TYM T25 vs TYM 2610 | Side-by-side comparison | ITC Resource Center
ITC Resource Center
Tractor Comparison
Pick up to 4tractors and we'll lay every spec sheet out side by side. Same data we publish on the individual model pages, stacked in columns so you can compare numbers at a glance.
No photo
—
TYMT25
No photo
—
TYM2610
Comparison loaded for 2 tractors.
Spec
TYMT25
TYM2610
PTO Power
18.3 hp (13.6 kW)
18 hp (13.5 kW)
Alternator
12 V, 40 A
12 V, 60 A
Air Cleaner
Single dry
Dry element
Engine Type
3-cylinder, naturally aspirated diesel
3-cylinder, naturally aspirated diesel
Fuel System
IDI
IDI
Displacement
77.3 in³ (1267 cc)
71.7 in³ (1,175 cc)
No. of Cylinders
3
3
Rated Engine Speed
3,000 rpm
2,850 rpm
Cooling System Type
Water-cooled
Not Published
Engine Manufacturer
Yanmar 3TNV80F
TYM
Engine Emissions Constraints
Tier 4
Tier 4
Engine Power (Gross vs. Net HP)
Gross: 24.7 hp (18.4 kW)
Gross: 24 hp (17.9 kW)
Tractor Weight with Loader
2,726 lb (1,236 kg)
2,760 lb (1,253 kg)
Weight with Cab and Loader
Not Published
Not Applicable
Weight with ROPS and Loader
2,726 lb (1,236 kg)
2,760 lb (1,253 kg)
Pump Type
Single gear pump
Dual gear pump
Steering Flow
10.5 L/min (2.8 gpm)
12.6 L/min (3.3 gpm)
Implement Flow
15.8 L/min (4.2 gpm)
17.6 L/min (4.65 gpm)
Total Hydraulic Flow
26.3 L/min (6.9 gpm)
30.2 L/min (7.9 gpm)
Hydraulic System Type
Open center
Open center
Rear Remote Hydraulic Flow
Not Published
Not Published
Overall Hydraulic Pump Flow
26.3 L/min (6.9 gpm)
30.2 L/min (7.9 gpm)
No. of Optional Remote Valves
Not Published
2
No. of Standard Remote Valves
1
0
R3 Turf - Rear
Multi-Trac CS 33x12.50-16.5 NHS TL 4PR
33x12.50-16.5
R3 Turf - Front
Turf Master 23x8.50-12 NHS TL 4PR
23x8.50-12
Tire Size & Options
R1 Agricultural, R3 Turf, R4 Industrial
R1 Agricultural, R3 Turf, R4 Industrial
R4 Industrial - Rear
36x12.5-15; Trac Chief 14-17.5 NHS TL 6PR
12-16.5; 14-17.5
R4 Industrial - Front
Trac Chief 23x8.50-14 NHS TL 4PR
23x8.50-12; 25x8.50-14
R1 Agricultural - Rear
9.5-20 6PR
11.2-20
R1 Agricultural - Front
6-12 4PR
7.0-16
PTO Rear
540 rpm
540/1000 rpm
PTO Type
Independent
Live
Lift Control Type
Position control
Position control
Hitch Lift Capacity
1,551.2 lb (703.6 kg)
1,499 lb (680 kg)
Mid-PTO Availability
Available (Mid-PTO kit)
Available
Category, 3-Point Hitch
Category I
Category I
Hitch Lift Capacity (at 24”)
1,229.7 lb (557.8 kg)
974 lb (442 kg)
Rear 3-Point Hitch Lift Capacity
1,551.2 lb (703.6 kg)
1,499 lb (680 kg)
Coolant Capacity
3.8 qt (3.6 L)
5.3 qt (5 L)
Crankcase Capacity
2.9 qt (2.7 L)
2.9 qt (2.8 L)
Fuel Tank Capacity
6.6 gal (25 L)
6.0 gal (23 L)
Front Axle Fluid Capacity
4.7 qt (4.5 L)
3.5 qt (3.3 L)
Transmission / Hydraulic System Capacity
4.5 gal (17 L)
3.7 gal (14 L)
Loader Lift Height
87.2 in (2215 mm)
91.1 in (2,313 mm)
Loader Breakout Force
2,059 lb (934 kg)
2,077 lb (942 kg)
Price for Backhoe Option
TB65
Not Published
Price for Mid-Mount Mower
TM60
BM60L
Quick Attach Loader System
TL25: Quick attachment assembly
BL110S: Skid-steer quick attach (lever-lock)
Loader Lift Capacity (Full Height)
1,380 lb (626 kg)
1,373 lb (623 kg)
Clutch
Not Applicable
Dry single plate
No. of Speeds
Infinite 2-Range
3-Range
Transmission Type
HST
HST
Max Travel Speed (Forward)
13.7 mph (22 km/h)
17 mph (27.5 km/h)
Max Travel Speed (Reverse)
Not Published
Not Published
Differential Lock & Limited Slip Options
Not Published
Not Published
Brakes
Wet disc
Wet, Multi disc
Steering
Hydrostatic
Hydrostatic
Frame Type
Not Published
Not Published
Front Axle Type
Not Published
4WD
Drawbar Capacity
Not Published
Not Published
Front Axle Rating
Not Published
Not Published
Seat Suspension & Adjustability
Heavy duty mechanical suspension; manual weight adjustment
Comfortable suspension seat
Wheelbase
61 in (1550 mm)
65.7 in (1,670 mm)
Overall Width
50 in (1270 mm)
53.8 in (1,369 mm)
Ground Clearance
10.2 in (260 mm)
15.1 in (382 mm)
Height to Top of ROPS
91.3 in (2320 mm)
91.5 in (2,328 mm)
Height to Top of Cab Model
Not Published
Not Applicable
Height to Top of ROPS (folded)
Not Published
Not Published
Min. Turn Radius without Brakes
111.8 in (2840 mm)
L: 115.2 in (2,930 mm); R: 114 in (2,900 mm)
Overall Length with 3-Point Hitch
102.8 in (2610 mm)
122.9 in (3,122 mm)
Financing Options
0% financing for up to 72 months and instant cash rebates. Contact dealer for more information.
0% financing for up to 72 months and instant cash rebates. Contact dealer for more information.
Base Price with Loader
Not Published
Not Published
Warranty Length & Coverage
Up to 2 years or until the 2,000 hours mark, bumper-to-bumper warranty; 3000 hours maximum coverage period for parts and labour on drivetrains or powertrains; 12-months warranty period for implements, including loaders and backhoes.
Up to 2 years or until the 2,000 hours mark, bumper-to-bumper warranty; 3000 hours maximum coverage period for parts and labour on drivetrains or powertrains; 12-months warranty period for implements, including loaders and backhoes.
