▶ EngineAlternator 42 A 40 A, 12 V Engine Type diesel 3 Cylinder, Water-Cooled, Diesel (Natural aspiration) Displacement 67.1 in³ 60.6 in³ No. of Cylinders 3 3 Engine Manufacturer ITL Yanmar Engine Power (Gross) 22 hp 21.5 hp PTO Power — 15.4 hp Air Cleaner — Single dry Fuel System — Indirect fuel injection Rated Engine Speed — 3200 rpm Cooling System Type — Water-cooled Engine Emissions Constraints — Tier 4 ▶ WeightTractor Weight with Loader 2194 lbs 2,193.6 lb Not Published Weight with Cab and Loader — Not Published Weight with ROPS and Loader — 1,433 lb ▶ PTO & HitchPTO Rear 540 540 rpm Hitch Lift Capacity 1323 lbs 1,322.8 lb 1,100 lb Category, 3-Point Hitch I Category I (N) PTO Type — Independent Lift Control Type — Position Mid-PTO Availability — Optional (2,500 rpm) Hitch Lift Capacity (at 24”) — 679 lb ▶ Tire OptionsR1 Agricultural - Rear 280/70R18 BAR R 24X12.00-12 R1 Agricultural - Front 6.5/80-12 BAR F 16X7.50-9 R3 Turf - Rear — TURF R 16X12.00-12 R3 Turf - Front — TURF F 16X7.50-8 Tire Size & Options — R1 (BAR) / R3 (TURF) / R4 (IND) R4 Industrial - Rear — 26X12-12 R4 Industrial - Front — 18X8.50-10 ▶ Fluid CapacityFuel Tank Capacity 6.9 gal 6.6 gal Coolant Capacity — 3.7 qt Crankcase Capacity — 2.1 qt (with filter) Front Axle Fluid Capacity — 2.6 qt Transmission / Hydraulic System Capacity — 3.6 gal ▶ Transmission & DrivetrainNo. of Speeds 6 2 Range Transmission Type 6-speed gear HST Differential Lock & Limited Slip Options mechanical rear Mechanical rear differential lock Clutch — Dry single plate Max Travel Speed (Forward) — 7.8 mph Max Travel Speed (Reverse) — Not Published ▶ Chassis, Steering & ControlsBrakes Wet disc brakes Wet disc Steering Power steering Hydrostatic Frame Type — Sub-compact tractor, 4WD Front Axle Type — Center pin front axle Drawbar Capacity — Not Published Front Axle Rating — Not Published Seat Suspension & Adjustability — Standard adjustable seat ▶ Dimensions & ManeuverabilityWheelbase 61.4 inches 61 in 53.1 in Overall Width — 44.5 in Ground Clearance — 8.3 in Height to Top of ROPS — 86.6 in Height to Top of Cab Model — Not Published Height to Top of ROPS (folded) — Not Published Min. Turn Radius without Brakes — Not Published Overall Length with 3-Point Hitch — 94.2 in ▶ HydraulicsPump Type — Single gear pump with flow divider Steering Flow — 2.11 gpm Implement Flow — 4.17 gpm Total Hydraulic Flow — 6.97 gpm (max total flow) Hydraulic System Type — Not Published Rear Remote Hydraulic Flow — Not Published Overall Hydraulic Pump Flow — 6.97 gpm (max total flow) No. of Optional Remote Valves — Up to 1 No. of Standard Remote Valves — Not Published ▶ Loader & AttachmentsLoader Lift Height — 72.7 in (under level bucket); 78.5 in (pivot pin) Loader Breakout Force — 1,531 lb (at pivot pin, ground level) Price for Backhoe Option — Not Published Price for Mid-Mount Mower — Optional 54 in mid-mount mower deck Quick Attach Loader System — Yes (quick attach) Loader Lift Capacity (Full Height) — 992 lb (at pivot pin) ▶ Pricing, Financing & WarrantyFinancing Options — Payments as low as $180.00/month Base Price with Loader — Not Published Warranty Length & Coverage — 7-year powertrain warranty Base Price with Loader + Cab — Not Published ▶ ITC Company AccessoriesAccessories that fit
