▶ EnginePTO Power 18.5 hp (13.8 kW) 19.2 hp (14.3 kW) Alternator 12 V, 50 A 12 V, 50 A Air Cleaner Dry Dry Engine Type 3-cylinder, Indirect-injection (swirl chamber), Water-cooled 3-cylinder, Liquid-cooled, Diesel, NA, IDI Fuel System Indirect injection (in-line pump) IDI Displacement 80.4 in³ (1318 cc) 80.4 in³ (1318 cc) No. of Cylinders 3 3 Rated Engine Speed 2500 rpm 2,500 rpm Cooling System Type Water-cooled Liquid-cooled Engine Manufacturer Mitsubishi MHI Engine Emissions Constraints Tier 4 Tier 4 Engine Power (Gross vs. Net HP) Gross: 24.7 hp (18.4 kW) Gross: 24.6 hp (18.3 kW) ▶ WeightTractor Weight with Loader Not Published Not Published Weight with Cab and Loader Not Published Not Published Weight with ROPS and Loader Not Published Not Published ▶ HydraulicsPump Type Transmission drive pump Gear pump Steering Flow 10.0 L/min (2.6 gpm) 17.4 L/min (4.6 gpm) Implement Flow 22.5 L/min (5.9 gpm) 29.9 L/min (7.9 gpm) Total Hydraulic Flow 32.5 L/min (8.5 gpm) 47.3 L/min (12.5 gpm) Hydraulic System Type Not Published Open center Rear Remote Hydraulic Flow Not Published Not Published Overall Hydraulic Pump Flow 32.5 L/min (8.5 gpm) 47.3 L/min (12.5 gpm) No. of Optional Remote Valves 1 pair (2 outlets; optional) 1 No. of Standard Remote Valves Not Published 0 ▶ Tire OptionsR3 Turf - Rear 320/65-16.5 41X14.00-20 R3 Turf - Front 23X8.50-12 25X8.50-14 Tire Size & Options R1 Agricultural, R3 Turf, R4 Industrial R1 Agricultural, R3 Turf, R4 Industrial R4 Industrial - Rear 305/70-16.5 (6PR) 43X16.00-20 R4 Industrial - Front 23X8.50-12 (4PR) 27X8.50-15 R1 Agricultural - Rear 255/75-15.3 11.2-24 R1 Agricultural - Front 23X10.50-12 7-14 ▶ Pto & HitchPTO Rear 540 rpm 540 rpm PTO Type Electro-hydraulic rear PTO / mid-PTO TM Driven Lift Control Type Position control Position control Hitch Lift Capacity 1,433 lb (650 kg) 1433 lb (650 kg) Mid-PTO Availability Standard (2000 rpm) Available (option) Category, 3-Point Hitch Category I Category I Hitch Lift Capacity (at 24”) 1,058 lb (480 kg) 1433 lb (650 kg) Rear 3-Point Hitch Lift Capacity 1,433 lb (650 kg) 1433 lb (650 kg) ▶ Fluid CapacityCoolant Capacity 1.0 gal (3.8 L) Not Published Crankcase Capacity 1.1 gal (4.2 L) Not Published Fuel Tank Capacity 6.6 gal (25 L) 10.6 gal (40.1 L) Front Axle Fluid Capacity 0.8 gal (3.0 L) Not Published Transmission / Hydraulic System Capacity 5.3 gal (20 L) Not Published ▶ Loader & AttachmentsLoader Lift Height 85.7 in (2177 mm) 94.3 in (2395 mm) Loader Breakout Force 1,687 lb 2,962 lb Price for Backhoe Option Not Published Not Published Price for Mid-Mount Mower Not Published Not Published Quick Attach Loader System LL2102: Quick-attach front end loader LL3001, LL3002: ISO 24410 Quick Attaching Coupler Loader Lift Capacity (Full Height) 1,276 lb 1,965 lb ▶ Transmission & DrivetrainClutch Not Applicable Dry Single No. of Speeds 2 ranges F12 x R12 Transmission Type Hydrostatic Drive Synchro Shuttle Max Travel Speed (Forward) Not Published Not Published Max Travel Speed (Reverse) Not Published Not Published Differential Lock & Limited Slip Options Mechanical differential lock (pedal) Mechanical differential lock (pedal) ▶ Chassis Steering & ControlsBrakes Wet, multi-disc Wet, Multi-disc Steering Hydrostatic power steering Hydrostatic power steering Frame Type Not Published Not Published Front Axle Type Front wheel mechanical assist (4WD) Not Published Drawbar Capacity Horizontal load: 3,527 lb (1,600 kg); Vertical load: 551 lb (250 kg) pulled / 882 lb (400 kg) pushed Not Published Front Axle Rating Not Published Not Published Seat Suspension & Adjustability Not Published Not Published ▶ Dimensions & ManeuverabilityWheelbase 59 in (1499 mm) 66 in (1676 mm) Overall Width 44.9 in (1140 mm) 66 in (1676 mm) Ground Clearance Not Published Not Published Height to Top of ROPS 84.5 in (2146 mm) 95 in (2413 mm) Height to Top of Cab Model Not Published Not Applicable Height to Top of ROPS (folded) Not Published Not Published Min. Turn Radius without Brakes Not Published 11.5 ft (3.5 m) Overall Length with 3-Point Hitch 103 in (2616 mm) 119 in (3023 mm) ▶ Pricing Financing & WarrantyFinancing Options 0% financing for up to 96 months on select models; cash rebate incentives may be available (limited time; subject to approved credit) 0% financing up to 96 months on select models; cash rebate incentive (offers vary) Base Price with Loader Not Published Not Published Warranty Length & Coverage 6-year limited powertrain warranty; 2-year bumper-to-bumper warranty 6-year limited powertrain warranty; 2-year bumper-to-bumper warranty Base Price with Loader + Cab Not Published Not Published ▶ SourcesSpec sheet sources [1] lstractorusa.com [2] lstractorusa.com [3] lstractorusa.com [4] lstractorusa.com [5] lstractorusa.com [6] lstractorusa.com [7] lstractorusa.com [1] lstractorusa.com [2] lstractorusa.com [3] lstractorusa.com [4] lstractorusa.com [5] lstractorusa.com [6] lstractorusa.com [7] lstractorusa.com
