TYM T394C vs TYM 4215C | Side-by-side comparison | ITC Resource Center
ITC Resource Center
Tractor Comparison
Pick up to 4tractors and we'll lay every spec sheet out side by side. Same data we publish on the individual model pages, stacked in columns so you can compare numbers at a glance.
No photo
—
TYMT394C
No photo
—
TYM4215C
Comparison loaded for 2 tractors.
Spec
TYMT394C
TYM4215C
PTO Power
30 hp (22.5 kW)
36 hp (26.9 kW)
Alternator
12 V, 70 A
12 V, 70 A
Air Cleaner
Dual dry
Dry element
Engine Type
3-cylinder, naturally aspirated diesel
4-cylinder, naturally aspirated diesel
Fuel System
CRDI
IDI
Displacement
100.2 in³ (1642 cc)
139.5 in³ (2,287 cc)
No. of Cylinders
3
4
Rated Engine Speed
3,000 rpm
2,600 rpm
Cooling System Type
Water-cooled
Not Published
Engine Manufacturer
Yanmar 3TNV88-CR
TYM
Engine Emissions Constraints
Tier 4
Tier 4
Engine Power (Gross vs. Net HP)
Gross: 37.4 hp (27.5 kW)
Gross: 41 hp (30.6 kW)
Tractor Weight with Loader
4,370 lb (1,982 kg)
4,652 lb (2,110 kg)
Weight with Cab and Loader
4,370 lb (1,982 kg)
4,652 lb (2,110 kg)
Weight with ROPS and Loader
Not Applicable
Not Applicable
Pump Type
Dual gear pump
Dual gear pump
Steering Flow
16.7 L/min (4.4 gpm)
19.4 L/min (5.2 gpm)
Implement Flow
23.2 L/min (6.1 gpm)
43.2 L/min (11.4 gpm)
Total Hydraulic Flow
39.9 L/min (10.5 gpm)
62.6 L/min (16.5 gpm)
Hydraulic System Type
Open center
Open center
Rear Remote Hydraulic Flow
Not Published
Not Published
Overall Hydraulic Pump Flow
39.9 L/min (10.5 gpm)
62.6 L/min (16.5 gpm)
No. of Optional Remote Valves
1 or 2
2
No. of Standard Remote Valves
0
0
R3 Turf - Rear
Multi-Trac CS 41x14.00-20 NHS TL 4PR
41x14.00, 4PR
R3 Turf - Front
Multi-Trac CS 27x8.50-15 NHS TL 4PR
27x8.5-15, 6PR
Tire Size & Options
R1 Agricultural, R3 Turf, R4 Industrial
R1 Agricultural, R3 Turf, R4 Industrial
R4 Industrial - Rear
Xtra Grip 43x16.00-20 NHS TL 6PR
380/70-19.5, 6PR
R4 Industrial - Front
Trac Chief 10-16.50 NHS TL 6PR
25x8.5-14, 6PR
R1 Agricultural - Rear
Farm Specialist 11.2-24 NHS TL 6PR
11.2-24
R1 Agricultural - Front
Farm Specialist 7-16 NHS TL 6PR
7.0-16
PTO Rear
540 rpm
540 rpm
PTO Type
Independent
Independent
Lift Control Type
Position control
Position control
Hitch Lift Capacity
2,639 lb (1,197 kg)
3,306 lb (1,500 kg)
Mid-PTO Availability
Available (Mid-PTO kit)
Not Published
Category, 3-Point Hitch
Category I
Category I
Hitch Lift Capacity (at 24”)
1,558 lb (707 kg)
2,425 lb (1,100 kg)
Rear 3-Point Hitch Lift Capacity
2,639 lb (1,197 kg)
3,306 lb (1,500 kg)
Coolant Capacity
7.4 qt (7 L)
5.8 qt (5.5 L)
Crankcase Capacity
6 qt (5.7 L)
4.8 qt (4.5 L)
Fuel Tank Capacity
9.0 gal (34 L)
7.1 gal (27 L)
Front Axle Fluid Capacity
8.7 qt (8.2 L)
6.8 qt (6.4 L)
Transmission / Hydraulic System Capacity
8.5 gal (32.2 L)
9.8 gal (37 L)
Loader Lift Height
101.5 in (2578 mm)
104.9 in (2665 mm)
Loader Breakout Force
3,435 lb (1,558 kg)
3,422 lb (1,552 kg)
Price for Backhoe Option
BY75
Not Published
Price for Mid-Mount Mower
Not Published
Not Published
Quick Attach Loader System
TX39H: Quick attachment assembly
BL150C: Quick attachment assembly
Loader Lift Capacity (Full Height)
2,116 lb (960 kg)
2,200 lb (998 kg)
Clutch
Dry single plate
Not Applicable
No. of Speeds
F12 x R12
3-Range
Transmission Type
Mechanical
HST
Max Travel Speed (Forward)
15.0 mph (24.2 km/h)
18 mph (28.9 km/h)
Max Travel Speed (Reverse)
Not Published
Not Published
Differential Lock & Limited Slip Options
Not Published
Not Published
Brakes
Wet disc
Wet, Multi disc
Steering
Hydrostatic
Hydrostatic
Frame Type
Not Published
Not Published
Front Axle Type
Not Published
Not Published
Drawbar Capacity
Not Published
Not Published
Front Axle Rating
Not Published
Not Published
Seat Suspension & Adjustability
Not Published
Comfortable suspension seat
Wheelbase
66.9 in (1700 mm)
65.7 in (1670 mm)
Overall Width
53.5 in (1360 mm)
55.6 in (1413 mm)
Ground Clearance
12.8 in (325 mm)
13.1 in (334 mm)
Height to Top of ROPS
Not Applicable
Not Applicable
Height to Top of Cab Model
92.5 in (2350 mm)
89.3 in (2267 mm)
Height to Top of ROPS (folded)
Not Applicable
Not Applicable
Min. Turn Radius without Brakes
116 in (2950 mm)
L: 124.8 in (3170 mm); R: 121.3 in (3080 mm)
Overall Length with 3-Point Hitch
126 in (3200 mm)
120.9 in (3071 mm)
Financing Options
0% financing for up to 72 months and instant cash rebates. Contact dealer for more information.
0% financing for up to 72 months and instant cash rebates. Contact dealer for more information.
Base Price with Loader
Not Published
Not Published
Warranty Length & Coverage
Up to 2 years or until the 2,000 hours mark, bumper-to-bumper warranty; 3000 hours maximum coverage period for parts and labour on drivetrains or powertrains; 12-months warranty period for implements, including loaders and backhoes.
Up to 2 years or until the 2,000 hours mark, bumper-to-bumper warranty; 3000 hours maximum coverage period for parts and labour on drivetrains or powertrains; 12-months warranty period for implements, including loaders and backhoes.
