TYM 3515 vs Case IH FARMALL COMPACT 35A | Side-by-side comparison | ITC Resource Center
ITC Resource Center
Tractor Comparison
Pick up to 4tractors and we'll lay every spec sheet out side by side. Same data we publish on the individual model pages, stacked in columns so you can compare numbers at a glance.
No photo
—
TYM3515
No photo
—
CaseIHFARMALLCOMPACT35A
Comparison loaded for 2 tractors.
Spec
TYM3515
Case IHFARMALL COMPACT 35A
PTO Power
30 hp (22.5 kW)
29.7 hp (Mechanical shuttle); 28.0 hp (3-range hydrostatic)
Alternator
12 V, 50 A
Not Published
Air Cleaner
Dry Element
Not Published
Engine Type
3-cylinder, naturally aspirated diesel
Diesel, turbocharged
Fuel System
IDI
Not Published
Displacement
104.5 in³ (1714 cc)
1.9 L
No. of Cylinders
3
3
Rated Engine Speed
2,600 rpm
2,600 rpm
Cooling System Type
Not Published
Not Published
Engine Manufacturer
TYM
Not Published
Engine Emissions Constraints
Tier 4
Tier 4 B/Final
Engine Power (Gross vs. Net HP)
Gross: 35 hp (26.2 kW)
35 hp
Tractor Weight with Loader
HST: 4,171 lb (1,892 kg); Gear: 4,191 lb (1,901 kg)
Not Published
Weight with Cab and Loader
Not Applicable
Not Published
Weight with ROPS and Loader
HST: 4,171 lb (1,892 kg); Gear: 4,191 lb (1,901 kg)
Not Published
Pump Type
Single Gear Pump
Not Published
Steering Flow
30.3 L/min (8.0 gpm)
Not Published
Implement Flow
16.3 L/min (4.3 gpm)
31 L/min (8.2 gpm)
Total Hydraulic Flow
46.6 L/min (12.3 gpm)
Not Published
Hydraulic System Type
Open center
Open center
Rear Remote Hydraulic Flow
Not Published
Not Published
Overall Hydraulic Pump Flow
46.6 L/min (12.3 gpm)
Not Published
No. of Optional Remote Valves
Up to 4
1
No. of Standard Remote Valves
0
0
R3 Turf - Rear
Not Published
Not Published
R3 Turf - Front
Not Published
Not Published
Tire Size & Options
R1 Agricultural, R4 Industrial
Not Published
R4 Industrial - Rear
43x16.00-20
Not Published
R4 Industrial - Front
28x8.50-15
Not Published
R1 Agricultural - Rear
12.4-24
Not Published
R1 Agricultural - Front
8.0-16
Not Published
PTO Rear
560 rpm
540 rpm
PTO Type
Independent
Rear independent 540 rpm PTO with electro-hydraulic engagement (standard)
0% financing for up to 72 months and instant cash rebates. Contact dealer for more information.
Not Published
Base Price with Loader
Not Published
Not Published
Warranty Length & Coverage
Up to 2 years or until the 2,000 hours mark, bumper-to-bumper warranty; 3000 hours maximum coverage period for parts and labour on drivetrains or powertrains; 12-months warranty period for implements, including loaders and backhoes.
6-year extended warranty: 2 years bumper-to-bumper + 4 years powertrain (Compact Farmall A “Series II”)
