Yanmar YT359C vs Yanmar YT359 | Side-by-side comparison | ITC Resource Center
ITC Resource Center
Tractor Comparison
Pick up to 4tractors and we'll lay every spec sheet out side by side. Same data we publish on the individual model pages, stacked in columns so you can compare numbers at a glance.
No photo
—
YanmarYT359C
No photo
—
YanmarYT359
Comparison loaded for 2 tractors.
Spec
YanmarYT359C
YanmarYT359
PTO Power
52.0 hp (38.3 kW)
52.0 hp (38.3 kW)
Alternator
12 V, 55 A
12 V, 55 A
Air Cleaner
Dual stage cyclonic (resin 6.5")
Dual stage cyclonic (resin 6.5")
Engine Type
4-cylinder, naturally aspirated diesel
4-cylinder, naturally aspirated diesel
Fuel System
Common rail direct injection
Common rail direct injection
Displacement
202.5 in³ (3,318 cc)
202.5 in³ (3,318 cc)
No. of Cylinders
4
4
Rated Engine Speed
2,500 rpm
2,500 rpm
Cooling System Type
Liquid cooled
Liquid cooled
Engine Manufacturer
YANMAR
YANMAR
Engine Emissions Constraints
Tier 4
Tier 4
Engine Power (Gross vs. Net HP)
Gross: 58.9 hp (43.9 kW)
Gross: 58.9 hp (43.9 kW)
Tractor Weight with Loader
5,538 lb (2,512 kg)
5,135 lb (2,329 kg)
Weight with Cab and Loader
5,538 lb (2,512 kg)
Not Applicable
Weight with ROPS and Loader
Not Applicable
5,135 lb (2,329 kg)
Pump Type
Not Published
Not Published
Steering Flow
20.1 L/min (5.3 gpm)
20.1 L/min (5.3 gpm)
Implement Flow
35.5 L/min (9.4 gpm)
35.5 L/min (9.4 gpm)
Total Hydraulic Flow
55.6 L/min (14.7 gpm)
55.6 L/min (14.7 gpm)
Hydraulic System Type
Open center
Open center
Rear Remote Hydraulic Flow
Not Published
Not Published
Overall Hydraulic Pump Flow
55.6 L/min (14.7 gpm)
55.6 L/min (14.7 gpm)
No. of Optional Remote Valves
1
1
No. of Standard Remote Valves
2
2
R3 Turf - Rear
44 x 18 - 20.0
44 x 18 - 20.0
R3 Turf - Front
27.0 - 10.5
27.0 - 10.5
Tire Size & Options
R1 Agricultural; R3 Turf; R4 Industrial
R1 Agricultural; R3 Turf; R4 Industrial
R4 Industrial - Rear
17.5L - 24.0
17.5L - 24.0
R4 Industrial - Front
10.0 - 16.5
10.0 - 16.5
R1 Agricultural - Rear
14.9 - 24.0
14.9 - 24.0
R1 Agricultural - Front
8.0 - 16.0
8.0 - 16.0
PTO Rear
540 rpm
540 rpm
PTO Type
Independent (electro-hydraulic)
Independent (electro-hydraulic)
Lift Control Type
Position control
Position control
Hitch Lift Capacity
3,307 lb (1,500 kg)
3,307 lb (1,500 kg)
Mid-PTO Availability
Not Published
Not Published
Category, 3-Point Hitch
Category I
Category I
Hitch Lift Capacity (at 24”)
2,756 lb (1,250 kg)
2,756 lb (1,250 kg)
Rear 3-Point Hitch Lift Capacity
3,307 lb (1,500 kg)
3,307 lb (1,500 kg)
Coolant Capacity
7.8 qt (7.4 L)
7.8 qt (7.4 L)
Crankcase Capacity
8.0 qt (7.6 L)
8.0 qt (7.6 L)
Fuel Tank Capacity
12.7 gal (48 L)
12.7 gal (48 L)
Front Axle Fluid Capacity
2.4 gal (9 L)
2.4 gal (9 L)
Transmission / Hydraulic System Capacity
7.7 gal (29 L)
7.7 gal (29 L)
Loader Lift Height
113 in (2,870 mm)
113 in (2,870 mm)
Loader Breakout Force
3,969 lb (1,800 kg)
3,969 lb (1,800 kg)
Price for Backhoe Option
B90: $17,560
B90: $17,560
Price for Mid-Mount Mower
Not Published
Not Published
Quick Attach Loader System
YL610: Skid-steer-style loader quick attachment system
YL610: Skid-steer-style loader quick attachment system
Loader Lift Capacity (Full Height)
2,500 lb (1,134 kg)
2,500 lb (1,134 kg)
Clutch
Clutch-less shifting (i-HMT)
Clutch-less shifting (i-HMT)
No. of Speeds
3 ranges (variable speed)
3 ranges (variable speed)
Transmission Type
I-HMT (Integrated Hydro Mechanical Transmission)
I-HMT (Integrated Hydro Mechanical Transmission)
Max Travel Speed (Forward)
18 mph (29 km/h)
18 mph (29 km/h)
Max Travel Speed (Reverse)
18 mph (29 km/h)
18 mph (29 km/h)
Differential Lock & Limited Slip Options
Rear differential lock (foot pedal engagement)
Rear differential lock (foot pedal engagement)
Brakes
Mechanical wet disc
Mechanical wet disc
Steering
Fully hydraulic power steering
Fully hydraulic power steering
Frame Type
Not Published
Not Published
Front Axle Type
Selectable 2WD/4WD engagement
Selectable 2WD/4WD engagement
Drawbar Capacity
Not Published
Not Published
Front Axle Rating
Not Published
Not Published
Seat Suspension & Adjustability
Not Published
Not Published
Wheelbase
77.4 in (1,967 mm)
77.4 in (1,967 mm)
Overall Width
70.6 in (1,793 mm)
70.6 in (1,793 mm)
Ground Clearance
12.8 in (326 mm)
12.8 in (326 mm)
Height to Top of ROPS
Not Applicable
95.7 in (2,431 mm)
Height to Top of Cab Model
89.5 in (2,274 mm)
Not Applicable
Height to Top of ROPS (folded)
Not Published
Not Published
Min. Turn Radius without Brakes
Not Published
Not Published
Overall Length with 3-Point Hitch
132.1 in (3,355 mm)
132.1 in (3,355 mm)
Financing Options
See Exclusive Offers (promotions vary)
See Exclusive Offers (promotions vary)
Base Price with Loader
Not Applicable
$52,867
Warranty Length & Coverage
Tractor: 24 months or 2,000 hours; Powertrain: 10 years or 3,000 hours; Attachments: 1-year limited warranty
Tractor: 24 months or 2,000 hours; Powertrain: 10 years or 3,000 hours; Attachments: 1-year limited warranty
