Pick up to 4tractors and we'll lay every spec sheet out side by side. Same data we publish on the individual model pages, stacked in columns so you can compare numbers at a glance.
—
YanmarYM359
—
YanmarSM475
Comparison loaded for 2 tractors.
Spec
YanmarYM359
YanmarSM475
PTO Power
47 hp
64.1 hp
Alternator
Not Published
Not Published
Air Cleaner
Dual air cleaner element
Not Published
Engine Type
4-cylinder, liquid-cooled diesel
Not Published
Fuel System
Not Published
Not Published
Displacement
202.4 in³
Not Published
No. of Cylinders
4
Not Published
Rated Engine Speed
Not Published
2200 rpm
Cooling System Type
Liquid cooled
Not Published
Engine Manufacturer
YANMAR
Deutz
Engine Power (Gross)
58.9 hp
74 hp
Engine Emissions Constraints
Not Published
Not Published
Tractor Weight with Loader
5,371 lb
Not Published
Weight with Cab and Loader
Not Applicable
Not Published
Weight with ROPS and Loader
5,371 lb
Not Published
Pump Type
Not Published
Not Published
Steering Flow
5.7 gpm
5.8 gpm
Implement Flow
10.2 gpm
10.3 gpm
Total Hydraulic Flow
15.9 gpm
16.1 gpm
Hydraulic System Type
Not Published
Not Published
Rear Remote Hydraulic Flow
Not Published
Not Published
Overall Hydraulic Pump Flow
15.9 gpm
16.1 gpm
No. of Optional Remote Valves
2
Not Published
No. of Standard Remote Valves
1
2
PTO Rear
540/540E rpm
540 rpm
PTO Type
Independent
Independent
Lift Control Type
Not Published
Not Published
Hitch Lift Capacity
3,190 lb
5,115 lb
Mid-PTO Availability
Not Published
Not Published
Category, 3-Point Hitch
Category I & II
Category II
Hitch Lift Capacity (at 24”)
2,750 lb
3,418 lb
R3 Turf - Rear
44 x 18 - 20.0
Not Published
R3 Turf - Front
27.0 - 10.5
Not Published
Tire Size & Options
R1 Agricultural; R3 Turf; R4 Industrial
Not Published
R4 Industrial - Rear
16.9 - 24.0
Not Published
R4 Industrial - Front
10.0 - 16.5
Not Published
R1 Agricultural - Rear
420/85R24 (Radial)
Not Published
R1 Agricultural - Front
210/95R16 (Radial)
Not Published
Coolant Capacity
Not Published
Not Published
Crankcase Capacity
Not Published
Not Published
Fuel Tank Capacity
13.2 gal
23.8 gal
Front Axle Fluid Capacity
Not Published
Not Published
Transmission / Hydraulic System Capacity
Not Published
Not Published
Loader Lift Height
113 in
133.8 in
Loader Breakout Force
3,047 lb
5,485 lb
Price for Backhoe Option
B85: $18,524
Not Published
Price for Mid-Mount Mower
Not Published
Not Published
Quick Attach Loader System
YL605: Skid steer quick attach
Not Published
Loader Lift Capacity (Full Height)
2,500 lb (pivot pin)
3,325 lb
Clutch
Dry single
Wet multi plate
No. of Speeds
8F/8R
Not Published
Transmission Type
Synchronized shuttle shift
Power shuttle
Max Travel Speed (Forward)
18.5 mph
Not Published
Max Travel Speed (Reverse)
Not Published
Not Published
Differential Lock & Limited Slip Options
Not Published
Rear differential lock (foot pedal engagement)
Brakes
Not Published
Not Published
Steering
Power steering
Not Published
Frame Type
Not Published
Not Published
Front Axle Type
Not Published
Selectable 2WD/4WD engagement
Drawbar Capacity
Not Published
Not Published
Front Axle Rating
Not Published
Not Published
Seat Suspension & Adjustability
Suspension seat
Mechanical suspension seat
Wheelbase
77.5 in
Not Published
Overall Width
70.9 in (with R4 tires)
Not Published
Ground Clearance
15.5 in
18.3 in
Height to Top of ROPS
98 in (with R4 tires)
Not Published
Height to Top of Cab Model
Not Applicable
Not Published
Height to Top of ROPS (folded)
Not Published
Not Published
Min. Turn Radius without Brakes
11.8 ft (3.6 m)
Not Published
Overall Length with 3-Point Hitch
133.9 in (with 3PH and R4 tires)
Not Published
Financing Options
See Exclusive Offers (promotions vary)
See Exclusive Offers (offer valid through April 30, 2026; eligibility varies)
Base Price with Loader
$41,933
Not Published
Warranty Length & Coverage
10-year limited powertrain warranty or 3,000 hours (whichever comes first)
Tractor: 24 months or 2,000 hours; Powertrain: 10 years or 3,000 hours
