▶ EnginePTO Power 18.5 hp (13.8 kW) 17.2 hp (12.8 kW) Alternator 12 V, 50 A 12 V, 40 A Air Cleaner Dry Dry Engine Type 3-cylinder, Indirect-injection (swirl chamber), Water-cooled 3-cylinder, Indirect-injection, Water-cooled Fuel System Indirect injection (in-line pump) Indirect injection; in-line pump Displacement 80.4 in³ (1318 cc) 77.3 in³ (1267 cc) No. of Cylinders 3 3 Rated Engine Speed 2500 rpm 3000 rpm Cooling System Type Water-cooled Water-cooled (thermostat) Engine Manufacturer Mitsubishi Yanmar Engine Emissions Constraints Tier 4 Tier 4 Engine Power (Gross vs. Net HP) Gross: 24.7 hp (18.4 kW) Gross: 24.7 hp (18.4 kW) ▶ WeightTractor Weight with Loader Not Published Not Published Weight with Cab and Loader Not Published Not Published Weight with ROPS and Loader Not Published Not Published ▶ HydraulicsPump Type Transmission drive pump Gear pump (transmission drive) Steering Flow 10.0 L/min (2.6 gpm) 7.9 L/min (2.1 gpm) Implement Flow 22.5 L/min (5.9 gpm) 17.4 L/min (4.6 gpm) Total Hydraulic Flow 32.5 L/min (8.5 gpm) 25.4 L/min (6.7 gpm) Hydraulic System Type Not Published Open center Rear Remote Hydraulic Flow Not Published Not Published Overall Hydraulic Pump Flow 32.5 L/min (8.5 gpm) 25.4 L/min (6.7 gpm) No. of Optional Remote Valves 1 pair (2 outlets; optional) 1 set (optional) No. of Standard Remote Valves Not Published Not Published ▶ Tire OptionsR3 Turf - Rear 320/65-16.5 26X12.00-12 (4PR) R3 Turf - Front 23X8.50-12 18X8.50-10 (4PR) Tire Size & Options R1 Agricultural, R3 Turf, R4 Industrial R3 Turf, R4 Industrial R4 Industrial - Rear 305/70-16.5 (6PR) 26X12.00-12 (4PR) R4 Industrial - Front 23X8.50-12 (4PR) 18X8.50-10 (4PR) R1 Agricultural - Rear 255/75-15.3 Not Published R1 Agricultural - Front 23X10.50-12 Not Published ▶ Pto & HitchPTO Rear 540 rpm 540 rpm PTO Type Electro-hydraulic rear PTO / mid-PTO Independent Lift Control Type Position control Position control Hitch Lift Capacity 1,433 lb (650 kg) 992 lb (450 kgf) Mid-PTO Availability Standard (2000 rpm) Standard (2500 rpm) Category, 3-Point Hitch Category I Category I Hitch Lift Capacity (at 24”) 1,058 lb (480 kg) 728 lb (330 kg) Rear 3-Point Hitch Lift Capacity 1,433 lb (650 kg) 992 lb (450 kgf) ▶ Fluid CapacityCoolant Capacity 1.0 gal (3.8 L) 0.9 gal (3.3 L) Crankcase Capacity 1.1 gal (4.2 L) 0.8 gal (2.9 L) Fuel Tank Capacity 6.6 gal (25 L) 6.6 gal (25 L) Front Axle Fluid Capacity 0.8 gal (3.0 L) 0.5 gal (2.0 L) Transmission / Hydraulic System Capacity 5.3 gal (20 L) 3.0 gal (11.5 L); w/ loader: 3.4 gal (13.0 L); w/ loader + backhoe: 4.7 gal (17.7 L) ▶ Loader & AttachmentsLoader Lift Height 85.7 in (2177 mm) LL1101: 72.6 in (1844 mm); LL1700: 74 in (1878 mm) Loader Breakout Force 1,687 lb LL1101: 1,836 lb (pivot pin); LL1700: 1,470 lb (pivot pin) Price for Backhoe Option Not Published Not Published Price for Mid-Mount Mower Not Published Not Published Quick Attach Loader System LL2102: Quick-attach front end loader LL1101: Optional Quick Attach Assembly (compact type), standard pin-type bucket.; LL1700: Quick Attach Implement System Loader Lift Capacity (Full Height) 1,276 lb LL1101: 902 lb (pivot pin @ 1.5 m); LL1700: 980 lb (pivot pin @ 1.5 m) ▶ Transmission & DrivetrainClutch Not Applicable Not Applicable No. of Speeds 2 ranges 2 ranges Transmission Type Hydrostatic Drive Hydrostatic Drive Max Travel Speed (Forward) Not Published 11.6 mph (18.7 km/h) Max Travel Speed (Reverse) Not Published 8.9 mph (14.3 km/h) Differential Lock & Limited Slip Options Mechanical differential lock (pedal) Mechanical differential lock (pedal) ▶ Chassis Steering & ControlsBrakes Wet, multi-disc Wet, multi-disc Steering Hydrostatic power steering Hydrostatic power steering Frame Type Not Published Not Published Front Axle Type Front wheel mechanical assist (4WD) 4WD (Front Wheel Mechanical Assist) Drawbar Capacity Horizontal load: 3,527 lb (1,600 kg); Vertical load: 551 lb (250 kg) pulled / 882 lb (400 kg) pushed Not Published Front Axle Rating Not Published Not Published Seat Suspension & Adjustability Not Published Not Published ▶ Dimensions & ManeuverabilityWheelbase 59 in (1499 mm) 56 in (1422 mm) Overall Width 44.9 in (1140 mm) 47 in (1194 mm) Ground Clearance Not Published Not Published Height to Top of ROPS 84.5 in (2146 mm) 87 in (2210 mm) Height to Top of Cab Model Not Published Not Published Height to Top of ROPS (folded) Not Published Not Published Min. Turn Radius without Brakes Not Published 94.5 in (2400 mm) Overall Length with 3-Point Hitch 103 in (2616 mm) 97 in (2464 mm) ▶ Pricing Financing & WarrantyFinancing Options 0% financing for up to 96 months on select models; cash rebate incentives may be available (limited time; subject to approved credit) 0% financing for up to 120 months on MT1 models (limited time); other offers may apply Base Price with Loader Not Published Not Published Warranty Length & Coverage 6-year limited powertrain warranty; 2-year bumper-to-bumper warranty 6-year limited powertrain warranty; 2-year bumper-to-bumper warranty Base Price with Loader + Cab Not Published Not Published ▶ SourcesSpec sheet sources [1] lstractorusa.com [2] lstractorusa.com [3] lstractorusa.com [4] lstractorusa.com [5] lstractorusa.com [6] lstractorusa.com [7] lstractorusa.com [1] lstractorusa.com [2] lstractorusa.com [3] lstractorusa.com [4] lstractorusa.com [5] lstractorusa.com [6] lstractorusa.com [7] lstractorusa.com
