Pick up to 4tractors and we'll lay every spec sheet out side by side. Same data we publish on the individual model pages, stacked in columns so you can compare numbers at a glance.
—
SolisH24
—
BadBoy3026
Comparison loaded for 2 tractors.
Spec
SolisH24
Bad Boy Tractors3026
PTO Power
Not Published
18 hp
Alternator
alternator
50 A, 12 V
Air Cleaner
NOT FOUND — air cleaner type not explicitly listed in any source reviewed.
Dry, Element
Engine Type
diesel
TYM 0.3 gal 3-cyl diesel
Fuel System
Direct Injection
Diesel
Displacement
79.3 in³
70.7 in³
No. of Cylinders
3
3
Rated Engine Speed
2500 rpm
2600 rpm
Cooling System Type
Not Published
Water Cooled
Engine Manufacturer
Mitsubishi
TYM
Engine Power (Gross)
24 hp
24 hp
Engine Emissions Constraints
NOT FOUND — no emissions tier/standard (e.g. EPA Tier 4, EU Stage V) explicitly stated for the H24 in any source reviewed.
Not Published
Tractor Weight with Loader
2513 to 3108 pounds
Not Published
Weight with Cab and Loader
Not Applicable
2,106 lbs - base tractor with loader, no cab option confirmed for 3026 in available sources
Weight with ROPS and Loader
Not Published
2,107 lbs
Pump Type
Not Published
Gear Pump
Steering Flow
Not Published
3.1 gpm 11.7 lpm
Implement Flow
Not Published
4.3 gpm
Total Hydraulic Flow
3.98 gpm
7.4 gpm 28.0 lpm
Hydraulic System Type
open center
open center
Rear Remote Hydraulic Flow
Not Published
Not Published
Overall Hydraulic Pump Flow
3.98 gpm 15.1 lpm
7.7 gal per min
No. of Optional Remote Valves
Not Published
Optional (Up To 1)
No. of Standard Remote Valves
1
0
PTO Rear
540 (1.375)
540 / 960 rpm @ 2,600 rpm
PTO Type
independent
Live P.T.O. (6 Spline shaft)
Lift Control Type
NOT FOUND — no source explicitly states lift control type (e.g., position control, draft control, or float) for the Solis H24
Position control
Hitch Lift Capacity
1323 lbs 1,322.8 lb
1,433 lbs
Mid-PTO Availability
Optional
Option: 2,500 rpm (Mid)
Category, 3-Point Hitch
I
Cat 1
Hitch Lift Capacity (at 24”)
Not Published
974 lb
R3 Turf - Rear
33x15.5-16.5; 13.6x16
Not Published
R3 Turf - Front
23x8.50-12; 25x8.50-14
Not Published
Tire Size & Options
R1 Agricultural, R3 Turf, R4 Industrial
IND (Industrial) Front: 25×8.50-14; IND Rear: 14×17.5
R4 Industrial - Rear
33x15.5-16.5
14X17.5
R4 Industrial - Front
23x8.50-12
25X8.50-14
R1 Agricultural - Rear
8.3-20
11.2-20 8PR
R1 Agricultural - Front
6-12
7-16 6PR
Coolant Capacity
Not Published
1.21 gal
Crankcase Capacity
Not Published
0.79 gal
Fuel Tank Capacity
7 gal
6.08 gal
Front Axle Fluid Capacity
Not Published
0.79 gal
Transmission / Hydraulic System Capacity
Not Published
2.90 gal
Loader Lift Height
85 in
86 in.
Loader Breakout Force
1,146 lbs
1,960 lbs.
Price for Backhoe Option
backhoe
Not Published
Price for Mid-Mount Mower
60" mid-mount mower deck
Not Published
Quick Attach Loader System
HLN24 (NSL), HBLN24 (NSL), HB24 (MSL)
Front loader quick attach and latch system (Bad Boy BBL300)
Loader Lift Capacity (Full Height)
1,411 lbs
1,314 lbs.
Clutch
Not Published
Dry Single Plate
No. of Speeds
Infinite (HST - 2 Range); continuous variable forward and reverse via twin touch pedals
3 Range
Transmission Type
hydrostatic
Hydrostatic (HST)
Max Travel Speed (Forward)
Up to 14 mph
4.5~14.8 mph (7.0~14.9 mph)
Max Travel Speed (Reverse)
Up to 14 mph
4.5~14.8 mph (7.1~14.9 mph)
Differential Lock & Limited Slip Options
mechanical rear
mechanical rear
Brakes
Mechanical wet disc brakes
Wet, Multi-Disc
Steering
Power steering
Hydrostatic
Frame Type
Not Published
Steel frame with cast iron axles
Front Axle Type
Four-wheel drive
4 Wheel Drive
Drawbar Capacity
Not Published
Not Published
Front Axle Rating
Not Published
Not Published
Seat Suspension & Adjustability
Not Published
Adjustable seat; flips up and back for rear backhoe operation
Wheelbase
61.8 inches 61.4 in
65.7"
Overall Width
47.38 in.
53.9 in
Ground Clearance
9.44 in.
16.4 in
Height to Top of ROPS
91.53 in
91.4"
Height to Top of Cab Model
Not Applicable
Not Applicable
Height to Top of ROPS (folded)
Not Published
91.4 in - ROPS up (no folded dimension found in available sources)
Min. Turn Radius without Brakes
Not Published
46°
Overall Length with 3-Point Hitch
113.98 in
110 in
Financing Options
$0 down financing available for up to 84 months
0% for 72 months (with approved credit); also 3.99% APR for 84 months with $0 down (dealer-level programs vary)
Base Price with Loader
Not Published
Not Published
Warranty Length & Coverage
3-year warranty; 7-year limited powertrain
6-year powertrain warranty
Base Price with Loader + Cab
Not Applicable
Tractor with Loader (no cab available on 3026): MSRP ~$27,620 (dealer example); no cab model confirmed for 3026
