Pick up to 4tractors and we'll lay every spec sheet out side by side. Same data we publish on the individual model pages, stacked in columns so you can compare numbers at a glance.
—
YanmarSA425
—
BadBoy1025
Comparison loaded for 2 tractors.
Spec
YanmarSA425
Bad Boy Tractors1025
PTO Power
18.1 hp
18.8 hp
Alternator
40 A, 12 V
40 A, 12 V
Air Cleaner
Not Published
Single element
Engine Type
3-cylinder, naturally aspirated diesel
Water cooled, 4-cycle diesel
Fuel System
Not Published
Injection pump (indirect)
Displacement
77.3 in³
77.3 in³
No. of Cylinders
3
3
Rated Engine Speed
3200 rpm
3000 rpm
Cooling System Type
Liquid cooled
Water cooled, forced circulation
Engine Manufacturer
YANMAR
Yanmar
Engine Power (Gross)
23.9 hp
24.6 hp
Engine Emissions Constraints
Not Published
Not Published
Tractor Weight with Loader
2,338 lb
Not Published
Weight with Cab and Loader
Not Applicable
Not Applicable
Weight with ROPS and Loader
2,338 lb
1,610 lb
Pump Type
Not Published
Gear pump
Steering Flow
3.7 gpm
2.8 gpm
Implement Flow
4.3 gpm
4.2 gpm
Total Hydraulic Flow
8 gpm
7.0 gpm
Hydraulic System Type
Open center
Power Assisted Hydro-Static
Rear Remote Hydraulic Flow
Not Applicable
Not Applicable
Overall Hydraulic Pump Flow
8 gpm
6.95 gpm
No. of Optional Remote Valves
Not Published
Not Published
No. of Standard Remote Valves
Not Published
Not Applicable
PTO Rear
554 rpm @ 3,200 engine rpm
540 rpm @ 2,893 engine rpm
PTO Type
Independent (hydraulic clutch)
Independent
Lift Control Type
Position control
Position control
Hitch Lift Capacity
Not Published
1,323 lb
Mid-PTO Availability
Standard
Yes (2,000 rpm @ 2,875 engine rpm)
Category, 3-Point Hitch
Limited Category I
Category I (N)
Hitch Lift Capacity (at 24”)
1,209 lb
1,101 lb @ 24 in behind lift point
R3 Turf - Rear
36x14.00-15 4PR
29X12.5-15
R3 Turf - Front
23x8.50-12 4PR
20X8-10
Tire Size & Options
R3 Turf; R4 Industrial
R1 (Ag) / R3 (Turf) / R4 (Industrial)
R4 Industrial - Rear
14-17.5 6PR
27X12-16.5
R4 Industrial - Front
23x8.50-12 4PR
23X8.5-12
R1 Agricultural - Rear
Not Applicable
9.5-16
R1 Agricultural - Front
Not Applicable
6-12
Coolant Capacity
3.0 qt
0.96 gal
Crankcase Capacity
3.6 qt
0.71 gal
Fuel Tank Capacity
6.1 gal
5.81 gal
Front Axle Fluid Capacity
3.7 qt
0.85 gal
Transmission / Hydraulic System Capacity
4.1 gal
3.83 gal
Loader Lift Height
79 in
75.5 in (pivot pin)
Loader Breakout Force
2,090 lb
1,531 lb (pivot pin, ground level)
Price for Backhoe Option
B65: $10,668
Not Published
Price for Mid-Mount Mower
M60: 3,862
Not Published
Quick Attach Loader System
YL210: YANMAR quick attachment system
Yes (quick attach)
Loader Lift Capacity (Full Height)
1,200 lb
992 lb (pivot pin)
Clutch
Not Applicable
No
No. of Speeds
Unlimited (hydrostatic); 2 ranges (High/Low)
2 range (Low/High)
Transmission Type
Hydrostatic transmission, dual range speeds
HST (Hydro Max)
Max Travel Speed (Forward)
13.1 mph
10.5 mph (H range, Ag tires)
Max Travel Speed (Reverse)
9.1 mph
Not Published
Differential Lock & Limited Slip Options
Differential lock
Differential lock
Brakes
Wet disc
Wet disc, foot-operated
Steering
Hydrostatic power steering
Power steering (hydrostatic)
Frame Type
Full-frame chassis
Sub-compact tractor; selectable 4WD
Front Axle Type
Not Published
Not Published
Drawbar Capacity
Not Published
Not Published
Front Axle Rating
Not Published
Not Published
Seat Suspension & Adjustability
Not Published
Not Published
Wheelbase
63 in
57.5 in
Overall Width
54.1 in
45.8 in
Ground Clearance
9.9 in
9.4 in
Height to Top of ROPS
87.2 in
91.3 in
Height to Top of Cab Model
Not Applicable
Not Applicable
Height to Top of ROPS (folded)
71.8 in
Not Published
Min. Turn Radius without Brakes
8.5 ft (2.6 m)
Not Published
Overall Length with 3-Point Hitch
105.8 in
104.0 in
Financing Options
See Exclusive Offers (promotions vary)
Payments as low as $213.00/month
Base Price with Loader
$20,884
Not Published
Warranty Length & Coverage
Tractor: 24 months or 2,000 hours; Powertrain: 10 years or 3,000 hours; Attachments: 1-year limited warranty
Engine & Powertrain: 84 months (7 years) or 2,000 hours
