Pick up to 4tractors and we'll lay every spec sheet out side by side. Same data we publish on the individual model pages, stacked in columns so you can compare numbers at a glance.
—
YanmarYM359
—
TYMT4058P
Comparison loaded for 2 tractors.
Spec
YanmarYM359
TYMT4058P
PTO Power
47 hp
48 hp
Alternator
Not Published
70 A, 12 V
Air Cleaner
Dual air cleaner element
Dry element
Engine Type
4-cylinder, liquid-cooled diesel
4-cylinder, turbocharged diesel
Fuel System
Not Published
IDI
Displacement
202.4 in³
139.5 in³
No. of Cylinders
4
4
Rated Engine Speed
Not Published
2600 rpm
Cooling System Type
Liquid cooled
Not Published
Engine Manufacturer
YANMAR
TYM
Engine Power (Gross)
58.9 hp
58 hp
Engine Emissions Constraints
Not Published
Tier 4
Tractor Weight with Loader
5,371 lb
5,806.2 lb
Weight with Cab and Loader
Not Applicable
Not Applicable
Weight with ROPS and Loader
5,371 lb
5,806.2 lb
Pump Type
Not Published
Single gear pump
Steering Flow
5.7 gpm
5.13 gpm
Implement Flow
10.2 gpm
11.4 gpm
Total Hydraulic Flow
15.9 gpm
16.5 gpm
Hydraulic System Type
Not Published
Not Published
Rear Remote Hydraulic Flow
Not Published
Not Published
Overall Hydraulic Pump Flow
15.9 gpm
16.5 gpm
No. of Optional Remote Valves
2
Not Published
No. of Standard Remote Valves
1
Loader: 4; Rear: 4
PTO Rear
540/540E rpm
540 rpm
PTO Type
Independent
Independent
Lift Control Type
Not Published
Position control
Hitch Lift Capacity
3,190 lb
4,409 lb
Mid-PTO Availability
Not Published
Not Published
Category, 3-Point Hitch
Category I & II
Category II
Hitch Lift Capacity (at 24”)
2,750 lb
3,748 lb
R3 Turf - Rear
44 x 18 - 20.0
44x18.00-20
R3 Turf - Front
27.0 - 10.5
29x12.5-15
Tire Size & Options
R1 Agricultural; R3 Turf; R4 Industrial
R1 Agricultural, R3 Turf, R4 Industrial
R4 Industrial - Rear
16.9 - 24.0
16.9-24
R4 Industrial - Front
10.0 - 16.5
10.5/80-18
R1 Agricultural - Rear
420/85R24 (Radial)
14.9-28
R1 Agricultural - Front
210/95R16 (Radial)
9.5-20
Coolant Capacity
Not Published
6.2 qt
Crankcase Capacity
Not Published
4.7 qt
Fuel Tank Capacity
13.2 gal
15.32 gal
Front Axle Fluid Capacity
Not Published
6.8 qt
Transmission / Hydraulic System Capacity
Not Published
11.6 gal
Loader Lift Height
113 in
117.5 in
Loader Breakout Force
3,047 lb
4,742 lb
Price for Backhoe Option
B85: $18,524
BH86
Price for Mid-Mount Mower
Not Published
Not Published
Quick Attach Loader System
YL605: Skid steer quick attach
L4058P: Quick attach mechanism
Loader Lift Capacity (Full Height)
2,500 lb (pivot pin)
3,437 lb
Clutch
Dry single
Wet, multi-disc
No. of Speeds
8F/8R
F12 x R12
Transmission Type
Synchronized shuttle shift
Power shuttle
Max Travel Speed (Forward)
18.5 mph
24.04 mph
Max Travel Speed (Reverse)
Not Published
Not Published
Differential Lock & Limited Slip Options
Not Published
Not Published
Brakes
Not Published
Wet, multi-disc
Steering
Power steering
Hydrostatic
Frame Type
Not Published
Not Published
Front Axle Type
Not Published
4WD
Drawbar Capacity
Not Published
Not Published
Front Axle Rating
Not Published
Not Published
Seat Suspension & Adjustability
Suspension seat
Suspension seat
Wheelbase
77.5 in
78.7 in
Overall Width
70.9 in (with R4 tires)
68.9 in
Ground Clearance
15.5 in
18.1 in
Height to Top of ROPS
98 in (with R4 tires)
104.7 in
Height to Top of Cab Model
Not Applicable
Not Applicable
Height to Top of ROPS (folded)
Not Published
Not Published
Min. Turn Radius without Brakes
11.8 ft (3.6 m)
L: 139.7 in; R: 141.9 in
Overall Length with 3-Point Hitch
133.9 in (with 3PH and R4 tires)
141.5 in
Financing Options
See Exclusive Offers (promotions vary)
0% financing for up to 72 months and instant cash rebates. Contact dealer for more information.
Base Price with Loader
$41,933
Not Published
Warranty Length & Coverage
10-year limited powertrain warranty or 3,000 hours (whichever comes first)
Up to 2 years or until the 2,000 hours mark, bumper-to-bumper warranty; 3000 hours maximum coverage period for parts and labour on drivetrains or powertrains; 12-months warranty period for implements, including loaders and backhoes.
