Pick up to 4tractors and we'll lay every spec sheet out side by side. Same data we publish on the individual model pages, stacked in columns so you can compare numbers at a glance.
No photo
—
TYMT254
No photo
—
TYMT25
Comparison loaded for 2 tractors.
Spec
TYMT254
TYMT25
PTO Power
18.8 hp (14.0 kW)
18.3 hp (13.6 kW)
Alternator
12 V, 40 A
12 V, 40 A
Air Cleaner
Single dry
Single dry
Engine Type
3-cylinder, naturally aspirated diesel
3-cylinder, naturally aspirated diesel
Fuel System
IDI
IDI
Displacement
77.3 in³ (1267 cc)
77.3 in³ (1267 cc)
No. of Cylinders
3
3
Rated Engine Speed
3,000 rpm
3,000 rpm
Cooling System Type
Water-cooled
Water-cooled
Engine Manufacturer
Yanmar
Yanmar 3TNV80F
Engine Emissions Constraints
Tier 4
Tier 4
Engine Power (Gross vs. Net HP)
Gross: 23.9 hp (17.8 kW)
Gross: 24.7 hp (18.4 kW)
Tractor Weight with Loader
Not Published
2,726 lb (1,236 kg)
Weight with Cab and Loader
Not Published
Not Published
Weight with ROPS and Loader
Not Published
2,726 lb (1,236 kg)
Pump Type
Single gear pump
Single gear pump
Steering Flow
10.5 L/min (2.8 gpm)
10.5 L/min (2.8 gpm)
Implement Flow
15.8 L/min (4.2 gpm)
15.8 L/min (4.2 gpm)
Total Hydraulic Flow
26.3 L/min (6.9 gpm)
26.3 L/min (6.9 gpm)
Hydraulic System Type
Open center
Open center
Rear Remote Hydraulic Flow
Not Published
Not Published
Overall Hydraulic Pump Flow
26.3 L/min (6.9 gpm)
26.3 L/min (6.9 gpm)
No. of Optional Remote Valves
1
Not Published
No. of Standard Remote Valves
0
1
R3 Turf - Rear
29x12.50-15
Multi-Trac CS 33x12.50-16.5 NHS TL 4PR
R3 Turf - Front
20x8.00-10
Turf Master 23x8.50-12 NHS TL 4PR
Tire Size & Options
R1 Agricultural, R3 Turf, R4 Industrial; R4 Lg Industrial (optional)
R1 Agricultural, R3 Turf, R4 Industrial
R4 Industrial - Rear
27x12.5-15; 12-16.5
36x12.5-15; Trac Chief 14-17.5 NHS TL 6PR
R4 Industrial - Front
20x8.00-10; 23x8.50-12
Trac Chief 23x8.50-14 NHS TL 4PR
R1 Agricultural - Rear
9.5-16
9.5-20 6PR
R1 Agricultural - Front
6.0-12
6-12 4PR
PTO Rear
540 rpm
540 rpm
PTO Type
Independent
Independent
Lift Control Type
Position control
Position control
Hitch Lift Capacity
1,214 lb (551 kg)
1,551.2 lb (703.6 kg)
Mid-PTO Availability
Available
Available (Mid-PTO kit)
Category, 3-Point Hitch
Category I (Narrow)
Category I
Hitch Lift Capacity (at 24”)
1,101 lb (499 kg)
1,229.7 lb (557.8 kg)
Rear 3-Point Hitch Lift Capacity
1,214 lb (551 kg)
1,551.2 lb (703.6 kg)
Coolant Capacity
3.8 qt (3.6 L)
3.8 qt (3.6 L)
Crankcase Capacity
2.9 qt (2.7 L)
2.9 qt (2.7 L)
Fuel Tank Capacity
5.8 gal (22 L)
6.6 gal (25 L)
Front Axle Fluid Capacity
3.7 qt (3.5 L)
4.7 qt (4.5 L)
Transmission / Hydraulic System Capacity
3.7 gal (14 L)
4.5 gal (17 L)
Loader Lift Height
75 in (1905 mm)
87.2 in (2215 mm)
Loader Breakout Force
1,680 lb (720 kg)
2,059 lb (934 kg)
Price for Backhoe Option
TB60
TB65
Price for Mid-Mount Mower
MM60R
TM60
Quick Attach Loader System
TX25P: Quick attach mechanism
TL25: Quick attachment assembly
Loader Lift Capacity (Full Height)
948 lb (430 kg)
1,380 lb (626 kg)
Clutch
Not applicable
Not Applicable
No. of Speeds
Infinite 2-Range
Infinite 2-Range
Transmission Type
HST
HST
Max Travel Speed (Forward)
11.0 mph (17.7 km/h)
13.7 mph (22 km/h)
Max Travel Speed (Reverse)
Not Published
Not Published
Differential Lock & Limited Slip Options
Differential lock
Not Published
Brakes
Wet disc
Wet disc
Steering
Hydrostatic
Hydrostatic
Frame Type
Not Published
Not Published
Front Axle Type
Not Published
Not Published
Drawbar Capacity
Not Published
Not Published
Front Axle Rating
Not Published
Not Published
Seat Suspension & Adjustability
Ergonomic seating
Heavy duty mechanical suspension; manual weight adjustment
Wheelbase
57.5 in (1460 mm)
61 in (1550 mm)
Overall Width
45.8 in (1164 mm)
50 in (1270 mm)
Ground Clearance
9.4 in (240 mm)
10.2 in (260 mm)
Height to Top of ROPS
91.3 in (2320 mm)
91.3 in (2320 mm)
Height to Top of Cab Model
Not Published
Not Published
Height to Top of ROPS (folded)
Not Published
Not Published
Min. Turn Radius without Brakes
100 in (2540 mm)
111.8 in (2840 mm)
Overall Length with 3-Point Hitch
100.5 in (2553 mm)
102.8 in (2610 mm)
Financing Options
0% financing for up to 72 months and instant cash rebates. Contact dealer for more information.
0% financing for up to 72 months and instant cash rebates. Contact dealer for more information.
Base Price with Loader
Not Published
Not Published
Warranty Length & Coverage
Up to 2 years or until the 2,000 hours mark, bumper-to-bumper warranty; 3000 hours maximum coverage period for parts and labour on drivetrains or powertrains; 12-months warranty period for implements, including loaders and backhoes.
Up to 2 years or until the 2,000 hours mark, bumper-to-bumper warranty; 3000 hours maximum coverage period for parts and labour on drivetrains or powertrains; 12-months warranty period for implements, including loaders and backhoes.
