Pick up to 4tractors and we'll lay every spec sheet out side by side. Same data we publish on the individual model pages, stacked in columns so you can compare numbers at a glance.
No photo
—
MasseyFergusonMF1740M
No photo
—
MasseyFergusonMF1735M
Comparison loaded for 2 tractors.
Spec
Massey FergusonMF 1740 M
Massey FergusonMF 1735 M
PTO Power
Not Published
Not Published
Alternator
Not Published
Not Published
Air Cleaner
Not Published
Not Published
Engine Type
3-cylinder turbocharged diesel
3-cylinder turbocharged diesel
Fuel System
Not Published
Not Published
Displacement
111.4 in³ (1,825 cc)
111.4 in³ (1,825 cc)
No. of Cylinders
3
3
Rated Engine Speed
2,500 rpm
2,500 rpm
Cooling System Type
Not Published
Not Published
Engine Manufacturer
Massey Ferguson (AGCO)
Massey Ferguson (AGCO)
Engine Emissions Constraints
Stage V
Stage V
Engine Power (Gross vs. Net HP)
ISO: 40 hp (29 kW)
ISO: 35 hp (25 kW)
Tractor Weight with Loader
Not Published
Not Published
Weight with Cab and Loader
Not Published
Not Published
Weight with ROPS and Loader
Not Published
Not Published
Pump Type
Not Published
Not Published
Steering Flow
Not Published
Not Published
Implement Flow
41.5 L/min (11.0 gpm)
41.5 L/min (11.0 gpm)
Total Hydraulic Flow
Not Published
Not Published
Hydraulic System Type
Open-centre
Open-centre
Rear Remote Hydraulic Flow
Not Published
Not Published
Overall Hydraulic Pump Flow
Not Published
Not Published
No. of Optional Remote Valves
Not Published
Not Published
No. of Standard Remote Valves
2
2
R3 Turf - Rear
315/80D-16
315/80D-16
R3 Turf - Front
24X8.50-12
24X8.50-12
Tire Size & Options
R1 Agricultural, R3 Turf, R4 Industrial
R1 Agricultural, R3 Turf, R4 Industrial
R4 Industrial - Rear
13.6-16
13.6-16
R4 Industrial - Front
21X10.50-12
21X10.50-12
R1 Agricultural - Rear
9.5-24
9.5-24
R1 Agricultural - Front
7-14
7-14
PTO Rear
540/750 (540E) rpm
540/750 (540E) rpm
PTO Type
Not Published
Not Published
Lift Control Type
Not Published
Not Published
Hitch Lift Capacity
2,646 lb (1,200 kg)
2,646 lb (1,200 kg)
Mid-PTO Availability
Standard
Standard
Category, 3-Point Hitch
Category I
Category I
Hitch Lift Capacity (at 24”)
Not Published
Not Published
Rear 3-Point Hitch Lift Capacity
2,646 lb (1,200 kg)
2,646 lb (1,200 kg)
Coolant Capacity
Not Published
Not Published
Crankcase Capacity
Not Published
Not Published
Fuel Tank Capacity
9.5 gal (36 L)
9.5 gal (36 L)
Front Axle Fluid Capacity
Not Published
Not Published
Transmission / Hydraulic System Capacity
Not Published
Not Published
Loader Lift Height
Not Published
Not Published
Loader Breakout Force
Not Published
Not Published
Price for Backhoe Option
Not Published
Not Published
Price for Mid-Mount Mower
Not Published
Not Published
Quick Attach Loader System
Not Published
Not Published
Loader Lift Capacity (Full Height)
Not Published
Not Published
Clutch
Not Applicable
Not Applicable
No. of Speeds
Not Published
Not Published
Transmission Type
Hydrostatic
Hydrostatic
Max Travel Speed (Forward)
Not Published
Not Published
Max Travel Speed (Reverse)
Not Published
Not Published
Differential Lock & Limited Slip Options
Differential lock
Differential lock
Brakes
Not Published
Not Published
Steering
Not Published
Not Published
Frame Type
Not Published
Not Published
Front Axle Type
Not Published
Not Published
Drawbar Capacity
Not Published
Not Published
Front Axle Rating
Not Published
Not Published
Seat Suspension & Adjustability
Not Published
Not Published
Wheelbase
CAB: 66.7 in (1,695 mm); ROPS: 76.0 in (1,930 mm)
CAB: 66.7 in (1,695 mm); ROPS: 76.0 in (1,930 mm)
Overall Width
CAB: 55.7 in (1,415 mm); ROPS: 53.9 in (1,370 mm)
CAB: 55.7 in (1,415 mm); ROPS: 53.9 in (1,370 mm)
Ground Clearance
Not Published
Not Published
Height to Top of ROPS
96.7 in (2,455 mm)
96.7 in (2,455 mm)
Height to Top of Cab Model
85.6 in (2,175 mm)
85.6 in (2,175 mm)
Height to Top of ROPS (folded)
Not Published
Not Published
Min. Turn Radius without Brakes
Not Published
Not Published
Overall Length with 3-Point Hitch
CAB: 121.7 in (3,090 mm); ROPS: 135.0 in (3,430 mm)
CAB: 121.7 in (3,090 mm); ROPS: 135.0 in (3,430 mm)
Financing Options
0% for up to 60 Months* (Offer valid through February 28, 2026)
0% for up to 60 Months* (Offer valid through February 28, 2026)
