Tractor Comparison
Pick up to 4tractors and we'll lay every spec sheet out side by side. Same data we publish on the individual model pages, stacked in columns so you can compare numbers at a glance.
No photo
—
MahindraMAX26XLT
No photo
—
Mahindra1126
Comparison loaded for 2 tractors.
Spec
MahindraMAX 26 XLT
Mahindra1126
PTO Power
21.7 hp (16.2 kW)
19.2 hp (14.3 kW)
Alternator
12 V, 50 A
12 V, 55 A
Air Cleaner
Not Published
Not Published
Engine Type
Four-stroke, Naturally Aspirated, Indirect Injection, Water Cooled Diesel Engine
Four Stroke, Naturally Aspired, Indirect Injection, Water-Cooled Diesel Engine
Fuel System
Indirect Injection
Indirect Injection
Displacement
80.4 in³ (1318 cc)
67.2 in³ (1102 cc)
No. of Cylinders
3
3
Rated Engine Speed
2500 rpm
3000 rpm
Cooling System Type
Water-cooled
Water-Cooled
Engine Manufacturer
Mitsubishi
Mitsubishi
Engine Emissions Constraints
No DPF
No DPF
Engine Power (Gross vs. Net HP)
Gross: 25.9 hp (19.3 kW) @ 2500 rpm
Gross: 25.3 hp (18.9 kW) @ 3000 rpm
Tractor Weight with Loader
2600 lb (1180 kg)
2026 lb (919 kg)
Weight with Cab and Loader
Not Applicable
Not Applicable
Weight with ROPS and Loader
2600 lb (1180 kg)
2026 lb (919 kg)
Pump Type
Not Published
Not Published
Steering Flow
10.2 L/min (2.7 gpm)
14.4 L/min (3.8 gpm)
Implement Flow
22.0 L/min (5.8 gpm)
28.7 L/min (7.6 gpm)
Total Hydraulic Flow
32.2 L/min (8.5 gpm)
43.1 L/min (11.4 gpm)
Hydraulic System Type
Open Center
Open Center, full-live hydraulic with position control
Rear Remote Hydraulic Flow
Not Published
Not Published
Overall Hydraulic Pump Flow
32.2 L/min (8.5 gpm)
43.1 L/min (11.4 gpm)
No. of Optional Remote Valves
Not Published
Single or dual
No. of Standard Remote Valves
Not Published
Not Published
R3 Turf - Rear
33X12.5-15
26X12-12
R3 Turf - Front
23X8.5-12
18X8.5-10
Tire Size & Options
R1 Agriculture, R3 Turf, R4 Industrial
R3 Turf, R4 Industrial
R4 Industrial - Rear
12-16.5
26X12-12
R4 Industrial - Front
23X8.50-12
18X8.5-10
R1 Agricultural - Rear
9.5-16
Not Published
R1 Agricultural - Front
7.0-12
Not Published
PTO Rear
540 rpm @ 2376 rpm
540 rpm @ 2837 rpm
PTO Type
Live
Independent Wet Clutch
Lift Control Type
Position Control
Position Control
Hitch Lift Capacity
Not Published
Not Published
Mid-PTO Availability
Optional; 2000 @ 2526 rpm
Optional; 2500 rpm @ 2837 rpm
Category, 3-Point Hitch
CAT I
CAT I with check chains
Hitch Lift Capacity (at 24”)
2315 lb (1052 kg)
771 lb (350 kg)
Rear 3-Point Hitch Lift Capacity
Not Published
Not Published
Coolant Capacity
Not Published
Not Published
Crankcase Capacity
Not Published
Not Published
Fuel Tank Capacity
6.1 gal (23 L)
6.6 gal (25 L)
Front Axle Fluid Capacity
Not Published
Not Published
Transmission / Hydraulic System Capacity
Not Published
Not Published
Loader Lift Height
82.7 in (2100 mm)
68 in (1721 mm)
Loader Breakout Force
2690 lb (1220 kg)
1433 lb (650 kg)
Price for Backhoe Option
26B: $8,942
BHA11: $8,297
Price for Mid-Mount Mower
65M: $5,339.
MQ1154: $4,122; MQ1160: $4,870
Quick Attach Loader System
MXLT26L: Quick-Attach Adapter (included)
L11: Skid-steer couplers (skid-steer style quick attach) for superfast hookups.
