▶ EnginePTO Power 14.2 hp (10.6 kW) 16.8 hp (12.5 kW) Alternator 12 V, 45 A 12 V, 55 A Air Cleaner Not Published Not Published Engine Type Four-stroke, Naturally Aspirated, Indirect Injection, Water-cooled Diesel Engine Diesel, Indirect Injection, Water-cooled Fuel System Indirect Injection Indirect Injection Displacement 60.6 in³ (993 cc) 80.4 in³ (1318 cc) No. of Cylinders 3 3 Rated Engine Speed 3000 rpm 2500 rpm Cooling System Type Water-cooled Water-cooled Engine Manufacturer Yanmar Mitsubishi Engine Emissions Constraints Complies with US TIER-4 Final Norms No DPF Engine Power (Gross vs. Net HP) Gross: 19.4 hp (14.5 kW) @ 3000 rpm Gross: 22.9 hp (17.1 kW) @ 2500 rpm ▶ WeightTractor Weight with Loader 1918 lb (870 kg) 2557 lb (1200 kg) Weight with Cab and Loader Not Applicable 3063 lb (1389 kg) Weight with ROPS and Loader 1918 lb (870 kg) 2557 lb (1200 kg) ▶ HydraulicsPump Type Not Published Not Published Steering Flow 7.9 L/min (2.1 gpm) 18.9 L/min (5.0 gpm) Implement Flow 15.5 L/min (4.1 gpm) 23.8 L/min (6.3 gpm) Total Hydraulic Flow 23.4 L/min (6.2 gpm) 42.8 L/min (11.3 gpm) Hydraulic System Type Open Center Open Center with Position Control Rear Remote Hydraulic Flow Not Published Not Published Overall Hydraulic Pump Flow 23.4 L/min (6.2 gpm) 42.8 L/min (11.3 gpm) No. of Optional Remote Valves Not Published Not Published No. of Standard Remote Valves Not Published Not Published ▶ Tire OptionsR3 Turf - Rear 26X12-12 13.5-16 R3 Turf - Front 18X8.5-10 8.5X14 Tire Size & Options R1 Agriculture, R3 Turf, R4 Industrial R3 Turf, R4 Industrial R4 Industrial - Rear 26X12-12 12.4-16 R4 Industrial - Front 18X8.5-10 8.5X14 R1 Agricultural - Rear 26X12-12 Not Applicable R1 Agricultural - Front 18X8.5-10 Not Applicable ▶ Pto & HitchPTO Rear 540 @ 2942 rpm 540 rpm @ 2376 rpm PTO Type Independent Live Lift Control Type Position Control Position Control Hitch Lift Capacity Not Published Not Published Mid-PTO Availability Available; 2500 @ 2958 rpm Available; 2500 @ 2500 Category, 3-Point Hitch CAT I Narrow with Check Chains CAT I with Telescoping stabilizers Hitch Lift Capacity (at 24”) 680 lb (309 kg) 1760 lb (798 kg) Rear 3-Point Hitch Lift Capacity Not Published Not Published ▶ Fluid CapacityCoolant Capacity Not Published Not Published Crankcase Capacity Not Published Not Published Fuel Tank Capacity 6.6 gal (25 L) 5.8 gal (22 L) Front Axle Fluid Capacity Not Published Not Published Transmission / Hydraulic System Capacity Not Published Not Published ▶ Loader & AttachmentsLoader Lift Height 71.3 in 77 in (1950 mm) Loader Breakout Force 1235 lb 2160 lb (980 kg) Price for Backhoe Option 23B: $6,708 B21: $9,689 Price for Mid-Mount Mower 50M: $3,452 MQ2160: $4,870 Quick Attach Loader System 23L: Standard skid-steer style loader couplers (Quick Attach Couplers) for fast, easy front-implement connection. L21: Skid-steer couplers (skid-steer style quick attach) for superfast hookups. Loader Lift Capacity (Full Height) 617 lb (at pivot pin) 1477 lb (670 kg) ▶ Transmission & DrivetrainClutch Dry-Single Not Applicable No. of Speeds Infinite / 2 ranges Infinite / 3 Ranges Transmission Type HST HST Max Travel Speed (Forward) 7.8 mph (12.9 km/h) 11.2 mph (18 km/h) Max Travel Speed (Reverse) Not Published Not Published Differential Lock & Limited Slip Options Not Published Not Published ▶ Chassis Steering & ControlsBrakes Wet Disc Two Pedal Steering Power Steering Hydrostatic Power Steering Frame Type Not Published Not Published Front Axle Type Not Published Not Published Drawbar Capacity Not Published Not Published Front Axle Rating Not Published 2425 lb Seat Suspension & Adjustability Not Published Not Published ▶ Dimensions & ManeuverabilityWheelbase 53.1 in (1348 mm) 61.4 in (1560 mm) Overall Width 44.5 in (1130 mm) 54.4 in (1383 mm) Ground Clearance 8.3 in (210 mm) 13.4 in (340 mm) Height to Top of ROPS 86.6 in (2299 mm) 93.6 in (2377 mm) Height to Top of Cab Model Not Applicable 84.4 in (2145 mm) Height to Top of ROPS (folded) Not Published Not Published Min. Turn Radius without Brakes Not Published Not Published Overall Length with 3-Point Hitch 94.2 in (2392 mm) 112.7 in (2863 mm) ▶ Pricing Financing & WarrantyFinancing Options 0% up to 72 months; 1.99% 73–84 months 0% up to 60 months; 1.99% 61-72 months; 2.99% 73-84 months Base Price with Loader $13,481 + $4,603 (23L) = $18,084 $19,431 + $6,262 (L21) = $25,693 Warranty Length & Coverage 7-Year Limited Powertrain Warranty 7-Year Limited Powertrain Warranty Base Price with Loader + Cab Not Applicable Not Applicable ▶ SourcesSpec sheet sources [1] mahindrausa.com [2] mahindrausa.com [1] mahindrausa.com [2] mahindrausa.com
