,359.0 lb (2,430.8 kg) (at pivot pins) Price for Backhoe Option Not Applicable Not Applicable Price for Mid-Mount Mower Not Applicable Not Applicable Quick Attach Loader System LL5001: Standard Quick-Attach, Skid-Steer Compatible (SSQA) Built-in parking stand; designed to be quickly and easily attached and detached. Loader Lift Capacity (Full Height) 3,488 lb 3,384.0 lb (1,535.0 kg) (to full height at pivot pins) ▶ Transmission & DrivetrainClutch Wet clutch disks Wet Disc No. of Speeds F16 X R16 12 forward / 12 reverse Transmission Type Electro Power Shuttle Manual: Power Shuttle Max Travel Speed (Forward) Not Published 23.53 mph (37.86 km/h) Max Travel Speed (Reverse) Not Published 23.13 mph (37.23 km/h) Differential Lock & Limited Slip Options Mechanical differential lock (pedal) Rear differential lock (standard) ▶ Chassis Steering & ControlsBrakes Wet, Multi-disc Wet Multi Disc Steering Hydrostatic Power Steering Hydrostatic Power Steering Frame Type Not Published Not Published Front Axle Type Not Published Not Published Drawbar Capacity Not Published Not Published Front Axle Rating Not Published Not Published Seat Suspension & Adjustability Seat With Suspension & Armrest Adjustable Seat ▶ Dimensions & ManeuverabilityWheelbase 83.1 in (2111 mm) 83.90 in (2,131 mm) Overall Width 72.6 in (1844 mm) 77.20 in (1,961 mm) Ground Clearance Not Published 17.30 in (439 mm) Height to Top of ROPS 113.9 in (2893 mm) Not Applicable Height to Top of Cab Model Not Applicable 104.50 in (2,655 mm) Height to Top of ROPS (folded) Not Published Not Applicable Min. Turn Radius without Brakes 12.8 ft (3.9 m) 11.20 ft (3.42 m) Overall Length with 3-Point Hitch 154 in (3912 mm) 146.30 in (3,715 mm) ▶ Pricing Financing & WarrantyFinancing Options 0% financing up to 96 months on select models; cash rebate incentive (offers vary) RX Series: up to $4,000 cash offer; 0% up to 36 months; 6.99% interest rate (offers subject to change). Base Price with Loader Not Published Tractor Starting MSRP $50,639 + Front End Loader KL7320 $9,978 = $60,617 MSRP Warranty Length & Coverage 6-year limited powertrain warranty; 2-year bumper-to-bumper warranty Tractors (Non-Commercial Application): 24 months parts & labor; Extended (Non-Commercial, driveline/powertrain): 48 months parts & labor; Limited time: eligible units receive total 6 years (72 months) extended powertrain warranty coverage. Base Price with Loader + Cab Not Published Tractor Starting MSRP $50,639 + Front End Loader KL7320 $9,978 = $60,617 MSRP ▶ SourcesSpec sheet sources [1] lstractorusa.com [2] lstractorusa.com [3] lstractorusa.com [4] lstractorusa.com [5] lstractorusa.com [6] lstractorusa.com [7] lstractorusa.com [1] kioti.com [2] kioti-api.files.svdcdn.com [3] kioti-api.files.svdcdn.com [4] kioti.com
