Pick up to 4tractors and we'll lay every spec sheet out side by side. Same data we publish on the individual model pages, stacked in columns so you can compare numbers at a glance.
No photo
—
TYMT254
No photo
—
YanmarSA425DHX
Comparison loaded for 2 tractors.
Spec
TYMT254
YanmarSA425DHX
PTO Power
18.8 hp (14.0 kW)
18.1 hp (13.5 kW)
Alternator
12 V, 40 A
12 V, 40 A
Air Cleaner
Single dry
Not Published
Engine Type
3-cylinder, naturally aspirated diesel
3-cylinder, naturally aspirated diesel
Fuel System
IDI
Not Published
Displacement
77.3 in³ (1267 cc)
77.2 in³ (1,266 cc)
No. of Cylinders
3
3
Rated Engine Speed
3,000 rpm
3,200 rpm
Cooling System Type
Water-cooled
Liquid cooled
Engine Manufacturer
Yanmar
YANMAR
Engine Emissions Constraints
Tier 4
Not Published
Engine Power (Gross vs. Net HP)
Gross: 23.9 hp (17.8 kW)
Gross: 23.9 hp (17.8 kW); Net: 21.7 hp (16.2 kW)
Tractor Weight with Loader
Not Published
2,338 lb (1,061 kg)
Weight with Cab and Loader
Not Published
Not Applicable
Weight with ROPS and Loader
Not Published
2,338 lb (1,061 kg)
Pump Type
Single gear pump
Not Published
Steering Flow
10.5 L/min (2.8 gpm)
14.1 L/min (3.7 gpm)
Implement Flow
15.8 L/min (4.2 gpm)
16.1 L/min (4.3 gpm)
Total Hydraulic Flow
26.3 L/min (6.9 gpm)
30.2 L/min (8.0 gpm)
Hydraulic System Type
Open center
Open center
Rear Remote Hydraulic Flow
Not Published
Not Published
Overall Hydraulic Pump Flow
26.3 L/min (6.9 gpm)
30.2 L/min (8.0 gpm)
No. of Optional Remote Valves
1
Not Published
No. of Standard Remote Valves
0
Not Published
R3 Turf - Rear
29x12.50-15
36x14.00-15 4PR
R3 Turf - Front
20x8.00-10
23x8.50-12 4PR
Tire Size & Options
R1 Agricultural, R3 Turf, R4 Industrial; R4 Lg Industrial (optional)
R3 Turf; R4 Industrial
R4 Industrial - Rear
27x12.5-15; 12-16.5
14-17.5 6PR
R4 Industrial - Front
20x8.00-10; 23x8.50-12
23x8.50-12 4PR
R1 Agricultural - Rear
9.5-16
Not Applicable
R1 Agricultural - Front
6.0-12
Not Applicable
PTO Rear
540 rpm
554 rpm @ 3,200 engine rpm
PTO Type
Independent
Independent (hydraulic clutch)
Lift Control Type
Position control
Position control
Hitch Lift Capacity
1,214 lb (551 kg)
Not Published
Mid-PTO Availability
Available
Standard
Category, 3-Point Hitch
Category I (Narrow)
Limited Category I
Hitch Lift Capacity (at 24”)
1,101 lb (499 kg)
1,209 lb (548 kg)
Rear 3-Point Hitch Lift Capacity
1,214 lb (551 kg)
Not Published
Coolant Capacity
3.8 qt (3.6 L)
3.0 qt (2.8 L)
Crankcase Capacity
2.9 qt (2.7 L)
3.6 qt (3.4 L)
Fuel Tank Capacity
5.8 gal (22 L)
6.1 gal (23.0 L)
Front Axle Fluid Capacity
3.7 qt (3.5 L)
3.7 qt (3.5 L)
Transmission / Hydraulic System Capacity
3.7 gal (14 L)
4.1 gal (15.5 L)
Loader Lift Height
75 in (1905 mm)
79 in (2,000 mm)
Loader Breakout Force
1,680 lb (720 kg)
2,090 lb (950 kg)
Price for Backhoe Option
TB60
B65: $10,668
Price for Mid-Mount Mower
MM60R
M60: 3,862
Quick Attach Loader System
TX25P: Quick attach mechanism
YL210: YANMAR quick attachment system
Loader Lift Capacity (Full Height)
948 lb (430 kg)
1,200 lb (545 kg)
Clutch
Not applicable
Not Applicable
No. of Speeds
Infinite 2-Range
Unlimited (hydrostatic); 2 ranges (High/Low)
Transmission Type
HST
Hydrostatic transmission, dual range speeds
Max Travel Speed (Forward)
11.0 mph (17.7 km/h)
13.1 mph (21.0 km/h)
Max Travel Speed (Reverse)
Not Published
9.1 mph (14.7 km/h)
Differential Lock & Limited Slip Options
Differential lock
Differential lock
Brakes
Wet disc
Wet disc
Steering
Hydrostatic
Hydrostatic power steering
Frame Type
Not Published
Full-frame chassis
Front Axle Type
Not Published
Not Published
Drawbar Capacity
Not Published
Not Published
Front Axle Rating
Not Published
Not Published
Seat Suspension & Adjustability
Ergonomic seating
Not Published
Wheelbase
57.5 in (1460 mm)
63.0 in (1,600 mm)
Overall Width
45.8 in (1164 mm)
54.1 in (1,373 mm)
Ground Clearance
9.4 in (240 mm)
9.9 in (249 mm)
Height to Top of ROPS
91.3 in (2320 mm)
87.2 in (2,215 mm)
Height to Top of Cab Model
Not Published
Not Published
Height to Top of ROPS (folded)
Not Published
71.8 in (1,824 mm)
Min. Turn Radius without Brakes
100 in (2540 mm)
8.5 ft (2.6 m)
Overall Length with 3-Point Hitch
100.5 in (2553 mm)
105.8 in (2,688 mm)
Financing Options
0% financing for up to 72 months and instant cash rebates. Contact dealer for more information.
See Exclusive Offers (promotions vary)
Base Price with Loader
Not Published
$24,599
Warranty Length & Coverage
Up to 2 years or until the 2,000 hours mark, bumper-to-bumper warranty; 3000 hours maximum coverage period for parts and labour on drivetrains or powertrains; 12-months warranty period for implements, including loaders and backhoes.
Tractor: 24 months or 2,000 hours; Powertrain: 10 years or 3,000 hours; Attachments: 1-year limited warranty
