▶ EnginePTO Power 61 hp (45 kW) 60.0 hp (44.7 kW) (manufacturer’s estimated PTO horsepower) Alternator Not Published 12 V, 75 A Air Cleaner Not Published Dry type with safety element Engine Type 4-cylinder diesel Diesel, turbocharged and aftercooled Fuel System Electronic fuel injection High pressure common-rail direct injection Displacement 207 in³ (3400 cc) 127.6 in³ (2091 cc) No. of Cylinders 4 4 Rated Engine Speed 2300 rpm 2600 rpm Cooling System Type Not Published Liquid-cooled Engine Manufacturer FPT Industrial Yanmar Engine Emissions Constraints Tier 4B Final Final Tier 4 Engine Power (Gross vs. Net HP) ISO TR14396: 75 hp (55 kW) Gross: 74.6 hp (55.6 kW); Net: Not Published ▶ WeightTractor Weight with Loader Not Published Not Published Weight with Cab and Loader Not Applicable Not Published Weight with ROPS and Loader Not Published Not Published ▶ HydraulicsPump Type Open center Open center Steering Flow 36 L/min (9.5 gpm) 23.48 L/min (6.2 gpm) Implement Flow 64 L/min (16.9 gpm) 42.6 L/min (11.2 gpm) Total Hydraulic Flow 64 + 36 L/min (16.9 + 9.5 gpm) 66.0 L/min (17.4 gpm) Hydraulic System Type Open center Open center Rear Remote Hydraulic Flow Not Published Not Published Overall Hydraulic Pump Flow 64 + 36 L/min (16.9 + 9.5 gpm) 66.0 L/min (17.4 gpm) No. of Optional Remote Valves Not Published Up to 6 rear remotes available No. of Standard Remote Valves Not Published Not Published ▶ Tire OptionsR3 Turf - Rear Not Published 44X18-20 or 22.5LL-16.1 R3 Turf - Front Not Published 27X10.5-15 or 27X12LL-15 Tire Size & Options Not Published R1 Ag / R3 Turf / R4 Industrial / Snow R4 Industrial - Rear Not Published 16.9LX24 R4 Industrial - Front Not Published 10-16.5 R1 Agricultural - Rear Not Published 13.6-28 R1 Agricultural - Front Not Published 8-16 ▶ Pto & HitchPTO Rear 540 / 540E (Std); 540 / 540E / 1000 (Opt) 540 rpm @ 2600 rpm (540E optional) PTO Type Electrohydraulic Independent (wet disc clutch); PTO brake for mid & rear PTO Lift Control Type Mechanical Draft Control with Lift-O-Matic (Std); Electronic Draft Control (Opt) Position control (draft sensing) Hitch Lift Capacity 5,181 lb (2,350 kg) 3,079 lb (1,397 kg) at hitch balls Mid-PTO Availability Not Published Not Published Category, 3-Point Hitch Not Published Limited Category 1 Hitch Lift Capacity (at 24”) Not Published 2,709 lb (1,229 kg) @ 24 in behind Rear 3-Point Hitch Lift Capacity 5,181 lb (2,350 kg) 3,079 lb (1,397 kg) at hitch balls ▶ Fluid CapacityCoolant Capacity Not Published 8.0 qt (7.6 L) Crankcase Capacity Not Published 5.7 qt (5.4 L) (with filter) Fuel Tank Capacity 15.3 gal (58 L) 14.7 gal (55.6 L) Front Axle Fluid Capacity Not Published 5.8 qt (5.5 L) Transmission / Hydraulic System Capacity Not Published 12.5 gal (47.3 L) ▶ Loader & AttachmentsLoader Lift Height Not Published 110 in (2,796 mm) Loader Breakout Force Not Published 3,835 lbf (1,743.7 kgf) @ pivot Price for Backhoe Option Not Published Not Published Price for Mid-Mount Mower Not Published Not Published Quick Attach Loader System Not Published Quick-Park Loader System; Quik-Change Attachment Carrier Loader Lift Capacity (Full Height) Not Published 2,313 lb (1,006 kg) @ pivot ▶ Transmission & DrivetrainClutch Wet clutch Not Applicable (hydrostatic transmission) No. of Speeds 16F/16R; 32F/16R Infinitely variable / 3 range Transmission Type 16x16 Shuttle Command; 16x16 Power Shuttle; 32x16 Dual Command eHydro / 3-range hydrostatic Max Travel Speed (Forward) 25 mph (40 km/h) 18.7 mph (30.1 km/h) Max Travel Speed (Reverse) Not Published 18.7 mph (30.1 km/h) Differential Lock & Limited Slip Options Electro-hydraulic differential lock Differential lock: Yes ▶ Chassis Steering & ControlsBrakes Not Published Multi-plate wet disc Steering Not Published Hydrostatic power steering Frame Type Not Published Not Published Front Axle Type 4WD front axle MFWD (4WD) Drawbar Capacity Not Published Not Published Front Axle Rating Not Published 3,307 lb (1,500 kg) continuous Seat Suspension & Adjustability Not Published Air suspension with swivel seat ▶ Dimensions & ManeuverabilityWheelbase 85.8 in (2180 mm) 73.0 in (1,855 mm) Overall Width 41.8 in (1061 mm) 78.3 in (1,989 mm) Ground Clearance 9.8 in (250 mm) 13.8 in (351 mm) Height to Top of ROPS 98.7 in (2508 mm) 104.3 in (2,650 mm) Height to Top of Cab Model Not Applicable 97.4 in (2,474 mm) Height to Top of ROPS (folded) Not Published 80.0 in (2,033 mm) Min. Turn Radius without Brakes 13.8 ft (4.2 m) 126.0 in (3,200 mm) Overall Length with 3-Point Hitch Not Published 133.4 in (3,390 mm) ▶ Pricing Financing & WarrantyFinancing Options Not Published 0% APR fixed rate for 48 months Base Price with Loader Not Published Not Published Warranty Length & Coverage Not Published 6-year/2,000-hour powertrain; 2-year/2,000-hour basic (full machine) Base Price with Loader + Cab Not Applicable Not Published ▶ SourcesSpec sheet sources [1] cnhi-p-001-delivery.sitecorecontenthub.cloud [2] agriculture.newholland.com [1] deere.com [2] johndeere.widen.net [3] deere.com [4] deere.com
