Pick up to 4tractors and we'll lay every spec sheet out side by side. Same data we publish on the individual model pages, stacked in columns so you can compare numbers at a glance.
—
MasseyFergusonMF1735M
—
LSMT335H
Comparison loaded for 2 tractors.
Spec
Massey FergusonMF 1735 M
LS TractorMT335H
PTO Power
Not Published
28 hp
Alternator
Not Published
70 A, 12 V
Air Cleaner
Not Published
Dry
Engine Type
3-cylinder turbocharged diesel
4-stroke, vertical, water cooling, CRDI
Fuel System
Not Published
Delphi, CRDI
Displacement
111.4 in³
114.7 in³
No. of Cylinders
3
3
Rated Engine Speed
2500 rpm
2600 rpm
Cooling System Type
Not Published
Water-cooled
Engine Manufacturer
Massey Ferguson (AGCO)
LS Mtron
Engine Power (Gross)
35 hp
35 hp
Engine Emissions Constraints
Stage V
Tier 4
Tractor Weight with Loader
Not Published
Not Published
Weight with Cab and Loader
Not Published
Not Applicable
Weight with ROPS and Loader
Not Published
Not Published
Pump Type
Not Published
Gear pump, engine drive
Steering Flow
Not Published
5.5 gpm
Implement Flow
11.0 gpm
7.8 gpm
Total Hydraulic Flow
Not Published
13.3 gpm
Hydraulic System Type
Open-centre
Open center
Rear Remote Hydraulic Flow
Not Published
Not Published
Overall Hydraulic Pump Flow
Not Published
13.3 gpm
No. of Optional Remote Valves
Not Published
Not Published
No. of Standard Remote Valves
2
2 Pair
PTO Rear
540/750 (540E) rpm
540 rpm
PTO Type
Not Published
Independent PTO with wet disk clutch
Lift Control Type
Not Published
Position & Draft
Hitch Lift Capacity
2,646 lb
1,808 lbs
Mid-PTO Availability
Standard
Option (2,000 rpm)
Category, 3-Point Hitch
Category I
Category I
Hitch Lift Capacity (at 24”)
Not Published
1,433 lbs
R3 Turf - Rear
315/80D-16
41X14-20
R3 Turf - Front
24X8.50-12
25X8.5-14
Tire Size & Options
R1 Agricultural, R3 Turf, R4 Industrial
R1 Agricultural, R3 Turf, R4 Industrial
R4 Industrial - Rear
13.6-16
43X16-20
R4 Industrial - Front
21X10.50-12
25X8.5-14
R1 Agricultural - Rear
9.5-24
11.2-24
R1 Agricultural - Front
7-14
7.0-14
Coolant Capacity
Not Published
1.9 gal
Crankcase Capacity
Not Published
1.5 gal
Fuel Tank Capacity
9.5 gal
10.6 gal
Front Axle Fluid Capacity
Not Published
1.7 gal
Transmission / Hydraulic System Capacity
Not Published
7.9 gal
Loader Lift Height
Not Published
94.4 in
Loader Breakout Force
Not Published
3,612 lbs
Price for Backhoe Option
Not Published
Not Published
Price for Mid-Mount Mower
Not Published
Not Published
Quick Attach Loader System
Not Published
LL3116: Standard Skid Steer Coupler (skid-steer compatible quick-attach)
Loader Lift Capacity (Full Height)
Not Published
2,185 lbs
Clutch
Not Applicable
Not Applicable
No. of Speeds
Not Published
2 Pedal with 3 Range - HST
Transmission Type
Hydrostatic
Hydrostatic Drive
Max Travel Speed (Forward)
Not Published
Not Published
Max Travel Speed (Reverse)
Not Published
Not Published
Differential Lock & Limited Slip Options
Differential lock
Mechanical differential lock (pedal)
Brakes
Not Published
Wet, Multi-disc
Steering
Not Published
Hydrostatic Power Steering
Frame Type
Not Published
Not Published
Front Axle Type
Not Published
Not Published
Drawbar Capacity
Not Published
Not Published
Front Axle Rating
Not Published
Not Published
Seat Suspension & Adjustability
Not Published
Not Published
Wheelbase
CAB: 66.7 in; ROPS: 76.0 in
69.1 in
Overall Width
CAB: 55.7 in; ROPS: 53.9 in
59.3 in
Ground Clearance
Not Published
Not Published
Height to Top of ROPS
96.7 in
94.0 in
Height to Top of Cab Model
85.6 in
Not Applicable
Height to Top of ROPS (folded)
Not Published
Not Published
Min. Turn Radius without Brakes
Not Published
Not Published
Overall Length with 3-Point Hitch
CAB: 121.7 in; ROPS: 135.0 in
136.1 in
Financing Options
0% for up to 60 Months* (Offer valid through February 28, 2026)
0% financing up to 96 months on select models; cash rebate incentive (offers vary)
