Pick up to 4tractors and we'll lay every spec sheet out side by side. Same data we publish on the individual model pages, stacked in columns so you can compare numbers at a glance.
No photo
—
TYMT574C
No photo
—
TYMT554
Comparison loaded for 2 tractors.
Spec
TYMT574C
TYMT554
PTO Power
44.7 hp (32.9 kW)
45.6 hp (33.5 kW)
Alternator
12 V, 70 A
12 V, 70 A
Air Cleaner
Single dry
Dual dry
Engine Type
4-cylinder, turbocharged diesel
4-cylinder, turbocharged diesel
Fuel System
IDI
CRDI
Displacement
139.5 in³ (2,286 cc)
127.6 in³ (2,091 cc)
No. of Cylinders
4
4
Rated Engine Speed
2,600 rpm
2,800 rpm
Cooling System Type
Not Published
Not Published
Engine Manufacturer
TYM
Yanmar
Engine Emissions Constraints
Tier 4
Not Published
Engine Power (Gross vs. Net HP)
Gross: 55 hp (41 kW)
Gross: 55.9 hp (41.1 kW)
Tractor Weight with Loader
5,353 lb (2,428 kg)
5,075 lb (2,302 kg)
Weight with Cab and Loader
5,353 lb (2,428 kg)
Not Applicable
Weight with ROPS and Loader
Not Applicable
5,075 lb (2,302 kg)
Pump Type
Dual gear pump
Dual gear pump
Steering Flow
17.8 L/min (4.3 gpm)
17.3 L/min (4.6 gpm)
Implement Flow
29 L/min (7.7 gpm)
35.7 L/min (9.5 gpm)
Total Hydraulic Flow
46.8 L/min (11.9 gpm)
52.9 L/min (14.1 gpm)
Hydraulic System Type
Not Published
Not Published
Rear Remote Hydraulic Flow
Not Published
Not Published
Overall Hydraulic Pump Flow
46.8 L/min (11.9 gpm)
52.9 L/min (14.1 gpm)
No. of Optional Remote Valves
Not Published
Not Published
No. of Standard Remote Valves
2
2
R3 Turf - Rear
Multi-Trac CS 44x18.00-20 NHS TL 4PR
Multi-Trac CS 44x18.00-20 NHS TL 4PR
R3 Turf - Front
Multi-Trac CS 27x10.50-15 NHS TL 4PR
Multi-Trac CS 27x10.50-15 NHS TL 4PR
Tire Size & Options
R1 Agricultural, R3 Turf, R4 Industrial
R1 Agricultural, R3 Turf, R4 Industrial
R4 Industrial - Rear
Xtra Grip 17.5Lx24 NHS TL 6PR
Xtra Grip 17.5L-24 NHS TL 6PR
R4 Industrial - Front
Trac Chief 12-16.5 NHS TL 6PR
Trac Chief 12-16.5 NHS TL 6PR
R1 Agricultural - Rear
Farm Specialist 13.6-26 NHS TL 6PR
Farm Specialist 13.6-26 NHS TL 6PR
R1 Agricultural - Front
Farm Specialist 9.5-16 NHS TL 6PR
Farm Specialist 9.5-16 NHS TL 6PR
PTO Rear
540 rpm
540 rpm
PTO Type
Independent
Independent
Lift Control Type
Position/Draft
Position/Draft
Hitch Lift Capacity
3,822 lb (1,733 kg)
3,314 lb (1,503 kg)
Mid-PTO Availability
Available (Mid-PTO kit)
Not Published
Category, 3-Point Hitch
Category I
Category I
Hitch Lift Capacity (at 24”)
3,050.6 lb (1,387 kg)
2,945 lb (1,336 kg)
Rear 3-Point Hitch Lift Capacity
3,822 lb (1,733 kg)
3,314 lb (1,503 kg)
Coolant Capacity
6.9 qt (6.5 L)
9 qt (8.5 L)
Crankcase Capacity
6.8 qt (6.4 L)
7.1 qt (6.7 L)
Fuel Tank Capacity
17.0 gal (60 L)
17.0 gal (60 L)
Front Axle Fluid Capacity
10.5 qt (9.9 L)
10.5 qt (9.9 L)
Transmission / Hydraulic System Capacity
9.2 gal (34.8 L)
9.2 gal (34.8 L)
Loader Lift Height
109.4 in (2,780 mm)
109.1 in (2,770 mm)
Loader Breakout Force
5,316 lb (2,411 kg)
4,938 lb (2,240 kg)
Price for Backhoe Option
Not Published
Not Published
Price for Mid-Mount Mower
Not Published
Not Published
Quick Attach Loader System
TX57: Quick attachment (Skid/Euro type)
TX55: Quick attach mechanism
Loader Lift Capacity (Full Height)
2,790 lb (1,266 kg)
2,478 lb (1,124 kg)
Clutch
Dry single plate
Dry single plate
No. of Speeds
F8 x R8
F16 x R16
Transmission Type
Synchro-shuttle
Synchro-Shuttle
Max Travel Speed (Forward)
18.6 mph (30.0 km/h)
18.4 mph (29.7 km/h)
Max Travel Speed (Reverse)
Not Published
Not Published
Differential Lock & Limited Slip Options
Not Published
Not Published
Brakes
Wet disc
Wet disc
Steering
Hydrostatic
Hydrostatic
Frame Type
Not Published
Not Published
Front Axle Type
Not Published
Not Published
Drawbar Capacity
Not Published
Not Published
Front Axle Rating
Not Published
Not Published
Seat Suspension & Adjustability
Not Published
Not Published
Wheelbase
76.2 in (1,935 mm)
76.2 in (1,935 mm)
Overall Width
63.8 in (1,620 mm)
63.8 in (1,620 mm)
Ground Clearance
13.8 in (350 mm)
13.8 in (350 mm)
Height to Top of ROPS
Not Applicable
102.1 in (2,594 mm)
Height to Top of Cab Model
98 in (2,490 mm)
Not Applicable
Height to Top of ROPS (folded)
Not Applicable
Not Published
Min. Turn Radius without Brakes
131.5 in (3,340 mm)
150.4 in (3,820 mm)
Overall Length with 3-Point Hitch
141.3 in (3,590 mm)
141.3 in (3,590 mm)
Financing Options
0% financing for up to 72 months and instant cash rebates. Contact dealer for more information.
0% financing for up to 72 months and instant cash rebates. Contact dealer for more information.
Base Price with Loader
Not Published
Not Published
Warranty Length & Coverage
Up to 2 years or until the 2,000 hours mark, bumper-to-bumper warranty; 3000 hours maximum coverage period for parts and labour on drivetrains or powertrains; 12-months warranty period for implements, including loaders and backhoes.
Up to 2 years or until the 2,000 hours mark, bumper-to-bumper warranty; 3000 hours maximum coverage period for parts and labour on drivetrains or powertrains; 12-months warranty period for implements, including loaders and backhoes.
