Pick up to 4tractors and we'll lay every spec sheet out side by side. Same data we publish on the individual model pages, stacked in columns so you can compare numbers at a glance.
—
YanmarYM359
—
YanmarYM347
Comparison loaded for 2 tractors.
Spec
YanmarYM359
YanmarYM347
PTO Power
47 hp
35.5 hp
Alternator
Not Published
Not Published
Air Cleaner
Dual air cleaner element
Dual air cleaner element
Engine Type
4-cylinder, liquid-cooled diesel
4-cylinder, liquid-cooled diesel
Fuel System
Not Published
Not Published
Displacement
202.4 in³
133.6 in³
No. of Cylinders
4
4
Rated Engine Speed
Not Published
Not Published
Cooling System Type
Liquid cooled
Liquid cooled
Engine Manufacturer
YANMAR
YANMAR
Engine Power (Gross)
58.9 hp
46 hp
Engine Emissions Constraints
Not Published
Not Published
Tractor Weight with Loader
5,371 lb
5,129 lb
Weight with Cab and Loader
Not Applicable
Not Applicable
Weight with ROPS and Loader
5,371 lb
5,129 lb
Pump Type
Not Published
Not Published
Steering Flow
5.7 gpm
5.3 gpm
Implement Flow
10.2 gpm
9.3 gpm
Total Hydraulic Flow
15.9 gpm
14.6 gpm
Hydraulic System Type
Not Published
Not Published
Rear Remote Hydraulic Flow
Not Published
Not Published
Overall Hydraulic Pump Flow
15.9 gpm
14.6 gpm
No. of Optional Remote Valves
2
2
No. of Standard Remote Valves
1
1
PTO Rear
540/540E rpm
540/540E rpm
PTO Type
Independent
Independent
Lift Control Type
Not Published
Not Published
Hitch Lift Capacity
3,190 lb
3,190 lb
Mid-PTO Availability
Not Published
Not Published
Category, 3-Point Hitch
Category I & II
Category I & II
Hitch Lift Capacity (at 24”)
2,750 lb
2,750 lb
R3 Turf - Rear
44 x 18 - 20.0
44 x 18 - 20.0
R3 Turf - Front
27.0 - 10.5
27.0 - 10.5
Tire Size & Options
R1 Agricultural; R3 Turf; R4 Industrial
R1 Agricultural; R3 Turf; R4 Industrial
R4 Industrial - Rear
16.9 - 24.0
4.6 gal - 24.0
R4 Industrial - Front
10.0 - 16.5
10.0 - 16.5
R1 Agricultural - Rear
420/85R24 (Radial)
14.9 - 24.0
R1 Agricultural - Front
210/95R16 (Radial)
8.0 - 16.0
Coolant Capacity
Not Published
Not Published
Crankcase Capacity
Not Published
Not Published
Fuel Tank Capacity
13.2 gal
13.2 gal
Front Axle Fluid Capacity
Not Published
Not Published
Transmission / Hydraulic System Capacity
Not Published
Not Published
Loader Lift Height
113 in
113 in
Loader Breakout Force
3,047 lb
3,047 lb
Price for Backhoe Option
B85: $18,524
B85: $18,524
Price for Mid-Mount Mower
Not Published
Not Published
Quick Attach Loader System
YL605: Skid steer quick attach
YL605: Skid steer quick attach
Loader Lift Capacity (Full Height)
2,500 lb (pivot pin)
2,500 lb (pivot pin)
Clutch
Dry single
Dry single
No. of Speeds
8F/8R
8F/8R
Transmission Type
Synchronized shuttle shift
Synchronized shuttle shift
Max Travel Speed (Forward)
18.5 mph
17.7 mph
Max Travel Speed (Reverse)
Not Published
Not Published
Differential Lock & Limited Slip Options
Not Published
Not Published
Brakes
Not Published
Not Published
Steering
Power steering
Power steering
Frame Type
Not Published
Not Published
Front Axle Type
Not Published
Not Published
Drawbar Capacity
Not Published
Not Published
Front Axle Rating
Not Published
Not Published
Seat Suspension & Adjustability
Suspension seat
Suspension seat
Wheelbase
77.5 in
74.8 in
Overall Width
70.9 in (with R4 tires)
70.9 in (with R4 tires)
Ground Clearance
15.5 in
15.5 in
Height to Top of ROPS
98 in (with R4 tires)
98 in (with R4 tires)
Height to Top of Cab Model
Not Applicable
Not Applicable
Height to Top of ROPS (folded)
Not Published
Not Published
Min. Turn Radius without Brakes
11.8 ft (3.6 m)
11.5 ft (3.5 m)
Overall Length with 3-Point Hitch
133.9 in (with 3PH and R4 tires)
133.6 in (with 3PH and R4 tires)
Financing Options
See Exclusive Offers (promotions vary)
See Exclusive Offers (promotions vary)
Base Price with Loader
$41,933
$37,933
Warranty Length & Coverage
10-year limited powertrain warranty or 3,000 hours (whichever comes first)
10-year limited powertrain warranty or 3,000 hours (whichever comes first)
