▶ EnginePTO Power 61 hp (45 kW) 57.6 hp (43.0 kW) (OOS); 57.6 hp (43.0 kW) (Cab) Alternator Not Published 12 V, 60 A (OOS); 12 V, 110 A (Cab) Air Cleaner Not Published Dry type air cleaner with safety element Engine Type 4-cylinder diesel Diesel, turbocharged and aftercooled Fuel System Electronic fuel injection Electronically controlled, high-pressure common rail Displacement 207 in³ (3400 cc) 179 in³ (2,933 cc) No. of Cylinders 4 3 Rated Engine Speed 2300 rpm 2100 rpm Cooling System Type Not Published Liquid-cooled Engine Manufacturer FPT Industrial John Deere PowerTech™ 3029 EWR Engine Emissions Constraints Tier 4B Final EPA Final Tier 4 Engine Power (Gross vs. Net HP) ISO TR14396: 75 hp (55 kW) Gross: 74.8 hp (55.0 kW) @2100 rpm (97/68/EC) ▶ WeightTractor Weight with Loader Not Published Not Published Weight with Cab and Loader Not Applicable Not Published Weight with ROPS and Loader Not Published Not Published ▶ HydraulicsPump Type Open center Tandem gear pump (implement + steering) Steering Flow 36 L/min (9.5 gpm) 25.7 L/min (6.8 gpm) Implement Flow 64 L/min (16.9 gpm) 43.1 L/min (11.4 gpm) Total Hydraulic Flow 64 + 36 L/min (16.9 + 9.5 gpm) 68.8 L/min (18.2 gpm) Hydraulic System Type Open center Open center Rear Remote Hydraulic Flow Not Published 43.1 L/min (11.4 gpm) at a single rear SCV Overall Hydraulic Pump Flow 64 + 36 L/min (16.9 + 9.5 gpm) 68.8 L/min (18.2 gpm) No. of Optional Remote Valves Not Published 2 No. of Standard Remote Valves Not Published 1 ▶ Tire OptionsR3 Turf - Rear Not Published 41X14.00-20 4PR R3; 44X18.00-20 4PR R3 (Premium) R3 Turf - Front Not Published 33X15.50-15 6PR R3; 33X12.50-15 6PR R3; 29X12.5-15 4PR R3 (Premium) Tire Size & Options Not Published R1 Ag / R3 Turf / R4 Industrial / Snow R4 Industrial - Rear Not Published 17.5L-24 8PR R4; 19.5L-24 8PR R4; 16.9-30 10PR R4; 43X16.00-20 R4; 43X16.00-20 R4 (Premium); 18.4-30 10PR R4 R4 Industrial - Front Not Published 27/12LL-15 6PR R4; 10-16.5 8PR R4; 28X8.50-15 8PR R4; 12.5/80-18 12PR R4 R1 Agricultural - Rear Not Published 14.9-28 6PR R1; 16.9-28 6PR R1; 16.9-30 6PR R1; 18.4-30 6PR R1; 460/85R30 R1; 460/85R30 R1W R1 Agricultural - Front Not Published 9.5-24 10PR R1; 12.4-24 8PR R1; 320/85R24 R1; 320/85R24 R1W ▶ Pto & HitchPTO Rear 540 / 540E (Std); 540 / 540E / 1000 (Opt) 540 @ 2083 engine rpm; 540E @ 1588 engine rpm PTO Type Electrohydraulic Independent PTO: 540 (SyncShuttle); 540/540E (PowrReverser) Lift Control Type Mechanical Draft Control with Lift-O-Matic (Std); Electronic Draft Control (Opt) Position and draft control; adjustable rate of drop Hitch Lift Capacity 5,181 lb (2,350 kg) 3,968 lb (1,800 kg) @ hitch points Mid-PTO Availability Not Published Not Applicable Category, 3-Point Hitch Not Published Category II; convertible to Category I Hitch Lift Capacity (at 24”) Not Published 3,197 lb (1,450 kg) @ 24 in behind hitch balls Rear 3-Point Hitch Lift Capacity 5,181 lb (2,350 kg) 3,968 lb (1,800 kg) @ hitch points ▶ Fluid CapacityCoolant Capacity Not Published Open operator station: 2.85 gal (13 L); Cab: 3.08 gal (14 L) Crankcase Capacity Not Published 9.0 qt (8.5 L) (with filter) Fuel Tank Capacity 15.3 gal (58 L) Open operator station: 15.6 ± 0.44 gal (71 ± 2 L); Cab: 17.59 ± 0.44 gal (80 ± 2 L) Front Axle Fluid Capacity Not Published DANA: 1.18 gal (4.5 L) diff + 0.21 gal (0.8 L) per hub; Carraro: 1.03 gal (3.9 L) diff + 0.15 gal (0.6 L) per side Transmission / Hydraulic System Capacity Not Published 8.36 gal (38 L) (9x3); 9.46 gal (43 L) (12x12) ▶ Loader & AttachmentsLoader Lift Height Not Published 124 in (3,150 mm) Loader Breakout Force Not Published 4,354 lb (1,975 kg) (measured at pivot) Price for Backhoe Option Not Published Not Published Price for Mid-Mount Mower Not Published Not Published Quick Attach Loader System Not Published Parkable loader (parking system; no tools required for removal/installation); optional John Deere skid steer attachment carrier (tool-free attachment changes) Loader Lift Capacity (Full Height) Not Published 3,225 lb (1,463 kg) (measured at pivot) ▶ Transmission & DrivetrainClutch Wet clutch Dual clutch, 11 in (PowrReverser) No. of Speeds 16F/16R; 32F/16R 9 forward / 3 reverse (SyncShuttle); 12 forward / 12 reverse (PowrReverser) Transmission Type 16x16 Shuttle Command; 16x16 Power Shuttle; 32x16 Dual Command SyncShuttle™ 9F/3R (standard); PowrReverser™ 12F/12R (optional) Max Travel Speed (Forward) 25 mph (40 km/h) 15.5 mph (25.0 km/h) (SyncShuttle); 20.5 mph (32.9 km/h) (PowrReverser) Max Travel Speed (Reverse) Not Published 14.2 mph (22.8 km/h) (SyncShuttle); 22.3 mph (36.0 km/h) (PowrReverser) Differential Lock & Limited Slip Options Electro-hydraulic differential lock Mechanical differential lock (pedal) ▶ Chassis Steering & ControlsBrakes Not Published Hydraulically actuated wet disk brakes (self-equalizing and self-adjusting) Steering Not Published Hydrostatic power steering Frame Type Not Published Not Published Front Axle Type 4WD front axle 2WD (standard) or MFWD (optional) Drawbar Capacity Not Published 1,675 lb (760 kg) (fully extended); 2,470 lb (1,120 kg) (short position) Front Axle Rating Not Published Up to 9,612 lb (4,360 kg) (max permissible MFWD axle load w/ loader; varies by tire) Seat Suspension & Adjustability Not Published Mechanical suspension with weight adjustment; fore/aft and backrest angle adjustment ▶ Dimensions & ManeuverabilityWheelbase 85.8 in (2180 mm) 80.7 in (2,050 mm) Overall Width 41.8 in (1061 mm) Not Published Ground Clearance 9.8 in (250 mm) Not Published Height to Top of ROPS 98.7 in (2508 mm) Not Published Height to Top of Cab Model Not Applicable Not Published Height to Top of ROPS (folded) Not Published Not Published Min. Turn Radius without Brakes 13.8 ft (4.2 m) 137.8 in (3,500 mm) (2WD); 183.1 in (4,650 mm) (4WD) Overall Length with 3-Point Hitch Not Published 143.3 in (3,639 mm) ▶ Pricing Financing & WarrantyFinancing Options Not Published 0% APR fixed rate for 60 months Base Price with Loader Not Published Not Published Warranty Length & Coverage Not Published 6-year/2,000-hour powertrain; 2-year/2,000-hour basic (full machine) Base Price with Loader + Cab Not Applicable Not Published ▶ SourcesSpec sheet sources [1] cnhi-p-001-delivery.sitecorecontenthub.cloud [2] agriculture.newholland.com [1] deere.com [2] johndeere.widen.net [3] deere.com
