▶ EnginePTO Power 18.5 hp (13.8 kW) 19.3 hp (14.4 kW) Alternator 12 V, 50 A 12 V, 50 A Air Cleaner Dry Dry Engine Type 3-cylinder, Indirect-injection (swirl chamber), Water-cooled 3-cylinder, Indirect Injection (IDI), Swirl chamber Fuel System Indirect injection (in-line pump) In-line injection pump Displacement 80.4 in³ (1318 cc) 77.3 in³ (1267 cc) No. of Cylinders 3 3 Rated Engine Speed 2500 rpm 2800 rpm Cooling System Type Water-cooled Not Published Engine Manufacturer Mitsubishi YANMAR Engine Emissions Constraints Tier 4 Tier 4 Engine Power (Gross vs. Net HP) Gross: 24.7 hp (18.4 kW) Gross: 24.7 hp (18.4 kW) ▶ WeightTractor Weight with Loader Not Published Not Published Weight with Cab and Loader Not Published Not Applicable Weight with ROPS and Loader Not Published Not Published ▶ HydraulicsPump Type Transmission drive pump Engine-driven Steering Flow 10.0 L/min (2.6 gpm) 14.1 L/min (3.7 gpm) Implement Flow 22.5 L/min (5.9 gpm) 21.1 L/min (5.6 gpm) Total Hydraulic Flow 32.5 L/min (8.5 gpm) 35.2 L/min (9.3 gpm) Hydraulic System Type Not Published Open center Rear Remote Hydraulic Flow Not Published Not Published Overall Hydraulic Pump Flow 32.5 L/min (8.5 gpm) 35.2 L/min (9.3 gpm) No. of Optional Remote Valves 1 pair (2 outlets; optional) 1 pair (optional) No. of Standard Remote Valves Not Published Not Applicable ▶ Tire OptionsR3 Turf - Rear 320/65-16.5 31X15.50-15 R3 Turf - Front 23X8.50-12 22X8.50-12 Tire Size & Options R1 Agricultural, R3 Turf, R4 Industrial R1 Agricultural, R3 Turf, R4 Industrial R4 Industrial - Rear 305/70-16.5 (6PR) 12-16.5 R4 Industrial - Front 23X8.50-12 (4PR) 23X8.50-12 R1 Agricultural - Rear 255/75-15.3 11.2-16 R1 Agricultural - Front 23X10.50-12 7-12 ▶ Pto & HitchPTO Rear 540 rpm 540 rpm PTO Type Electro-hydraulic rear PTO / mid-PTO Independent Lift Control Type Position control Position control Hitch Lift Capacity 1,433 lb (650 kg) 1,896 lb (850 kg) Mid-PTO Availability Standard (2000 rpm) Optional (2500 rpm) Category, 3-Point Hitch Category I Category I Hitch Lift Capacity (at 24”) 1,058 lb (480 kg) 1,323 lb (600 kg) Rear 3-Point Hitch Lift Capacity 1,433 lb (650 kg) 1,896 lb (850 kg) ▶ Fluid CapacityCoolant Capacity 1.0 gal (3.8 L) 0.9 gal (3.3 L) Crankcase Capacity 1.1 gal (4.2 L) 0.8 gal (2.9 L) Fuel Tank Capacity 6.6 gal (25 L) 6.6 gal (25 L) Front Axle Fluid Capacity 0.8 gal (3.0 L) 0.8 gal (3.0 L) Transmission / Hydraulic System Capacity 5.3 gal (20 L) 4.5 gal (17 L) ▶ Loader & AttachmentsLoader Lift Height 85.7 in (2177 mm) 84.4 in (2144 mm) Loader Breakout Force 1,687 lb LL2300: 2,290 lb; LL2001: Not Published Price for Backhoe Option Not Published Not Published Price for Mid-Mount Mower Not Published Not Published Quick Attach Loader System LL2102: Quick-attach front end loader LL2300: Bobcat-type (skid-steer style) quick attach bucket carrier; LL2001: Not Published Loader Lift Capacity (Full Height) 1,276 lb LL2300: 1,067 lb; LL2001: 955 lb ▶ Transmission & DrivetrainClutch Not Applicable Not Applicable No. of Speeds 2 ranges 3 ranges Transmission Type Hydrostatic Drive Hydrostatic Drive Max Travel Speed (Forward) Not Published Not Published Max Travel Speed (Reverse) Not Published Not Published Differential Lock & Limited Slip Options Mechanical differential lock (pedal) Mechanical differential lock (pedal) ▶ Chassis Steering & ControlsBrakes Wet, multi-disc Wet, multi-disc Steering Hydrostatic power steering Hydrostatic power steering Frame Type Not Published Not Published Front Axle Type Front wheel mechanical assist (4WD) Not Published Drawbar Capacity Horizontal load: 3,527 lb (1,600 kg); Vertical load: 551 lb (250 kg) pulled / 882 lb (400 kg) pushed Not Published Front Axle Rating Not Published Not Published Seat Suspension & Adjustability Not Published Not Published ▶ Dimensions & ManeuverabilityWheelbase 59 in (1499 mm) 63.4 in (1610 mm) Overall Width 44.9 in (1140 mm) 48.7 in (1237 mm) Ground Clearance Not Published Not Published Height to Top of ROPS 84.5 in (2146 mm) 86.4 in (2195 mm) Height to Top of Cab Model Not Published Not Applicable Height to Top of ROPS (folded) Not Published Not Published Min. Turn Radius without Brakes Not Published Not Published Overall Length with 3-Point Hitch 103 in (2616 mm) 111.9 in (2842 mm) ▶ Pricing Financing & WarrantyFinancing Options 0% financing for up to 96 months on select models; cash rebate incentives may be available (limited time; subject to approved credit) 0% financing for up to 96 months on select models; cash rebate incentive may be available (limited time; subject to approved credit) Base Price with Loader Not Published Not Published Warranty Length & Coverage 6-year limited powertrain warranty; 2-year bumper-to-bumper warranty 6-year limited powertrain warranty; 2-year bumper-to-bumper warranty Base Price with Loader + Cab Not Published Not Applicable ▶ SourcesSpec sheet sources [1] lstractorusa.com [2] lstractorusa.com [3] lstractorusa.com [4] lstractorusa.com [5] lstractorusa.com [6] lstractorusa.com [7] lstractorusa.com [1] lstractorusa.com [2] lstractorusa.com [3] lstractorusa.com [4] lstractorusa.com [5] lstractorusa.com [6] lstractorusa.com [7] lstractorusa.com
